Reel Tipper Assembly
Parts (25)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 105-0138-03 | STABILIZER Price: $159.95 |
| 2 | 108-6706-03 | BRACKET-TIPPER Price: $65.54 |
| 3 | 108-6707 | ROLLER-REEL Price: $46.92 |
| 4 | 108-6705 | PIN-ROLLER Price: $9.02 |
| 5 | 105-0142-03 | ROD-PIVOT, FRONT Price: $122.57 |
| 6 | 98-3929 | SPRING-TORSION Price: $23.85 |
| 7 | 93-6738 | CHAIN Price: $13.80 |
| 8 | 3256-26 | WASHER-FLAT Price: $0.39 |
| 9 | 3234-38 | SCREW-HHF Price: $3.33 |
| 10 | 3234-1 | SCREW-HHF Price: $1.62 |
| 11 | 32151-61 | RING-RETAINING Price: $2.39 |
| 12 | 3256-24 | WASHER-FLAT Price: $0.28 |
| 13 | 3296-39 | NUT-LOCK, NI Price: $2.29 |
| 14 | 323-7 | SCREW-HH Price: $0.65 |
| 15 | 104-1805 | SPRING-TORSION, LH Price: $29.15 |
| 16 | 5-1096 | CHAIN-LIFT Price: $18.82 |
| 17 | 75-5390 | ROLLER Price: $56.69 |
| 18 | 75-5400 | PIN-ROLLER Price: $26.06 |
| 19 | 100-3892-03 | BRACKET-TIPPER, REAR Price: $42.76 |
| 20 | 112-6577-03 | SUPPORT-TIPPER BRACKET, RH Price: $77.63 |
| 21 | 112-6576-03 | SUPPORT-TIPPER BRACKET, LH Price: $77.63 |
| 22 | 323-8 | SCREW-HH Price: $1.20 |
| 23 | 3256-3 | WASHER-FLAT Price: $0.49 |
| 24 | 105-0126-03 | LH PIVOT ROD ASM Price: $130.91 |
| 25 | 105-0127-03 | RH PIVOT ROD ASM Price: $142.57 |
