| Ref | Part Number | Description |
|---|
| 15 |
756-0330A |
PULLEY Not Available Price: |
| 16 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 17 |
712-04326 |
Jam Nut, 1/4-28, LH This part replaces 712-0351. Price: $13.12 |
| 18 |
738-0440 |
Shld. Spacer .375" Dia. x .170 Price: $5.45 |
| 20 |
738-0826 |
Shld. Bolt .375" Dia. x .40" Price: $11.12 |
| 22 |
741-0556 |
Needle Brg. .375" x .31 Price: $15.85 |
| 23 |
N/A |
UNKNOWN |
| 25 |
712-0138 |
Hex Patch L-Nut 1/4-28 Thd. Price: $5.99 |
| 26 |
732-0357A |
Extension Spring .33 OD x 1.12 Lg. This part replaces 732-0357. Price: $3.94 |
| 35 |
736-0410 |
FLAT WASHER .260x.880x.040:HD Not Available Price: |
| 37 |
738-0102 |
Front Axle Bolt Price: $9.22 |
| 38 |
734-1826 |
Front/Rear Wheel 8" x 2" "S" Wave This part replaces 734-1512A. Price: $29.71 |
| 39 |
736-0105 |
Bell-Wash. .380" I.D. x .88 Price: $3.96 |
| 40 |
710-1241 |
Hex Wash. Hd. Scr. 1/4 x 1" Lg. Price: $5.77 |
| 42 |
741-0492A |
Block Bushing Price: $5.41 |
| 43 |
17733 |
AXLE ASSEMBLY- Not Available Price: |
| 44 |
782-0516 |
HEIGHT ADJUSTMENT BRACKET Not Available Price: |
| 45 |
710-0653 |
Hex TT-Tap Scr. 1/4-20 x .38" Price: $3.78 |
| 46 |
731-13116-1 |
HEIGHT ADJUSTMENT KNOB This part replaces 720-0190. Price: $12.01 |
| 47 |
732-0639 |
LEVER-SPRING Not Available Price: |
| 48 |
731-1281 |
FRONT END Not Available Price: |
| 49 |
710-0352 |
Hex B-Tap Scr. 1/4" x .38" Price: $4.05 |
| 50 |
782-7558 |
BELT COVER Not Available Price: |
| 51 |
710-0599 |
Hex Wash. Hd. TT-Scr. 1/4-20 Price: $3.86 |
| 52 |
710-0896 |
Hex Wash. Hd. B-Tap Scr. 1/4 x .62" (Spec.) Price: $3.86 |
| 55 |
747-0549 |
BELT GUARD Not Available Price: |
| 56 |
710-1242 |
Torx Truss Hd. Scr. 5/16 x .75" Price: $3.95 |
| 57 |
736-0242 |
Bell-Wash. .345" I.D. x .88" Price: $3.75 |
| 59 |
946-0710A |
S.P. Cable This part replaces 746-0710A. Price: $35.59 |
| 60 |
736-0222 |
External L-Wash. 1/4" I.D. Price: $5.07 |
| 65 |
710-05177 |
CARRIAGE BOLT 1/4-20X.50" This part replaces 710-0167. Price: $4.26 |
| 67 |
912-3027 |
LOCK NUT 1/4 This part replaces 712-3027. Price: $3.85 |
