| Ref | Part Number | Description |
|---|
| 0 |
640290 |
CARBURETOR This part replaces 640263. Price: $78.65 |
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
631255 |
SHAFT & LEV Price: $6.36 |
| 2 |
530016153 |
Screw Price: $1.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 2 |
94-2703 |
PLUG Price: $1.86 |
| 3 |
112-6967 |
O-RING Price: $2.70 |
| 3 |
530059006 |
Reflector-Tape Price: $1.99 |
| 4 |
106-5363 |
SHAFT-ADJUSTER Price: $41.05 |
| 4 |
530039238 |
Module - Ignition Price: $29.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
530016432 |
Screw Price: $1.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
114-9396 |
CAPSCREW-HH Price: $2.22 |
| 6 |
530047442 |
Strap-Ground Price: $1.99 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 7 |
530057943 |
Assy-Wire Harness Price: $5.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 7 |
99-2097 |
DETENT Price: $12.71 |
| 8 |
119-4164 |
WASHER-WAVE This part replaces 106-5335. Price: $2.73 |
| 8 |
530058687 |
Cover-Air Filter Price: $4.99 |
| 9 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 9 |
530057925 |
Filter-Air Price: $0.99 |
| 10 |
137-6132 |
SCREW-ADJUSTER, BEDBAR This part replaces 99-2096. Price: $32.54 |
| 10 |
530016425 |
Screw Price: $1.99 |
| 10 |
631605 |
SHAFT & LEV Price: $7.84 |
| 11 |
530057892 |
Housing-Air Filter Price: $4.99 |
| 11 |
99-2098 |
WASHER Price: $7.01 |
| 12 |
119-4156 |
SPRING-COMPRESSION This part replaces 99-3755. Price: $0.91 |
| 12 |
545070601 |
Carburetor Zama W-26 This part replaces 530035590. Price: $27.99 |
| 13 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 13 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 14 |
31837 |
SHUTTER Price: $1.18 |
| 14 |
530047721 |
Bulb-Purge "snap-in" Price: $3.99 |
| 15 |
107-3273-01 |
BEDBAR Price: $303.02 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
119-4151 |
SCREW-BEDKNIFE This part replaces 57-4910. Price: $0.41 |
| 16 |
530071894 |
Gasket-cyl. o-ring (kit) Price: $6.99 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 17 |
137-6094 |
BEDKNIFE-EDGEMAX (RM 22IN) This part replaces 108-9095. Price: $166.88 |
| 17 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 19 |
631201 |
CHECK VALVE Price: $15.40 |
| 20 |
631562 |
ADJ SCREW Price: $3.74 |
| 21 |
530057942 |
Backplate-Muffler Price: $5.99 |
| 21 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 21 |
630738 |
SPRING Price: $1.25 |
| 22 |
530071894 |
Gasket-Muffler (kit) Price: $6.99 |
| 22 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
545006056 |
Kit-Spark Arrestor Price: $6.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 23 |
69-8980 |
WASHER Price: $0.58 |
| 24 |
106-9623 |
BOLT-BEDBAR Price: $18.27 |
| 24 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 25 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 25 |
545015301 |
Insert-Left (black) Cyl. This part replaces 530057885. Price: $2.99 |
| 26 |
323-12 |
SCREW-HH Price: $1.14 |
| 26 |
545112901 |
Assy-Crankshaft/Rod This part replaces 530012537. Price: $49.99 |
| 27 |
108-4269-01 |
WEIGHT Price: $146.07 |
| 27 |
530016417 |
Bolt Price: $1.99 |
| 28 |
107-2954 |
NUT-ADJUSTER, BEARING Price: $17.63 |
| 28 |
530057941 |
Cap-Crankcase Price: $5.99 |
| 29 |
530056363 |
Assy-Bearing/Seal Price: $11.99 |
| 29 |
93-2489 |
BEARING Price: $24.37 |
| 30 |
107-4028 |
SEAL-GREASE Price: $21.51 |
| 31 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 32 |
137-8432 |
REEL+,7IN FWY(22)8 BLD This part replaces 108-9073. Price: $671.21 |
| 32 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 33 |
545015401 |
Insert-Right (gray) Cyl. This part replaces 530057886. Price: $2.99 |
| 34 |
530071894 |
Seal-Adaptor (kit) Price: $6.99 |
| 35 |
530016426 |
Screw Price: $1.99 |
| 36 |
530071894 |
Gasket-Carb. (kit) Price: $6.99 |
| 37 |
530057926 |
Tube-Intake Price: $1.99 |
| 38 |
530057909 |
Wire-Throttle Price: $1.99 |
| 39 |
530016101 |
Nut-Carb. Price: $1.99 |
| 40 |
640223 |
RESTRICTOR Price: $3.86 |
| 40A |
640053 |
CAP Price: $0.81 |
| 41 |
530031163 |
Bar Wrench This part replaces 530031135. Price: $4.99 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
632554 |
WELCH PLUG Price: $1.17 |
| 50 |
630978 |
DIAPHRAGM Price: $4.49 |
| 51 |
630750A |
GASKET Price: $3.00 |
| 52 |
631653 |
COVER Price: $7.61 |
| 53 |
650545 |
SCREW Price: $1.20 |
| 55 |
630932A |
INLET NEEDLE Price: $4.39 |
| 56 |
630742 |
GASKET Price: $1.25 |
| 57 |
631049 |
SPRING Price: $1.20 |
