| Ref | Part Number | Description |
|---|
| 1 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 1 |
601000118 |
PIN, CLEVIS .38 DIAX1.00 Price: $1.61 |
| 2 |
250-1 |
DISCONTINUED Price: Call Us |
| 2 |
601000604 |
PIN, HAIR .091 DIAX1.62LG Price: $9.99 |
| 3 |
2412-109 |
CLIP-J Price: $3.82 |
| 3 |
601000860 |
CLEVIS Price: $14.25 |
| 4 |
237-100 |
GROMMET Price: $9.73 |
| 4 |
601000362 |
ROD, 40" REAR DECK LIFT Price: $8.99 |
| 5 |
104-5232 |
CLIP-WIRE This part replaces 60-0930. Price: $3.13 |
| 5 |
601000008 |
NUT, 1/2-13 HEXJAM Price: $1.99 |
| 6 |
601000004 |
NUT, 1/2-13 .458 SQ Price: $2.99 |
| 7 |
601000837 |
SHIFT ROD Price: $4.99 |
| 7 |
82-9760 |
WIRE HARNESS - GAUGES Price: $202.94 |
| 8 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 8 |
601000059 |
NUT, 5/16-18 REGHEXCTRLK Price: $5.99 |
| 9 |
601000073 |
SCREW, 5/16-18X .75 HHC This part replaces 601000072. Price: $2.99 |
| 9 |
82-9790 |
HARNESS Price: $69.81 |
| 10 |
601000423 |
BRACKET This part replaces 601000353. Price: $62.99 |
| 10 |
82-9810 |
DISCONTINUED Price: Call Us |
| 11 |
116749 |
HORN This part replaces 48-4590. Price: $130.99 |
| 11 |
601000639 |
ADJ NUT Price: $3.99 |
| 12 |
601000669 |
WASHER, FLAT .391X1.00X. Price: $3.99 |
| 12 |
82-9940 |
HARNESS Price: $22.70 |
| 13 |
601000402 |
CHANNEL DRAWBAR Price: $36.99 |
| 13 |
75-6700 |
SENDER-MAGNETIC Price: $229.36 |
| 14 |
601000183 |
ROD.DRAWBAR NLA Price: $23.87 |
| 14 |
82-9800 |
DISCONTINUED Price: Call Us |
| 15 |
58-3850 |
CABLE Price: $80.83 |
| 15 |
601000781 |
MOWER DECK This part replaces 601000838. Price: $236.36 |
| 16 |
58-3840 |
DISCONTINUED Price: Call Us |
| 16 |
601000516 |
NUT, PUSH ON CAP .312 OD Price: $3.99 |
| 17 |
601000675 |
PF BRKT GAGE WHEEL LH This part replaces 601000225. Price: $159.99 |
| 17 |
82-9830 |
HARNESS Price: $1,044.75 |
| 18 |
601000170 |
WHEEL, SD 6.00ODX1.38WD S Price: $11.70 |
| 18 |
82-9750 |
HARNESS Price: $24.36 |
| 19 |
601000095 |
BOLT, .500X1.390 HHSH 3/8 Price: $3.92 |
| 20 |
601002407 |
NUT 3/8-16 This part replaces 601000060. Price: $3.99 |
| 20 |
63-4790 |
DISCONTINUED Price: Call Us |
| 21 |
2412-131 |
R-CLAMP-CABLE Price: $5.02 |
| 21 |
601000173 |
GUARD, BELT LH PLASTIC Price: $10.92 |
| 22 |
43-5920 |
WASHER-LOCK, SPRING This part replaces 48-8000. Price: $0.25 |
| 22 |
601000019 |
WASHER, FLAT .344X .69X. Price: $2.99 |
| 23 |
48-7880 |
NUT-HEX Price: $0.25 |
| 23 |
601000073 |
SCREW, 5/16-18X .75 HHC This part replaces 601000006. Price: $2.99 |
| 24 |
86-6450 |
DISCONTINUED Price: Call Us |
| 25 |
2412-74 |
R-CLAMP Price: $2.37 |
| 25 |
601000612 |
SHAFT/SADDLE Price: $56.99 |
| 26 |
37-2690 |
CAPACITOR Price: $155.98 |
| 26 |
601000569 |
DUST SHIELD Price: $3.99 |
| 27 |
38-2860 |
RESISTOR- 5 OHM Price: $71.95 |
| 27 |
601002315 |
BALL BEARING This part replaces 601000050. Price: $20.99 |
| 28 |
601000782 |
QUILL HOUSING This part replaces 601000839. Price: $17.99 |
| 29 |
601000572 |
SPACER Price: $3.23 |
| 30 |
601000840 |
SPACER Price: $2.43 |
| 31 |
601002500 |
PULLEY, QUILL This part replaces 601000841. Price: $21.84 |
| 32 |
601000609 |
SPECIAL WASHER Price: $3.99 |
| 33 |
601002418 |
This part replaces 601000053. Price: $2.02 |
| 34 |
601000570 |
SCREW, 5/16-18X .88 WAHHT Price: $3.99 |
| 35 |
601000345 |
PF BLADE, 20.32 HIGH-LIFT This part replaces 601000187. Price: $37.36 |
| 36 |
601002313 |
This part replaces 601000098. Price: $2.94 |
| 37 |
601000527 |
SCREW, 3/8-24X1.00 NYLHHC Price: $2.88 |
| 38 |
601000697 |
TOE GUARD This part replaces 601000200. Price: $10.99 |
| 39 |
601000073 |
SCREW, 5/16-18X .75 HHC Price: $2.99 |
| 40 |
601000223 |
CHUTE DEFLECTOR 40",42"&4 Price: $54.99 |
| 41 |
601000466 |
SPRING TORSION CHUTE DEF. Price: $7.04 |
| 42 |
601000504 |
BRACKET This part replaces 601000158. Price: $27.77 |
| 43 |
601000224 |
ROD,PIVOT 40"DECK .312DX7 Price: $10.44 |
| 44 |
601000505 |
BRKT, GAGE WHEEL RH This part replaces 601000210. Price: $17.26 |
| 45 |
601000188 |
RODS, CLUTCH Price: $22.48 |
| 46 |
601000249 |
LF CLEVIS EURO Z-P Price: $8.99 |
| 47 |
601000012 |
NUT, 5/16-18 REGHEX Price: $5.99 |
| 48 |
601000563 |
PIN,CLEVIS Price: $1.83 |
| 49 |
601000842 |
IDLER ASSEMBLY Price: Call Us |
| 50 |
601000054 |
RETAINER Price: $1.99 |
| 51 |
601000391 |
PULLEY, IDLER BFF 4.00 WI Price: $34.99 |
| 52 |
601000627 |
BOLT, 3/8-16X2.00 CARR Price: $3.99 |
| 53 |
601000222 |
BOLT, .500X2.15 HXHDCPSH Price: $10.99 |
| 54 |
601000419 |
BRACE This part replaces 601000157. Price: $2.52 |
| 55 |
601000670 |
WASHER, FLAT .391X1.0OX. Price: $2.53 |
| 56 |
601000542 |
NUT, 3/8-16 HWDFL WHIZ-LO Price: $1.75 |
| 57 |
601000172 |
ROD, BRAKE Price: $22.99 |
| 58 |
601000422 |
ROD, 40" REAR DECK LIFT Z Price: $4.99 |
| 59 |
601000106 |
WASHER, FLAT .406X .73X. Price: $1.99 |
| 60 |
601000558 |
BELT, V 5L 82.00 DECK DR Price: $64.99 |
| 61 |
601000517 |
SPRING .071 X .62 X 4.37 Price: $3.48 |
| 62 |
601000204 |
SF BLADE BRAKE ASSY. Price: $12.99 |
| 63 |
601000121 |
SCREW Price: $2.53 |
| 64 |
601002318 |
RP NUT This part replaces 601000062. Price: $9.99 |
| 65 |
601000227 |
LF CLEVIS Price: $14.89 |
| 66 |
601000015 |
WASHER, REGSPTLK.393X.68X Price: $1.66 |
| 67 |
601000013 |
NUT, 3/8-16 REGHX Price: $1.99 |
| 68 |
601000074 |
SCREW, 5/16-18X1.00 HHC Price: $1.54 |
| 69 |
601000843 |
NUT 5/16-28 THD Price: Call Us |
| 70 |
601000844 |
BOLT CARRIAGE 5/16-18X.63 GR5 Price: $0.99 |
| 71 |
601001976 |
This part replaces 601000546. Price: $1.14 |
| 72 |
601000541 |
WASHER, FLAT .375X .88X. Price: $3.99 |
