| Ref | Part Number | Description |
|---|
| 10 |
112-7018 |
VALVE-INLET This part replaces 98-9494. Price: $41.87 |
| 20 |
112-7019 |
VALVE-EXHAUST This part replaces 98-9625. Price: $56.65 |
| 30 |
98-9626 |
SPRING-VALVE Price: $10.57 |
| 40 |
107-9092 |
RETAINER-SPRING Price: $2.58 |
| 41 |
951-12066 |
Connecting Rod Assembly This part replaces 751-12066. Price: $65.06 |
| 42 |
951-12043 |
Piston This part replaces 751-12043. Price: $31.70 |
| 43 |
951-11632 |
PISTON PIN SNAP RING Price: $3.53 |
| 44 |
951-12044 |
PISTON PIN Not Available This part replaces 751-12044. Price: |
| 45 |
951-12067 |
PISTON RING KIT Not Available This part replaces 751-12067. Price: |
| 49 |
951-12068 |
Governor Gear This part replaces 751-12068. Price: $18.08 |
| 50 |
117-7572 |
COLLET-SPRING, VALVE This part replaces 98-9390. Price: $9.43 |
| 50 |
951-12069 |
BEARING Not Available This part replaces 751-12069. Price: |
| 51 |
736-04453 |
Washer 8×20×0.8 Price: $5.34 |
| 52 |
714-04077 |
Cotter Pin Price: $5.30 |
| 53 |
951-11958 |
Governor Seal This part replaces 751-12070. Price: $3.56 |
| 54 |
951-12071 |
GOVERNOR ARM SHAFT Not Available This part replaces 751-12071. Price: |
| 56 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 57 |
715-04102 |
Dowel Pin 9×12 Price: $4.93 |
| 58 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04092. Price: $3.66 |
| 59 |
951-12072A |
Camshaft This part replaces 751-12072. Price: $85.04 |
| 60 |
951-11374 |
Crankcase Cover Gasket Price: $13.94 |
| 60 |
99-8385 |
SEAL-STEM, VALVE Price: $7.29 |
| 61 |
736-04545 |
WASHER Not Available Price: |
| 62 |
951-11577 |
O-RING 15.8 x 2.5 Price: $3.53 |
| 63 |
951-11283 |
Oil Fill Plug Asm This part replaces 951-11377. Price: $6.11 |
| 65 |
951-11372 |
Oil Seal,30×46×8 Price: $13.54 |
| 66 |
710-06061 |
BOLT M8×38 This part replaces 710-04971. Price: $5.67 |
| 67 |
710-06062 |
SCREW M8-1.25 x 45 GR10.9 Not Available This part replaces 710-04972. Price: |
| 68 |
710-06063 |
BOLT M8×35 This part replaces 710-05052. Price: $5.45 |
| 69 |
710-04968 |
Bolt M6×16 Price: $5.77 |
| 70 |
951-11320 |
OIL TUBE SUPPORT BRACKET Not Available Price: |
| 70 |
98-9497 |
CAP-VALVE Price: $8.36 |
| 71 |
710-04966 |
Bolt M6×8 Price: $5.30 |
| 73 |
951-11381 |
Oil Fill Tube O-Ring This part replaces 951-11903. Price: $4.59 |
| 74 |
951-12073 |
Oil Fill Tube Assembly This part replaces 751-12073. Price: $10.19 |
| 75 |
951-11904 |
Dipstick O-Ring This part replaces 951-11934. Price: $3.69 |
| 76 |
951-11971A |
Disptick Assembly This part replaces 751-12074. Price: $27.49 |
| 78 |
951-11350A |
OIL DRAIN PIPE This part replaces 951-11350. Price: $7.05 |
| 79 |
736-04440A |
FLAT WASHER This part replaces 736-04440. Price: $6.01 |
| 80 |
105-3790 |
R-ARM SHAFT ASM Price: $28.61 |
| 80 |
710-04906 |
Oil Drain Plug Price: $5.86 |
| 81 |
951-11498 |
Oil Seal 30×46×8 Price: $12.49 |
| 90 |
100-1762 |
BOLT This part replaces 100-9265. Price: $1.68 |
| 100 |
98-9505 |
BRACKET-ARM, ROCKER Price: $22.17 |
| 110 |
105-3758 |
PIN-SPRING Price: $0.57 |
| 120 |
98-9507 |
WASHER-SHAFT, ROCKER ARM Price: $0.85 |
| 126 |
951-11180 |
CYLINDER BAFFLE Not Available Price: |
| 127 |
710-04915 |
Bolt M6×12 Price: $3.82 |
| 130 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 140 |
98-9504 |
SPRING-ARM, ROCKER Price: $0.66 |
| 144 |
951-11283 |
Oil Fill Plug Asm This part replaces 951-11377. Price: $6.11 |
| 145 |
951-10641 |
Oil Drain Assembly Price: $11.36 |
| 160 |
98-9501 |
ROCKER ARM ASM Price: $28.78 |
| 170 |
98-9502 |
SCREW-ADJUSTING Price: $2.78 |
| 180 |
98-9503 |
NUT Price: $1.33 |
| 190 |
98-9506 |
STUD Price: $5.98 |
| 200 |
98-9393 |
NUT Price: $2.72 |
