| Ref | Part Number | Description |
|---|
| 1 |
120-4010-03 |
FRAME Price: $4,870.83 |
| 2 |
161-1780 |
BUMPER ASM This part replaces 120-8919-03. Price: $324.35 |
| 3 |
115-0282 |
PROXIMITY SENSOR ASM Price: $155.22 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
325-5 |
SCREW-HH Price: $1.20 |
| 6 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 7 |
32128-23 |
NUT-HF Price: $1.51 |
| 8 |
105-8278 |
DECAL Price: $9.67 |
| 9 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 9 |
596501502 |
Keepers Price: $9.99 |
| 10 |
2412-138 |
R-CLAMP Price: $1.36 |
| 11 |
240-7 |
GROMMET-RUBBER Price: $16.51 |
| 12 |
532405472 |
RP_PULLEY ENGINE This part replaces 586728901. Price: $34.99 |
| 12 |
56-7971 |
CLAMP-TUBE Price: $17.90 |
| 13 |
3230-5 |
BOLT-CAR Price: $0.54 |
| 14 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 15 |
121-1508-0P |
BRACKET-BULKHEAD This part replaces 121-1508-03. Price: $24.95 |
| 16 |
323-6 |
SCREW-HH Price: $0.66 |
| 17 |
322-10 |
SCREW-HH Price: $0.70 |
| 18 |
69-9760 |
COVERPLATE Price: $5.38 |
| 19 |
56-7976 |
CLAMP-TUBE Price: $2.44 |
| 20 |
240-2 |
GROMMET-RUBBER Price: $20.20 |
| 21 |
121-1481-0P |
PLATE-MOUNT, LH BULKHEAD This part replaces 121-1481-03. Price: $33.56 |
| 21 |
596321701 |
Screws Price: $2.99 |
| 22 |
2412-147 |
CLAMP-R Price: $2.51 |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers Price: $2.99 |
| 45 |
596133601 |
Hardware Price: $2.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK Price: $22.99 |
| 79 |
596134202 |
Screws Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE Price: $2.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 102 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
