| Ref | Part Number | Description |
|---|
| 0 |
640058A |
CARBURETOR Price: $78.00 |
| 1 |
532437078 |
Price: Call Us |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 1 |
ZNK1L000U |
HEX.DOME NUT M12 Price: $1.88 |
| 2 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 2 |
ZNL1L000U |
HEX LOCKNUT M12 Price: $1.44 |
| 3 |
532138017 |
BRKT ASM SWAY BAR Price: $7.99 |
| 3 |
876064W |
ROLLER MOUNTING W/A Price: $91.66 |
| 4 |
10-11-017 |
GREASE NIPPLE 1/8BSP STR Price: $1.44 |
| 4 |
532165460 |
BRACKET SWAY BAR 42" DECK Price: $6.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 5 |
876099 |
DISC SPRING DIA 25* DIA 12,2*1,5MMTHK Price: $1.40 |
| 6 |
532178024 |
BAR SWAY DECK Price: $5.99 |
| 6 |
63-01-960 |
REAR ROLLER ADJUSTING STUD Price: $28.47 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 7 |
111-9450 |
SHAFT-ADJUSTER, ROLLER This part replaces 876027. Price: $63.35 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
532850857 |
BLADE BOLT Price: $1.99 |
| 8 |
63-02-123 |
REAR ROLLER ADJ SPACER Price: $10.76 |
| 9 |
539990118 |
SLW 3/8 STD This part replaces 810030600. Price: $1.99 |
| 10 |
532140296 |
WASHER.BLADE Price: $2.99 |
| 10 |
632118 |
SHAFT & LEV Price: $5.07 |
| 10 |
876062 |
NUT ROLLER Price: $11.05 |
| 11 |
532134149 |
BLADE.42".MULCH Price: $12.99 |
| 12 |
876006 |
SMOOTH ROLLER (SERVICEABLE) Price: $153.04 |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $17.99 |
| 13 |
876098 |
CAP PRESSURE CONTROL Price: $8.40 |
| 14 |
532128774 |
HSG MANDREL Price: $22.99 |
| 14 |
63-07-072 |
SCRAPER WIRE Price: $17.04 |
| 14 |
631890 |
SHUTTER Price: $1.20 |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 15 |
876013W |
HANDWHEEL Price: $18.57 |
| 16 |
09730 |
PIN SPIROL Price: $1.42 |
| 16 |
532174493 |
STRIPPER.MANDREL.ROUND.BLACK Price: $3.99 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 17 |
876034 |
DISC SPRING Price: $1.65 |
| 18 |
214053 |
DECAL HEIGHT OF CUT Price: $1.63 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 18 |
872140505 |
BOLT This part replaces 532066238. Price: $2.99 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $2.99 |
| 19 |
876082 |
BEARING Price: $5.65 |
| 20 |
532159770 |
BAFFLE.VORTEX Price: $12.99 |
| 20 |
640027 |
FUEL JET Price: $2.60 |
| 20 |
876047 |
TRUNNION Price: $32.01 |
| 20A |
640053 |
CAP Price: $0.81 |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 21 |
876085 |
SLEEVE ADJUSTER Price: $31.75 |
| 22 |
876003 |
SPRING COMPRESSION Price: $2.52 |
| 23 |
532177563 |
BRKT, DEFL. MOWER Price: $2.99 |
| 23 |
876053 |
CAGE BACKLASH Price: $20.69 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 24 |
876054 |
NUT BACKLASH Price: $13.28 |
| 25 |
532123713 |
SPRING TORSION This part replaces 532106734. Price: $3.99 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 25 |
631951 |
FLOAT BOWL Price: $12.35 |
| 25 |
876004 |
SWING BOLT Price: $21.66 |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 26 |
876035 |
BEARING Price: $3.25 |
| 27 |
09599 |
WASHER Price: $1.42 |
| 27 |
532130968 |
SHIELD.DEFLECTOR.MOWER.42".BLK This part replaces 532171859. Price: $22.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
09454 |
NUT M12 PLAIN HEX PLATED Price: $1.36 |
| 28 |
632816 |
FLOAT This part replaces 632802. Price: $5.90 |
| 28 |
819111016 |
WASHER Price: $5.99 |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 29 |
876022 |
PIN PIVOT Price: $8.77 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $1.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 30 |
876009W |
COUNTERWEIGHT Price: $44.64 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $1.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 31 |
ZWQ1J000U |
PLAIN HEAVY WASHER M10 Price: $1.38 |
| 32 |
09480 |
WASHER M10 SC SPRING Price: $1.36 |
| 32 |
27136A |
DRAIN ASSY Price: $5.96 |
| 32 |
532173436 |
PULLEY MANDREL Price: $7.99 |
| 33 |
27554 |
GASKET Price: $1.05 |
| 33 |
532400234 |
NUT.FLANGE.LOCK.TOP This part replaces 532178342. Price: $3.99 |
| 33 |
ZCS1J030U |
SOC.HD.CAP Price: $1.31 |
| 34 |
872110614 |
BOLT Price: $3.99 |
| 34 |
876032 |
O RING Price: $1.65 |
| 35 |
63-07-008 |
CIRCLIP INTERNAL 52DIA Price: $2.55 |
| 36 |
532173438 |
PULLEY.IDLER.FLAT Price: $14.99 |
| 36 |
63-07-036 |
BEARING Price: $9.69 |
| 36 |
640019 |
NOZZLE Price: $4.95 |
| 37 |
63-07-038 |
SEAL DOUB.LIP 30*52*10W Price: $10.87 |
| 37 |
632547 |
O RING Price: $1.49 |
| 37 |
819131316 |
WASHER Price: $2.99 |
| 38 |
876007W |
CASTING BEARING Price: $128.11 |
| 39 |
134-0499 |
REEL-8 IN,8 BLD,LH HELIX This part replaces 111-3416. Price: $421.46 |
| 40 |
640059 |
NUT Price: $3.86 |
| 40 |
873680600 |
LOCKNUT Price: $1.99 |
| 40 |
ZNB1J000U |
M10 BINX SELF LOCKING NUT Price: $1.27 |
| 41 |
63-11-019 |
HEX HD SCREW(DURLOCK) M10X16 Price: $2.47 |
| 44 |
27110A |
GASKET Price: $1.45 |
| 44 |
532140088 |
GUARD MANDREL LH BLACK This part replaces 532134236. Price: $14.99 |
| 44 |
63-13-039 |
DECAL HEIGHT OF CUT ADJ Price: $1.44 |
| 45 |
40-07-017 |
CIRCLIP EXT.25MM DIA Price: $1.40 |
| 45 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 47 |
876019W |
SKID Price: $38.77 |
| 48 |
532133944 |
WASHER Price: $2.99 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 48 |
ZNN1J000U |
HEX.NUT NYLOC M10 Price: $1.42 |
| 49 |
09479 |
WASHER M10 X 21 X 1.45 THK (P) Price: $1.39 |
| 49 |
532174284 |
ROLLER ASM CAM FOLLOWER Price: $6.99 |
| 50 |
532131340 |
BOLT Price: $2.99 |
| 50 |
876033C |
MAINFRAME Price: $562.27 |
| 51 |
09438 |
NUT M6 X 1.5 PLAIN Price: $1.39 |
| 51 |
532069180 |
LOCKNUT Price: $2.99 |
| 52 |
532139888 |
BOLT.SHOULDER.5/16-18 This part replaces 532105529. Price: $2.99 |
| 52 |
ZDH1L016U |
HEX HD.SET SCW.M12*16 Price: $1.35 |
| 53 |
532184907 |
ARM BRAKE ASSY This part replaces 532131845. Price: $11.99 |
| 53 |
876069 |
PIN BEARING ADJUSTER Price: $26.70 |
| 54 |
532178515 |
WASHER This part replaces 532133943. Price: $2.99 |
| 54 |
876052W |
BRACKET GUARD LH Price: $30.28 |
| 55 |
09362 |
SCREW M6 X 16 HEX HD ZINC Price: $1.42 |
| 55 |
532155046 |
ARM IDLER 42" MOWER LT/YT Price: $7.99 |
| 56 |
09738 |
BOLT CARRIAGE Price: $1.42 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $2.99 |
| 57 |
876057W |
BRACKET-GUARD, RH Price: $31.31 |
| 58 |
HY4200 |
WASHER Price: $1.34 |
| 59 |
532141043 |
GUARD, BELT This part replaces 532173442. Price: $3.99 |
| 59 |
ZNB1L000U |
HEX.NUT M12 BINX Price: $1.59 |
| 60 |
ZWP1L000U |
PLAIN WASHER M12 Price: $1.44 |
| 61 |
65-05-120 |
HEAD PIVOT PIN (30/353MM) Price: $32.70 |
| 62 |
876065 |
BUSH Price: $8.47 |
| 63 |
09491 |
WASHER M16 PLAIN Price: $1.42 |
| 64 |
922500 |
BUSHING Price: $10.19 |
| 65 |
876060W |
BOTTOM BLADE ASSY Price: $280.94 |
| 66 |
922115W |
CASTING-PIVOT, FIXED Price: $121.27 |
| 67 |
532106932 |
KNOB T (3/8 HOLE) Price: $2.99 |
| 67 |
ZDH1P050U |
SETSCREW M16*50 Price: $1.35 |
| 68 |
09598 |
SETSCREW HEX.HD. Price: $1.44 |
| 68 |
532144959 |
BELT V SECONDARY Price: $32.99 |
| 69 |
HY09485 |
WASHER M12 PLAIN Price: $1.40 |
| 70 |
40-13-010 |
DECAL - C/HEAD MIND TOES&FING Price: $1.44 |
| 71 |
340154 |
BUSHING Price: $4.85 |
| 91 |
532180532 |
BRACKET ASM NOSEROLLER LH Price: $2.99 |
| 94 |
539132264 |
MANUAL, OPERATOR Price: $3.20 |
| 95 |
532180533 |
BRACKET ASM NOSEROLLER RH Price: $3.99 |
| 101 |
532136420 |
COVER MULCH 42" Price: $14.99 |
| 102 |
871081010 |
SCREW Price: $3.99 |
| 103 |
819061216 |
WASHER Price: $2.99 |
| 104 |
810071000 |
LOCKWASHER This part replaces 532001863. Price: $2.99 |
| 105 |
532160793 |
LATCH ASSY Price: $7.99 |
| 106 |
532002029 |
NUT.WELD.#10-24 (2 2) This part replaces 532125004. Price: $2.99 |
| 111 |
532183074 |
Price: Call Us |
| 112 |
532183075 |
Price: Call Us |
| 113 |
817060510 |
Price: $2.99 |
| 114 |
873310500 |
NUT Price: $3.99 |
| 115 |
872110505 |
BOLT Price: $3.99 |
| 116 |
532004898 |
BOLT This part replaces 532124842. Price: $1.99 |
| 117 |
532165746 |
WHEEL.GAUGE.STANDARD Price: $11.99 |
| 118 |
873680600 |
LOCKNUT This part replaces 532005394. Price: $1.99 |
| 119 |
734117201 |
WASHER This part replaces 819121414. Price: $1.99 |
| 132 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $2.99 |
| 142 |
532165890 |
ARM SPRING BRAKE MOWER Price: $2.99 |
| 143 |
532157109 |
BRACKET, ARM IDLER Price: $3.99 |
| 144 |
532173441 |
KEEPER BELT 42" CLUTCH Price: $5.99 |
| 145 |
532173437 |
PULLEY.IDLER.FLAT.PLATED Price: $14.99 |
| 146 |
532173443 |
BOLT CARRIAGE IDLER Price: $3.99 |
| 147 |
532179748 |
SPRING This part replaces 532131335. Price: $1.99 |
| 148 |
532169022 |
IDLER RETURN SPRING Price: $2.99 |
| 149 |
532165898 |
SPRING.RETAINER.YELLOW.ZINC Price: $3.99 |
| 150 |
531003379 |
WASHER This part replaces 819091216. Price: $2.99 |
| 151 |
532169670 |
BRACKET.CLUTCH.CABLE Price: $14.99 |
| 152 |
532175067 |
KIT.CLUTCH.CABLE This part replaces 532169676. Price: $29.99 |
| 153 |
819131612 |
Washer 13/32 X 1 X 12 Ga (AYP part number) This part replaces 532169674. Price: $3.99 |
| 154 |
532169675 |
SPRING RETAINER Price: $3.99 |
| 155 |
532169671 |
SPRING RETENTION LEVER Price: $2.99 |
| 156 |
532169672 |
SPACER CLUTCH CABLE Price: $3.99 |
| 157 |
532169669 |
ROD CLUTCH CABLE 3/8" Price: $27.99 |
| 158 |
817240408 |
SCREW Price: $3.99 |
| 159 |
872140614 |
BOLT Price: $2.99 |
| 182 |
532179126 |
ROD ROLLER NOSE STANDARD Price: $6.99 |
| 183 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $1.99 |
