| Ref | Part Number | Description |
|---|
| 1 |
21-0230 |
PULLEY-PTO Price: $409.71 |
| 1 |
532189482 |
THROTTLE.CONTROL.RT.INTEK.50 Price: $19.99 |
| 2 |
43-5630 |
YOKE-PTO Price: $80.75 |
| 2 |
532165787 |
GRIP.HANDLE.BLACK This part replaces 532427643. Price: $5.99 |
| 3 |
3219-3 |
NUT-HEX Price: $0.34 |
| 4 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 5 |
3256-41 |
WASHER Price: $1.18 |
| 6 |
43-5540 |
SHAFT-PTO Price: $846.33 |
| 6 |
532446067 |
CONSOLE.GREY.DRT.W.SLOT.DRT900 Price: $29.99 |
| 9 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 10 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 10 |
532008206 |
GRIP T This part replaces 532124797. Price: $9.99 |
| 11 |
100-6599 |
PTO PIVOT ASM Price: $780.32 |
| 11 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 12 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 12 |
532081328 |
SHOULDER BOLT ST Price: $4.99 |
| 13 |
3254-7 |
WASHER-LOCK, INT Price: $4.82 |
| 13 |
532187497 |
HANDLE.SHIFT.TILLER Price: $6.99 |
| 14 |
3219-7 |
NUT-HEX Price: $1.53 |
| 14 |
532109313 |
GROMMET.RUBBER.CRT.TILLER Price: $3.99 |
| 15 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 15 |
532109337 |
SHIFT ROD CRT Price: $32.99 |
| 16 |
596728201 |
Bolts This part replaces 872110608. Price: $3.99 |
| 16 |
92-4058-01 |
ARM PTO This part replaces 92-4058. Price: $136.94 |
| 17 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 17 |
532109229 |
LOCK.HANDLE.CRT Price: $5.99 |
| 18 |
43-5550 |
SHAFT-ACTUATOR, PTO Price: $143.65 |
| 18 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 19 |
43-5570-01 |
ARM-ACTUATOR This part replaces 43-5570. Price: $164.96 |
| 19 |
596140201 |
Washers This part replaces 819131611. Price: $2.99 |
| 20 |
251-252 |
BEARING Price: $98.35 |
| 20 |
532109228 |
LEVER.LOCK.CRT Price: $11.99 |
| 21 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 21 |
532446156 |
HANDLE.ASM.HUSQ/P.PRO.GREY Price: $84.99 |
| 22 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 31 |
532150696 |
BOLT.PIVOT Price: $4.99 |
| 42 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 45 |
596434001 |
Screws This part replaces 532421756. Price: $2.99 |
| 100 |
532193133 |
CONTROL.ASSEMBLY.TINE.TILLER Price: $24.99 |
| 101 |
532188555 |
PIN, PIVOT Price: $3.99 |
