| Ref | Part Number | Description |
|---|
| 1 |
GW-9362 |
PIN - spring, 1/8" dia., retains castle nut to threaded stud Price: $3.82 |
| 2 |
GW-9838 |
HEX NUT 1/2-20 Not Available Price: |
| 3 |
GW-9934 |
WASHER- shoulder, 1/2" (shoulder faces disc washers) Price: $13.73 |
| 4 |
GW-9932 |
WASHER- disc spring (concave surfaces face each other) Price: $21.54 |
| 7 |
GW-9317 |
PIN - cotter, 3/32" x 1" Price: $3.22 |
| 8 |
GW-1231 |
ROD - connecting rod, wheel speed shift lever Price: $14.83 |
| 9 |
GW-1033 |
SWIVEL - connecting rod Price: $13.56 |
| 10 |
736-0567 |
NYLON FLAT WASHER Not Available Price: |
| 11 |
714-04048 |
PIN - hair cotter Price: $7.04 |
| 12 |
N/A |
LOCKNUT-hex. hd., 5/16"-18, retains swivel to eccentric lever |
| 13 |
710-0514 |
BOLT - hex. hd., 3/8"-16 x 1" Price: $3.78 |
| 14 |
736-0169 |
L-Wash. 3/8" I.D." This part replaces 936-0169. Price: $3.33 |
| 15 |
736-3050 |
WASHER - flat, 3/8", S.A.E. Price: $3.90 |
| 16 |
GW-2146 |
BUSHING - spacer, 21/64" (.325") long, yoke to engine mount Not Available Price: |
| 17 |
GW-1113-1099 |
BUSHING - spacer, 19/64" (.300") long, yoke link to retaining plug Price: $4.53 |
| 18 |
GW-9120 |
RING - retaining (tolerance ring) Price: $5.94 |
| 20 |
GW-2100 |
ROD - belt adjustment, 7" long, with measuring gauge Price: $11.28 |
| 21 |
710-0539 |
Screw, 3/8-24 x 1.75 This part replaces 1100012. Price: $3.95 |
| 23 |
756-04171 |
DISC ONLY-reverse, rubber rimmed Price: $58.85 |
| 24 |
GW-9245 |
BELT -forward drive Price: $21.83 |
| 25 |
619-04124 |
PULLEY- engine P.T.O. (Power Take Off) Price: $135.20 |
| 26 |
736-04187 |
SHIM - engine pulley, 1/16" thick Price: $4.36 |
| 26 |
736-04192 |
SHIM - same as above, 1/32" thick Price: $5.94 |
| 27 |
GW-9303 |
KEY - engine pulley, 3/16" square x 2-1/2" Price: $3.22 |
