| Ref | Part Number | Description |
|---|
| 2 |
04017-05 |
Screw, Hex Serrated Flange 1/4-20 x 3/4" Price: Call Us |
| 5 |
04110-01 |
U-Nut, 1/4-20 Price: Call Us |
| 6 |
484565 |
Hourmeter, Inductive This part replaces 483537. Price: Call Us |
| 9 |
04002-18 |
Bolt, M10-1.50 x 25mm Grade 8.8 Price: Call Us |
| 10 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 11 |
04001-21 |
Bolt, Hex Head 3/8-16 x 1-3/4" Price: Call Us |
| 12 |
04021-09 |
Nut, Hex Elastic Stop 3/8-16 Price: Call Us |
| 13 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 14 |
451454 |
Plate, Engine Mounting Price: Call Us |
| 15 |
04003-12 |
Bolt, Carriage 5/16-18 x 3/4" Price: Call Us |
| 16 |
04019-03 |
Nut, Hex Serrated Flange 5/16-18 Price: Call Us |
| 17 |
424691 |
Rear Cover Price: Call Us |
| 18 |
04040-05 |
Flatwasher, 3/8 - .406 x .812 x .065 Price: Call Us |
| 19 |
424634 |
Lock, Hood Latch Price: Call Us |
| 20 |
483507 |
Spring, Hood Latch Price: Call Us |
| 21 |
424633 |
Latch, Hood Price: Call Us |
| 22 |
04009-07 |
Bolt, Shoulder 5/16-18 x 1/2" Price: Call Us |
