| Ref | Part Number | Description |
|---|
| 1 |
127-3023 |
CASE-GEAR Price: $644.39 |
| 1 |
532170690 |
TUBE HANDLE BAGGER This part replaces 532165249. Price: $7.14 |
| 2 |
125-6995 |
PIN Price: $5.45 |
| 3 |
125-6972 |
COVER-FILLER Price: $10.14 |
| 3 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532171041. Price: $3.99 |
| 4 |
125-7107 |
PIPE Price: $8.10 |
| 4 |
532169916 |
HANDLE.BAGGER.W/LVRS.BLK.CRD Price: $9.99 |
| 5 |
125-6909 |
O-RING Price: $2.55 |
| 6 |
127-2973 |
O-RING Price: $3.16 |
| 7 |
125-7197 |
O-RING Price: $2.55 |
| 8 |
125-7214 |
BOLT Price: $3.77 |
| 8 |
532165715 |
COVER.BAGGER.CRD.ORANGE This part replaces 532167980. Price: $289.99 |
| 9 |
127-3024 |
GEARCASE COVER ASM Price: $475.19 |
| 10 |
583110201 |
TUBE.SUPPORT.BAGGER.CRD This part replaces 532169688. Price: $59.99 |
| 11 |
125-6944 |
SEAL-OIL Price: $31.03 |
| 11 |
532165719 |
BRACKET.SUPPORT.UPPER.BAG.CRD Price: $9.99 |
| 12 |
125-6977 |
COVER Price: $8.10 |
| 13 |
125-7174 |
WASHER-SEAL Price: $5.45 |
| 14 |
125-7214 |
BOLT Price: $3.77 |
| 15 |
125-7217 |
BOLT Price: $4.58 |
| 16 |
125-7218 |
BOLT Price: $3.48 |
| 17 |
125-7222 |
BOLT Price: $4.99 |
| 19 |
596040501 |
Hardware This part replaces 532171026. Price: $2.99 |
| 21 |
532180880 |
GRASS BAG This part replaces 532165780. Price: $130.99 |
| 22 |
532165781 |
BRKT.SIDE.BAG.CRD Price: $2.99 |
| 23 |
532165782 |
TUBE.UPPER.BAG.CRD Price: $279.99 |
| 24 |
532165783 |
TUBE.PIVOT.BAG.CRD.BLACK Price: $22.99 |
| 25 |
532165784 |
TUBE Price: $21.14 |
| 26 |
532165785 |
TUBE.LOWER.BAG.CRD Price: $32.99 |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $5.99 |
| 29 |
532165839 |
PLATE Price: $4.99 |
| 33 |
532428683 |
MULCHING.PLUG.107.CRD.(2 2) This part replaces 532169380. Price: $37.99 |
| 34 |
532165570 |
HANDLE.MULCHER.92.CRD (2 2) Price: $44.99 |
| 39 |
532169997 |
SET OF SEALING STRIPS This part replaces 532169999. Price: $12.99 |
| 40 |
532169997 |
SET OF SEALING STRIPS This part replaces 532170000. Price: $12.99 |
