| Ref | Part Number | Description |
|---|
| 1 |
137-8577 |
ES REEL-SPA 4 BOLT, 8 BLD This part replaces 5-3189. Price: $506.13 |
| 2 |
10-4940 |
DISCONTINUED Price: Call Us |
| 2 |
482588 |
Clip, Fuse Holder Price: Call Us |
| 3 |
10-4930-01 |
BAR-BED This part replaces 10-4930. Price: $194.64 |
| 3 |
483571 |
Cover, Sealed Double Price: Call Us |
| 4 |
321-3 |
SCREW-HH Price: $0.28 |
| 4 |
48298 |
FUSE, 20 AMP BLADE TYPE AUTOMOTIVE Price: Call Us |
| 5 |
483629 |
Fuse Holder Assembly Price: Call Us |
| 5 |
94-6396 |
BEDKNIFE, HIGHCUT,(GREENS) This part replaces 17-7040. Price: $60.45 |
| 6 |
119-4151 |
SCREW-BEDKNIFE This part replaces 3-6462. Price: $0.41 |
| 6 |
48126 |
RUBBER BOOT Price: Call Us |
| 7 |
04020-02 |
Nut, 1/4 - 20 Hex Price: Call Us |
| 7 |
21-8450 |
REAR ROLLER ASM Price: $188.65 |
| 8 |
48029-14 |
Battery Cable, 31-1/2" Black (25KA, 26DFI, 31DFI) - Kawasaki Price: Call Us |
| 8 |
65-8600 |
KNOB-ADJUSTMENT, HEIGHT This part replaces 10-5040. Price: $43.42 |
| 9 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 9 |
3243-13 |
SCREW-SET, SQH Price: $3.32 |
| 10 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 10 |
10-5140 |
HOC ADJUSTMENT PLATE Price: $13.37 |
| 11 |
3230-23 |
SCREW-CARR This part replaces 3-5861. Price: $0.89 |
| 11 |
428183 |
Battery Hold Down Price: Call Us |
| 12 |
10-4870-01 |
HOC ADJ BRKT This part replaces 10-4870. Price: $139.58 |
| 12 |
481284 |
Bumper, Rubber 5/16-18 x 5/8" Price: Call Us |
| 13 |
04001-44 |
Bolt, Hex Head 1/4-20 x 1/2” Price: Call Us |
| 13 |
3245-7 |
SCREW-SET Price: $0.34 |
| 14 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 15 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 15 |
483278 |
Solenoid, Sealed (Briggs & Stratton) Price: Call Us |
| 16 |
04011-14 |
Screw, Self-Tapping 1/4-20 x 3/4 Price: Call Us |
| 16 |
233-28 |
BLACK KNOB Price: $18.23 |
| 17 |
302-18 |
FITTING-GREASE Price: $3.46 |
| 17 |
48029-29 |
Battery Cable, 18" Red w/Braid (25KA, 26DFI, 31DFI) - Kawasaki Price: Call Us |
| 18 |
04031-03 |
Lockwasher, 5/16" Ext. Tooth (Kohler x1) Price: Call Us |
| 18 |
10-4850 |
COMP SPRING *O Price: $9.19 |
| 19 |
04002-06 |
Bolt, Hex Head M8 - 1.25 x 16 (48V / 52V) Price: Call Us |
| 19 |
10-4880 |
HOC ADJ PIN Price: $13.28 |
| 20 |
483529 |
Wire Harness Adapter, Kawasaki (not shown) Price: Call Us |
| 20 |
603773 |
LOCKNUT This part replaces 32146-2. Price: $2.09 |
| 21 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 21 |
323-2 |
SCREW-HH Price: $0.68 |
| 22 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 22 |
10-5080-01 |
CAP-END This part replaces 10-5080. Price: $94.19 |
| 23 |
253-61 |
SEAL-OIL Price: $9.11 |
| 23 |
427961 |
Plate, Anti-Rotation Price: Call Us |
| 24 |
04041-28 |
Flatwasher, 7/16-.469 x 1.75 x .25 (48, 52) Price: Call Us |
| 24 |
3296-60 |
NUT-LOCK, NI This part replaces 32127-46. Price: $5.08 |
| 25 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 25 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 26 |
04102-12 |
Bolt, Hex Head 7/16-20 x 3¼" w/Patch Price: Call Us |
| 26 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 27 |
108-6475 |
KIT-BEARING HOUSING This part replaces 10-5120. Price: $42.60 |
| 27 |
483958 |
Diode, 600V 6 Amp Price: Call Us |
| 28 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 28 |
485956 |
Pulley, 4-1/2" - 1" Bore Price: Call Us |
| 29 |
04063-01 |
Key, 1/4 x 1/4 x 1.25" Pulley Mtg. Price: Call Us |
| 29 |
94-2958 |
STUD/BALL This part replaces 2411-7. Price: $6.70 |
| 30 |
04117-03 |
Nut, Flanged Elastic Stop 1/4-20 Price: Call Us |
| 30 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 31 |
10-5010 |
SCREW-ADJUSTMENT, ROLLER Price: $53.13 |
| 31 |
426727 |
Bracket, Switch Price: Call Us |
| 32 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 32 |
10-5060 |
BRACKET-HOC Price: $38.24 |
| 33 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 33 |
486518 |
Wire Harness Price: Call Us |
| 34 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 34 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 35 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 35 |
3217-5 |
NUT-HEX Price: $0.25 |
| 36 |
217-74 |
BOLT-WHEEL Price: $4.87 |
| 36 |
483474 |
Switch, Double Pole - Twist Price: Call Us |
| 37 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 37 |
483473 |
Switch, Double Pole - Plunger Price: Call Us |
| 38 |
04003-02 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4" Price: Call Us |
| 38 |
3217-6 |
NUT-HEX Price: $1.19 |
| 39 |
323-19 |
SCREW-HH This part replaces 3290-316. Price: $1.70 |
| 40 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 40 |
462069 |
Key, Assembly w/Fob Price: Call Us |
| 41 |
321-4 |
SCREW-HH Price: $0.99 |
| 41 |
483472 |
Ignition Switch Price: Call Us |
| 42 |
04021-26 |
Nut, Elastic Stop #10-24 Price: Call Us |
| 42 |
11-0070 |
SCRAPER COMB ASM Price: $92.26 |
| 43 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 43 |
483645 |
Throttle Control, Kawasaki Price: Call Us |
| 44 |
04003-43 |
Bolt, Carriage #10-24 x 1/2" Price: Call Us |
| 44 |
3219-1 |
NUT-HEX Price: $0.47 |
| 45 |
3230-5 |
BOLT-CAR Price: $0.54 |
| 45 |
483646 |
Choke Control, Kawasaki Price: Call Us |
| 46 |
04030-02 |
Lockwasher, 1/4†Spring Price: Call Us |
| 46 |
253-96 |
SEAL-OIL Price: $6.85 |
| 47 |
04040-14 |
Flatwasher, 1/4" (.312 x .750 x .065") Price: Call Us |
| 47 |
10-5020 |
DISCONTINUED Price: Call Us |
| 48 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 49 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 49 |
484565 |
Hour Meter, Inductive Price: Call Us |
| 50 |
32108-20 |
SCREW Price: $0.61 |
| 50 |
485833 |
Switch, PTO - 10 Amp Price: Call Us |
| 51 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 51 |
20-2930 |
DISCONTINUED X-REF Price: Call Us |
| 52 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 52 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 53 |
93-1394 |
NUT-SPLINE This part replaces 10-5100. Price: $27.80 |
| 54 |
285-14 |
DISCONTINUED Price: Call Us |
| 55 |
20-4700-01 |
DISCONTINUED This part replaces 20-4700. Price: Call Us |
