| Ref | Part Number | Description |
|---|
| 1 |
27-6860 |
DISCONTINUED Price: Call Us |
| 1 |
532125098 |
Dash (AYP part number) Price: $3.33 |
| 2 |
874180512 |
Truss Hd. Screw (AYP part number) Price: $3.99 |
| 2 |
99-6969 |
SEAL-OIL, WHEEL END This part replaces 21-8330. Price: $14.71 |
| 3 |
21-8180 |
BEARING ASM Price: $65.11 |
| 3 |
873510500 |
Keps Nut (AYP part number) Price: $5.99 |
| 4 |
21-9450 |
SHIELD-DUST Price: $45.14 |
| 4 |
532109816 |
Snap-In Nyliner (AYP part number) Price: $2.99 |
| 5 |
21-9410 |
SEE P.B.#734A Price: Call Us |
| 5 |
532132771 |
Control Th/ch RH Blk Tee 15 10 (AYP part number) This part replaces 532121299. Price: $37.99 |
| 6 |
21-9390 |
SOCKET-SCREW, ADJUSTING Price: $5.56 |
| 6 |
817720410 |
Thread Cutting Hex Screw (AYP part number) Price: $5.99 |
| 7 |
21-9370 |
SCREW-ADJUSTING Price: $18.80 |
| 7 |
532105621 |
Lower Dash (AYP part number) Price: $3.33 |
| 8 |
21-9380 |
NUT-PIVOT Price: $26.77 |
| 8 |
817190508 |
Thread Cutting Hex Screw (AYP part number) Price: $4.99 |
| 9 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 9 |
532124814 |
Saddle (AYP part number) Price: $3.33 |
| 10 |
21-8360 |
CLIP-RETAINING Price: $1.29 |
| 10 |
817190608 |
Thd. Roll. Washer Hd. Hex Screw (AYP part number) Price: $3.33 |
| 11 |
28-0680-03 |
DRUM-BRAKE This part replaces 28-0680. Price: $358.84 |
| 11 |
532002751 |
Clip, Insulated (AYP part number) This part replaces 532124996. Price: $2.42 |
| 12 |
32152-5 |
NUT-HEX Price: $0.54 |
| 12 |
532124234 |
Steering Wheel Cap Decal (AYP part number) Price: $3.33 |
| 13 |
28-0670 |
SEAL-GREASE Price: $19.74 |
| 13 |
532100710 |
Steering Wheel Insert (AYP part number) Price: $10.20 |
| 14 |
21-9440 |
SPRING-SCREW, ADJUSTING Price: $11.92 |
| 14 |
873940800 |
Hex Jam Locknut (AYP part number) Price: $3.99 |
| 15 |
21-9460 |
RETAINER-LEVER, BRAKE Price: $2.18 |
| 15 |
532100712 |
Washer (AYP part number) Price: $2.42 |
| 16 |
21-9470 |
SEE PB #747 Price: Call Us |
| 16 |
532100713 |
Steering Wheel (AYP part number) Price: $64.99 |
| 17 |
21-9420 |
SPRING-RETURN, LH Price: $19.96 |
| 17 |
532100711 |
Steering Wheel Adaptor (AYP part number) Price: $11.99 |
| 18 |
21-9430 |
SPRING-RETURN, RH Price: $19.96 |
| 18 |
532109285 |
Steering Sleeve (AYP part number) Price: $34.99 |
| 19 |
27-6880 |
BRAKE LEVER ASSY Price: $85.13 |
| 19 |
532105643 |
Upper Steering Shaft (AYP part number) Price: $64.99 |
| 20 |
21-8320 |
REFER TO(PB#807 OR MISC COMM SB#50) Price: Call Us |
| 20 |
874760620 |
Hex Bolt 3/8-16 x 1-1/4 (AYP part number) Price: $3.99 |
| 21 |
873680600 |
Crownlock Nut Price: $1.99 |
| 21 |
99-5691 |
SCREW W/WASHER This part replaces 28-0660. Price: $7.18 |
| 22 |
817211008 |
Screw, Hex Wsh. Tap #10-16 x 1/2 (AYP part number) This part replaces 817431008. Price: $2.99 |
| 23 |
532108456 |
Operating Instruction Decal (AYP part number) Price: $3.33 |
| 24 |
532109284 |
Steering Bushing (AYP part number) Price: Call Us |
| 25 |
532110150 |
STEERING KIT This part replaces 532109432. Price: $30.42 |
| 26 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 27 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 28 |
532108684 |
Sector Gear (AYP part number) Price: $23.99 |
| 29 |
532106126 |
Woodruff Key (AYP part number) Price: $2.42 |
| 30 |
812000029 |
Klip Ring (AYP part number) Price: $1.99 |
| 31 |
532101930 |
Hardened Washer (AYP part number) Price: $3.08 |
| 32 |
532109068 |
Lower Steering Shaft (AYP part number) Price: $3.33 |
| 33 |
532001572 |
Pin, Roll, 3/16 x 1 (AYP part number) This part replaces 532002882. Price: $3.99 |
| 34 |
532074580 |
Spacer (AYP part number) Price: $2.42 |
| 35 |
532071208 |
Bushing (AYP part number) Price: $3.99 |
| 36 |
532108683 |
Steering Rod (AYP part number) Price: $21.70 |
| 37 |
532105663 |
Rear Saddle Support (AYP part number) Price: $8.25 |
| 38 |
532105664 |
Front Saddle Support (AYP part number) Price: $9.99 |
| 39 |
874761060 |
Hex Bolt (AYP part number) Price: $3.99 |
| 40 |
532105669 |
Front Axle (AYP part number) Price: $3.33 |
| 41 |
532110438 |
Front Axle Bearing Spacer (AYP part number) Price: $5.99 |
| 42 |
583612401 |
LOCKNUT M (1 2) (5 2) This part replaces 873901000. Price: $2.99 |
| 43 |
817490508 |
Thd. Roll. Washer Hd. Hex Screw (AYP part number) Price: $3.99 |
| 44 |
532108685 |
Pinion Gear (AYP part number) Price: $29.08 |
| 45 |
532003366 |
Bearing (AYP part number) Price: $1.99 |
| 46 |
532192757 |
ROD.TIE.WIRE.FORM This part replaces 532105715. Price: $12.99 |
| 47 |
532126847 |
BUSHING.DRAGLINK (2 2) This part replaces 532120754. Price: $2.99 |
| 48 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 49 |
876020412 |
Cotter Pin (AYP part number) Price: $3.99 |
| 50 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 51 |
873680600 |
LOCKNUT This part replaces 873610600. Price: $1.99 |
| 52 |
532105727 |
Drag Link (AYP part number) Price: $64.99 |
| 53 |
532156483 |
SPINDLE ASM LH This part replaces 532105656. Price: $14.99 |
| 54 |
532105654 |
R.H. Spindle (AYP part number) Price: $32.99 |
| 55 |
532000278 |
Grease Fitting (AYP part number) Price: $2.99 |
| 56 |
532009040 |
Flange Fitting Price: $3.99 |
| 57 |
532106732 |
RIM.ASM.6".FRONT.SILVER This part replaces 532125021. Price: $59.99 |
| 58 |
532059192 |
Valve Cap (AYP part number) Price: $3.99 |
| 59 |
532065139 |
Valve Stem (AYP part number) Price: $5.99 |
| 60 |
532124157 |
Front Tire (AYP part number) Price: $3.33 |
| 61 |
532121749 |
Washer (AYP part number) Price: $1.99 |
| 62 |
532104757 |
Front Hub Cap (AYP part number) Price: $1.99 |
| 63 |
532059904 |
Front Tube (Not furnished with tractor) Price: $22.99 |
| 64 |
532110130 |
Steering Retainer (AYP part number) Price: $4.99 |
| 65 |
532122819 |
Special Screw (AYP part number) Price: $2.38 |
| 66 |
532110307 |
Clutch Lever Stop Mower (AYP part number) Price: $3.33 |
| 67 |
532121748 |
Washer (AYP part number) Price: $1.99 |
| 68 |
819272016 |
Washer (AYP part number) Price: $2.99 |
