| Ref | Part Number | Description |
|---|
| 1 |
132-6259-0P |
SWITCH MOUNT ASM This part replaces 132-6259-03. Price: $105.94 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
117-5458 |
SCREW-HHF Price: $0.22 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
99-3410 |
SWITCH Price: $95.63 |
| 4 |
108-9824 |
NUT-SWITCH Price: $1.97 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
32144-69 |
SCREW-HWHTF Price: $1.58 |
| 7 |
2412-4 |
CLAMP-R Price: $4.22 |
| 8 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 9 |
120-8899 |
CABLE-BRAKE, LH Price: $97.43 |
| 10 |
322-13 |
SCREW-HH Price: $2.73 |
| 11 |
132-6290-0P |
RACK ASM This part replaces 132-6290-03. Price: $114.51 |
| 12 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 13 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 14 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 15 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 16 |
132-6288-01 |
PEDAL-BRAKE, LH Price: $132.21 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
120-8898 |
CABLE-BRAKE, RH Price: $104.62 |
| 18 |
94-3088 |
SPRING-COMPRESSION Price: $8.24 |
| 19 |
120-9694 |
PIN-CLEVIS Price: $2.17 |
| 20 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 21 |
132-6252 |
PEDAL-BRAKE, RH Price: $122.77 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 24 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 25 |
581498001 |
CABLE.BATT.RED.8GA.17 Price: $7.99 |
| 25 |
94-3050 |
PLATE-SPRING Price: $7.88 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
110-4896 |
LANYARD Price: $40.99 |
| 28 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 28 |
583390701 |
CABLE.GROUND.REAR.BATTERY.8GA This part replaces 532421686. Price: $8.99 |
| 29 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
132-6247-01 |
MOUNT-BEARING Price: $13.60 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 32 |
137-1632 |
HUB-BRAKE This part replaces 132-6229. Price: $43.71 |
| 33 |
4-2390 |
WASHER-FLAT Price: $0.62 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT This part replaces 532411933. Price: $8.99 |
| 34 |
32121-125 |
PIN-SPRING Price: $0.54 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 36 |
88-7970 |
CLIP Price: $2.51 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
