| Ref | Part Number | Description |
|---|
| 2 |
123583X |
Key Square Price: Call Us |
| 010 |
98-9620 |
OVERFLOW PIPE ASM Price: $44.29 |
| 15 |
19131316 |
Washer 13/32 x 13/16 x 16 Ga. Price: Call Us |
| 17 |
197296 |
Spring, Brake Price: Call Us |
| 020 |
98-9431 |
SCREW-BLEEDER, AIR Price: $15.04 |
| 22 |
197660 |
Rod Shift Price: Call Us |
| 23 |
409154X421 |
Knob Price: Call Us |
| 29 |
408391 |
Rod, Brake Price: Call Us |
| 030 |
98-7654 |
GASKET Price: $8.84 |
| 33 |
12000001 |
Ring E Price: Call Us |
| 035 |
98-9468 |
NOZZLE HOLDER ASM This part replaces 105-3740. Price: $341.86 |
| 35 |
197722 |
Rod, Brake, Park Price: Call Us |
| 37 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 040 |
98-9468 |
NOZZLE HOLDER ASM Price: $341.86 |
| 42 |
8883R |
Cover, Foot Pedal Price: Call Us |
| 49 |
72110614 |
Bolt Price: Call Us |
| 050 |
98-7676 |
GASKET Price: $2.73 |
| 50 |
194327 |
Pulley Idler Flat Price: Call Us |
| 51 |
73900600 |
Lock Nut 3/8-16 Price: Call Us |
| 52 |
194326 |
Idler V-Groove 910" Offset Price: Call Us |
| 56 |
125907X |
V-Belt, Drive Price: Call Us |
| 060 |
98-7677 |
SEAL-HEAT Price: $10.17 |
| 64 |
196200 |
Shaft Asm. Pedal Brake Control Price: Call Us |
| 70 |
193220X428 |
Console Price: Call Us |
| 73 |
74490544 |
Bolt Hex 5/16-18 Gr. 5 Price: Call Us |
| 74 |
142432 |
Screw 1/4 x 1/2 Price: Call Us |
| 080 |
98-9653 |
PIPE-INJECTION Price: $69.17 |
| 80 |
408393 |
Strap Torque Price: Call Us |
| 090 |
98-9654 |
PIPE-INJECTION Price: $76.86 |
| 99 |
408418 |
Rod Spring Bypass Price: Call Us |
| 100 |
98-9655 |
PIPE-INJECTION Price: $82.26 |
| 110 |
98-7682 |
CLAMP-PIPE Price: $6.37 |
| 114 |
73800500 |
Nut Lock 5/16-18 UNC Price: Call Us |
| 116 |
73900500 |
Nut Lock Hex Flange 5/16-18 Price: Call Us |
| 120 |
98-7683 |
CLAMP-PIPE Price: $3.66 |
| 121 |
175611 |
Bracket Strap Torque Price: Call Us |
| 122 |
72010520 |
Bolt 5/16-18 x 2.50 Price: Call Us |
| 125 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 130 |
98-7684 |
SCREW (W/WASHER) Price: $0.44 |
| 140 |
98-9623 |
PLUG-GLOW This part replaces 98-9695. Price: $93.76 |
| 150 |
98-9631 |
CORD-PLUG, GLOW Price: $12.41 |
| 153 |
4497H |
Retainer Spring 1" Price: Call Us |
| 159 |
76020412 |
Pin Cotter 1/8 x 3/4 Price: Call Us |
| 160 |
169484 |
Retainer Clip Price: Call Us |
| 160 |
99-8377 |
NUT-FLANGE Price: $2.56 |
| 161 |
195403 |
Spring, Return, Clutch Price: Call Us |
| 162 |
408784 |
Adapter Transaxle Price: Call Us |
| 165 |
196212 |
Bushing Price: Call Us |
| 166 |
197290 |
Nut Push .625 Price: Call Us |
| 167 |
405257 |
Latch Brake Parking Price: Call Us |
| 170 |
194322 |
Keeper Belt Centerspan Price: Call Us |
| 171 |
72110622 |
Bolt Price: Call Us |
| 174 |
197289 |
Nut Push Price: Call Us |
| 175 |
408539 |
Shaft Asm Shift Price: Call Us |
| 176 |
196214 |
Arm Clevis Rod Shift Price: Call Us |
| 178 |
197456 |
Spring Shift Price: Call Us |
| 180 |
98-9420 |
OVERFLOW PIPE ASM Price: $3.91 |
| 183 |
156972 |
Spacer Axle Price: Call Us |
| 184 |
198403X505 |
Handle Parking Brake Price: Call Us |
| 185 |
72110620 |
Bolt Price: Call Us |
| 186 |
194321 |
Spacer Retainer Price: Call Us |
| 187 |
19133210 |
Washer Price: Call Us |
| 188 |
194323 |
Link Clutch Ground Drive Price: Call Us |
| 189 |
194317 |
Bellcrank Ground Drive Price: Call Us |
| 190 |
194318 |
Keeper Bellcrank Ground Drive Price: Call Us |
| 205 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 226 |
74780716 |
Bolt 7/16-14 x 1 Gr 5 Price: Call Us |
| 227 |
405296 |
Washer Serrated Price: Call Us |
| 231 |
407287 |
Idler V-Groove 1.688" Offset Price: Call Us |
