| Ref | Part Number | Description |
|---|
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 1 |
539101165 |
FILTER HEAD Price: $37.99 |
| 2 |
539102606 |
HYDRAULIC OIL FILTER Price: $22.99 |
| 2 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 2 |
725-3243 |
Fuse, 25 Amp This part replaces DD-36919-56661. Price: $4.39 |
| 3 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 3 |
539101202 |
HYDRAULIC CAP Price: $19.99 |
| 3 |
925-1381 |
Fuse, 20 Amp This part replaces DD-36919-56650. Price: $5.38 |
| 4 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 4 |
539132147 |
HG_PUMP, 10CC W/O FAN OR RTN This part replaces 539107749. Price: $1,099.99 |
| 4 |
DD-T4260-33631 |
FUSE-10A Not Available Price: |
| 5 |
539105024 |
OIL TANK Price: $249.99 |
| 5 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 5 |
DD-T4625-69281 |
Label Price: Call Us |
| 6 |
539106933 |
OIL FILTER BRKT Price: $22.99 |
| 6 |
82-9850-03 |
AXLE-REAR This part replaces 82-9850. Price: $1,614.33 |
| 6 |
DD-52300-41664 |
COVER-FUSE BOX Not Available Price: |
| 7 |
539101237 |
FITTING, STRAIGHT F6400-8-8-0 Price: $7.99 |
| 7 |
93-0311-03 |
SPINDLE-WHEEL, LH This part replaces 93-0311. Price: $378.60 |
| 7 |
DD-01023-50620 |
HEX BOLT Not Available Price: |
| 8 |
539103316 |
STRAIGHT FITG Price: $9.99 |
| 8 |
69-2990 |
STUD-WHEEL Price: $4.85 |
| 8 |
DD-44512-83172 |
SWITCH-LIMIT Not Available Price: |
| 9 |
117-8969 |
HUB ASM This part replaces 69-2960. Price: $336.24 |
| 9 |
539101238 |
ELBOW, F6801-6-6-0 90 DEGREE Price: $12.99 |
| 9 |
DD-T4340-60243 |
RELAY-TIMER Not Available This part replaces DD-T4340-60242. Price: |
| 10 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 10 |
539106896 |
HYDRAULIC HOSE Price: $37.99 |
| 10 |
DD-T4240-31052 |
FLASHER Not Available Price: |
| 11 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 11 |
539104722 |
HOSE 7" Price: $19.99 |
| 11 |
DD-02751-50060 |
HEX FLANGE NUT Not Available Price: |
| 12 |
539106895 |
TEE ASSEMBLY Price: $39.99 |
| 12 |
69-9880 |
TIRE (23X10.5-12) 6-PLY Price: $189.93 |
| 12 |
DD-T4620-69041 |
RELAY (5P) Not Available Price: |
| 13 |
23-7270 |
NUT-LUG Price: $10.37 |
| 13 |
539106897 |
TEE ASSEMBLY Price: $49.99 |
| 13 |
DD-01754-50616 |
FLANGE BOLT Not Available Price: |
| 14 |
217-116 |
WHEEL Price: $258.19 |
| 14 |
539102396 |
FITTING Price: $11.99 |
| 14 |
DD-02751-50060 |
HEX FLANGE NUT Not Available Price: |
| 15 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 15 |
539105168 |
NUT 9/16-18 JIC CAP Price: $2.99 |
| 15 |
DD-T4520-75031 |
RELAY-TEMPERATURE Not Available Price: |
| 16 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 16 |
69-2970 |
CAP-HUB Price: $20.74 |
| 16 |
DD-01754-50616 |
FLANGE BOLT Not Available Price: |
| 17 |
3220-7 |
NUT-JAM Price: $4.09 |
| 17 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 17 |
DD-02751-50060 |
HEX FLANGE NUT Not Available Price: |
| 18 |
596564801 |
Washers This part replaces 539990052. Price: $1.99 |
| 18 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 18 |
DD-T4620-69054 |
CONTROL-PREHEATER Not Available Price: |
| 19 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 19 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 19 |
DD-02751-50060 |
HEX FLANGE NUT Not Available Price: |
| 20 |
254-107 |
CUP-BEARING, TAPERED Price: $9.93 |
| 20 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 20 |
DD-T5535-69951 |
RELAY Not Available This part replaces DD-C5510-43101. Price: |
| 21 |
254-106 |
CONE-BEARING, TAPERED Price: $19.51 |
| 21 |
539103115 |
O RING Price: $2.99 |
| 21 |
DD-02751-50060 |
HEX FLANGE NUT Not Available Price: |
| 22 |
539103116 |
O RING Price: $2.99 |
| 22 |
69-2980 |
SEAL Price: $33.94 |
| 22 |
DD-T4520-75481 |
SWITCH-SAFETY STAR Not Available Price: |
| 23 |
110-6141-03 |
RH TIE ROD END ASM This part replaces 2116-4. Price: $148.18 |
| 23 |
539103117 |
O RING Price: $2.99 |
| 23 |
DD-T4520-41821 |
SWITCH ASSEMBLY-STOP Not Available Price: |
| 24 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 24 |
539103118 |
O RING Price: $2.99 |
| 24 |
DD-44512-68813 |
SWITCH-MICRO Not Available Price: |
| 25 |
2412-7 |
CLAMP ASM Price: $23.32 |
| 25 |
539103119 |
O RING Price: $3.99 |
| 25 |
DD-T4810-69251 |
SWITCH-MICRO Not Available Price: |
| 26 |
539101176 |
PULLEY Price: $37.99 |
| 26 |
DD-03054-50316 |
SCREW Not Available Price: |
| 27 |
110-9719-03 |
TIE ROD ASM This part replaces 82-9260. Price: $380.21 |
| 27 |
510201401 |
BELT, PUMP This part replaces 539106887. Price: $34.99 |
| 27 |
DD-04012-50030 |
FLAT WASHER Not Available Price: |
| 28 |
539101177 |
KEY 5 MM SQ X 25 MM Price: $4.99 |
| 28 |
DD-04512-50030 |
LOCK WASHER Not Available Price: |
| 29 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 29 |
539102717 |
SCREW 5/16C X 5/8 SQ HEAD Price: $2.99 |
| 29 |
DD-02054-50030 |
HEX NUT Not Available Price: |
| 30 |
32136-2 |
NUT-SHH Price: $3.55 |
| 30 |
539103256 |
SPRING Price: $9.99 |
| 30 |
DD-C7810-43211 |
SWITCH-START SAFET Not Available Price: |
| 31 |
32136-13 |
NUT-SHH Price: $2.85 |
| 31 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 32 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 32 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 33 |
48-6640 |
BEARING Price: $10.04 |
| 33 |
539990588 |
HCS 3/8C X 2 Price: $3.99 |
| 34 |
48-6660 |
WASHER Price: $5.22 |
| 34 |
539130532 |
KIT, IDLER ARM W/PULLEY, PUMP This part replaces 539104408. Price: $149.99 |
| 35 |
539976695 |
BUSHING, IDLER FLANGE Price: $7.99 |
| 35 |
98-7414 |
HOSE-HYD Price: $84.76 |
| 36 |
115-8014 |
CYLINDER-HYDRAULIC This part replaces 77-4800. Price: $1,015.97 |
| 36 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 37 |
596583901 |
Bolts This part replaces 539990730. Price: $2.99 |
| 37 |
98-7415 |
HOSE-HYD Price: $72.36 |
| 38 |
237-22 |
O-RING Price: $2.43 |
| 38 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 39 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 39 |
596739801 |
PULLEYS This part replaces 539976688. Price: $29.99 |
| 40 |
237-78 |
O-RING Price: $3.85 |
| 40 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 41 |
539102236 |
PAD Price: $22.99 |
| 41 |
60-3670 |
PIN Price: $12.56 |
| 42 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 42 |
82-9210 |
SHAFT-PIVOT Price: $187.73 |
| 43 |
539130532 |
KIT, IDLER ARM W/PULLEY, PUMP This part replaces 539104388. Price: $149.99 |
| 44 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 44 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 45 |
106-6895-03 |
BALL JOINT ASM This part replaces 69-9810. Price: $258.08 |
| 45 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 47 |
93-0310-03 |
SPINDLE-WHEEL, RH This part replaces 93-0310. Price: $584.69 |
| 48 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 49 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 50 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
