| Ref | Part Number | Description |
|---|
| 1 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 2 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 3 |
92-7396-03 |
MOUNT-CABLE This part replaces 92-7396. Price: $12.51 |
| 4 |
92-7520 |
THROTTLE CABLE ASM Price: $70.09 |
| 5 |
98-2352-03 |
FRAME-SEAT This part replaces 98-2352. Price: $456.00 |
| 6 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 7 |
32128-25 |
NUT-HF Price: $3.19 |
| 8 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 9 |
322-3 |
SCREW-HH Price: $0.79 |
| 10 |
93-7598 |
LEVER-THROTTLE Price: $39.13 |
| 11 |
233-42 |
KNOB Price: $12.88 |
| 12 |
66-4190 |
SPRING-IDLER, CLUTCH Price: $10.15 |
| 13 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
63-9920 |
DISCONTINUED Price: Call Us |
| 16 |
85-6910 |
DECAL-RATING, NOISE Price: $7.03 |
| 17 |
95-3477 |
DECAL - CLIP (JA) Price: $22.66 |
| 17 |
98-8110 |
DECAL-CLIP Price: $47.91 |
| 18 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350. Price: $166.30 |
| 19 |
94-2919 |
DECAL-REAR MAN,6500,JAP Price: $17.36 |
| 19 |
98-8108 |
DECAL-REAR MANIFOLD Price: $41.51 |
| 20 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 21 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 22 |
98-2354-03 |
LATCH-SEAT This part replaces 98-2354. Price: $41.34 |
| 23 |
75-3680-03 |
ROD-SEAT This part replaces 75-3680. Price: $38.90 |
| 24 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
52-5910 |
RING-RETAINING Price: $3.64 |
| 26 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 27 |
70-1480 |
RELAY Price: $105.19 |
| 28 |
76-5260 |
DISCONTINUED Price: Call Us |
| 29 |
48-7880 |
NUT-HEX Price: $0.25 |
| 30 |
48-7890 |
NUT-HEX Price: $0.25 |
| 31 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 32 |
94-3090 |
HARNESS - WIRE, MAIN Price: $1,957.31 |
| 33 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 503216620 |
503216618 |
SCREW This part replaces 503216620. Price: $3.99 |
| 503216820 |
503216220 |
SCREW W/ LOCKING FLUID This part replaces 503216820. Price: $3.99 |
| 503217716 |
503217716 |
SCREW Price: $2.99 |
| 503852801 |
503852807 |
STARTER ASSY This part replaces 503852801. Price: $64.99 |
| 503858701 |
503852807 |
STARTER ASSY This part replaces 503858701. Price: $64.99 |
| 503873302 |
503873305 |
STARTER PAWL BRIDGE This part replaces 503873302. Price: $22.99 |
| 503873502 |
544011401 |
STARTER PAWL This part replaces 503873502. Price: $9.99 |
| 503873601 |
503873601 |
SPRING Price: $3.99 |
| 503964901 |
503964901 |
STARTER PULLEY ASSY. Price: $14.99 |
| 537008401 |
537008401 |
STARTER HANDLE Price: $9.99 |
| 537034101 |
537034101 |
PLATE Price: $17.99 |
| 731711651 |
731711651 |
FLANGE NUT Price: $3.99 |
| 735310820 |
735310820 |
E-RING 4 Price: $2.99 |
