| Ref | Part Number | Description |
|---|
| 1 |
596623501 |
Zerks This part replaces 539101474. Price: $2.99 |
| 1 |
76-9780 |
DISCONTINUED Price: Call Us |
| 2 |
596671501 |
Washers This part replaces 539101949. Price: $2.99 |
| 2 |
84-1450 |
PANEL-GAUGES, CONSOLE Price: $78.90 |
| 3 |
218-446 |
NUT-HEX Price: $6.09 |
| 3 |
539106791 |
HEX BOLT 3/8 X 1" Price: $2.99 |
| 4 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 4 |
539110071 |
TORSION SPRING, DECK LIFT Price: $6.99 |
| 5 |
539110160 |
SPRING, DECK ROD RIGHT Price: $5.99 |
| 5 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 6 |
3254-20 |
WASHER-LOCK, INT Price: $1.29 |
| 6 |
539110161 |
SPRING, DECK ROD LEFT Price: $8.99 |
| 7 |
3218-19 |
NUT-HJ Price: $0.54 |
| 7 |
539110205 |
DECK LIFT ASM PAINTED Price: $349.99 |
| 8 |
539100032 |
BUSHING, FLANGED NYLON Price: $5.99 |
| 8 |
66-2960 |
WARNING LAMP CLUSTER Price: $210.90 |
| 9 |
539110292 |
FOOT PEDAL Price: $17.99 |
| 9 |
76-9060 |
GAUGE-TEMPERATURE Price: $110.89 |
| 10 |
539110308 |
FOOT PAD, NON-SLIP Price: $3.99 |
| 10 |
66-2940 |
GAUGE-FUEL Price: $178.34 |
| 11 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 11 |
539110275 |
FOOT LEVER WELDED This part replaces 539110266. Price: $54.99 |
| 12 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 12 |
539110287 |
CASTER CASTING, RIGHT, PAINTED Price: $119.99 |
| 13 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 13 |
539110288 |
CASTER CASTING LEFT, PAINTED Price: $84.99 |
| 14 |
539110295 |
SPRING, PEDAL, LIFT Price: $4.99 |
| 14 |
69-4780 |
CLAMP-GAUGE Price: $73.28 |
| 15 |
32144-19 |
SCREW-SHWH Price: $0.89 |
| 15 |
539110306 |
DECK LIFT ROD Price: $7.99 |
| 16 |
32105-12 |
SCREW Price: $2.19 |
| 16 |
596739901 |
Yoke This part replaces 539977465. Price: $27.99 |
| 17 |
138-1911 |
PTO SWITCH KIT This part replaces 85-4980. Price: $320.00 |
| 17 |
539990155 |
NUT 3/8F Price: $2.99 |
| 18 |
32128-33 |
NUT-HF Price: $0.25 |
| 18 |
539113239 |
CONNECTOR, DECK LIFT Price: $14.99 |
| 19 |
3274-31 |
SCREW-HSBH This part replaces 3274-68. Price: $0.89 |
| 19 |
539113931 |
HEIGHT PLATE, DECK Price: $24.99 |
| 20 |
27-2360 |
SWITCH Price: $46.56 |
| 20 |
539916459 |
RETAINER Price: $3.99 |
| 21 |
539977703 |
CLEVIS PIN 3/8 X 1 1/8 Price: $4.99 |
| 21 |
82-3750-03 |
COVER-CONSOLE This part replaces 82-3750. Price: $183.31 |
| 22 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 22 |
77-3620 |
KNOB-RETAINER Price: $15.13 |
| 23 |
3256-3 |
WASHER-FLAT Price: $0.49 |
