| Ref | Part Number | Description |
|---|
| 1 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 2 |
117-9565-01 |
TUBE-CROSS Price: $620.99 |
| 2 |
575532301 |
Screw (2 pack) (9SXMBJ05-50) Price: $1.99 |
| 3 |
575630301 |
Spark Plug Price: $6.99 |
| 3 |
93-4696 |
PIN-HITCH Price: $5.84 |
| 4 |
119-9020-0P |
PIVOT HUB ASM This part replaces 119-9020-03. Price: $270.51 |
| 4 |
575532501 |
Screw (4 pack) (9SGEB-05-10) Price: $1.99 |
| 5 |
119-9018 |
HANDLE PIVOT ASM Price: $412.34 |
| 5 |
574587301 |
Plate (spark side) Price: $1.99 |
| 6 |
108-4548 |
SPRING-TORSION Price: $64.72 |
| 6 |
575532401 |
Screw (4 pack) (9SRCB-05-22) Price: $1.99 |
| 7 |
120-3414 |
HANDLE ASM Price: $412.45 |
| 8 |
233-48 |
KNOB Price: $10.92 |
| 8 |
575532201 |
Screw (4 pack) (9SGEB-04-10) Price: $1.99 |
| 9 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 9 |
574588701 |
Ring - Piston Price: $1.99 |
| 10 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 10 |
574589401 |
Assembly - Crankshaft & Rod Price: $17.99 |
| 11 |
109-1063 |
SCREW-WING Price: $3.49 |
| 11 |
574589301 |
Key Price: $3.99 |
| 12 |
120-3404 |
BLOCK-GUIDE Price: $43.90 |
| 12 |
574589501 |
IGNITION COIL This part replaces 575630401. Price: $9.99 |
| 13 |
117-2486-01 |
GUIDE Price: $43.49 |
| 13 |
575532101 |
Screw (5 pack) (9SGEB-05-20) Price: $1.99 |
| 14 |
574589701 |
Coil Wire Price: $1.99 |
| 14 |
59-9460 |
GUIDE Price: $14.60 |
| 15 |
115-5103 |
SCREW-HHF Price: $0.34 |
| 15 |
574592301 |
Flywheel Price: $11.99 |
| 16 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 16 |
574592201 |
C-Ring Price: $1.99 |
| 17 |
575531601 |
Bearing (2 pack) (9DB-620101) Price: $1.99 |
| 17 |
98-1375 |
SCREW-HWH Price: $1.45 |
| 18 |
120-3413 |
CUTTER HEAD ASM Price: $828.24 |
| 19 |
112-9318 |
SCREW-HHF, LOCKING Price: $1.38 |
| 19 |
574590001 |
Assembly - Pawls Price: $2.99 |
| 20 |
574859201 |
Kit - Rope & Handle Price: $1.99 |
| 20 |
93-6024 |
BUSHING-SUPPORT, HANDLE Price: $14.67 |
| 21 |
323-14 |
SCREW-HH Price: $1.34 |
| 21 |
575532001 |
Screw (4 pack) (9SGKB-05-12.5) Price: $1.99 |
| 23 |
574591401 |
Insulator Price: $3.99 |
| 24 |
574590801 |
Plate Price: $1.99 |
| 25 |
575531801 |
Screw (4 pack) (9SKKB-05-19) Price: $1.99 |
| 26 |
574590501 |
Carburetor Price: $54.99 |
| 27 |
575630601 |
Assembly - Filter Base (with choke lever) Price: $2.99 |
| 28 |
575531901 |
Screw (2 pack) (9SGEB-05-52) Price: $1.99 |
| 29 |
574590201 |
Filter Price: $1.99 |
| 30 |
575630701 |
Assembly - Filter (with knob) Price: $3.99 |
| 31 |
574859601 |
Kit - Gasket Price: $4.99 |
| 32 |
574859301 |
Kit - Vent Price: $1.99 |
| 33 |
574859401 |
Kit - Fuel Line & Filter Price: $2.99 |
| 34 |
574607701 |
Assembly - Fuel Cap with retainer Price: $1.99 |
| 35 |
575531501 |
Screw (6 pack) (9SKKBY05-18) Price: $1.99 |
