| Ref | Part Number | Description |
|---|
| 1 |
120-6049 |
FRAME AND AXLE ASM Price: $6,666.99 |
| 2 |
119-6224 |
SEE NOTES Price: $361.87 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
T0000-3423 |
JACK-SIDEWIND This part replaces 106-9699. Price: $134.35 |
| 4 |
110-7518-03 |
PLATE-HITCH, LH Price: $55.90 |
| 5 |
110-7519-03 |
PLATE-HITCH, RH Price: $68.60 |
| 6 |
131-4381-01 |
HITCH-CLEVIS This part replaces 47-3550-03. Price: $161.64 |
| 7 |
327-17 |
SCREW-HH Price: $8.50 |
| 8 |
327-12 |
SCREW-HH Price: $7.26 |
| 9 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 10 |
20-9580 |
ROPE-LATCH Price: $47.65 |
| 11 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 17 |
13-6890-01 |
GUIDE-ROPE Price: $119.16 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 18 |
13-6910-01 |
SPACER-GUIDE, ROPE Price: $18.39 |
| 19 |
2412-40 |
CLAMP-CONDUIT Price: $6.72 |
| 20 |
32104-95 |
SCREW-HWH Price: $0.41 |
| 21 |
32104-96 |
SCREW-HH Price: $5.59 |
| 22 |
106-0262-01 |
MOUNT-HARNESS Price: $23.39 |
| 23 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 24 |
323-6 |
SCREW-HH Price: $0.66 |
| 25 |
121-2778-03 |
GUARD-BELT Price: $374.83 |
| 26 |
121-2784-03 |
GUARD-FOOT Price: $299.44 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 27 |
121-2682-03 |
GUARD-BRUSH, LH Price: $56.94 |
| 28 |
121-2683-03 |
COVER-BRUSH, RH Price: $71.29 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 30 |
121-2686-03 |
COVER-BRUSH, CENTER Price: $87.34 |
| 31 |
105-4886 |
NUT-TINNERMAN Price: $2.37 |
| 32 |
110-5052 |
SCREW-HHF Price: $1.22 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
121-2706-03 |
SUPPORT-COVER Price: $25.32 |
| 35 |
583864502 |
Rods This part replaces 583864501. Price: $6.99 |
| 36 |
321-4 |
SCREW-HH Price: $0.99 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 80 |
531064101 |
SERVICE KIT TORQUE STRAP BLACK This part replaces 532410024. Price: $19.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
532415742 |
ROD.SPRING.BYPASS.K46.LT.Z Price: $7.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 532403118. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH This part replaces 532197867. Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 226 |
531170501 |
SERVICE KIT BRACKET This part replaces 532401564. Price: $4.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 230 |
532188967 |
WASHER.HARDENED Price: $3.99 |
