| Ref | Part Number | Description |
|---|
| 1 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 2 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 3 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 4 |
110-3257 |
HOSE-FUEL This part replaces 63-7630. Price: $17.26 |
| 5 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 6 |
2412-147 |
CLAMP-R Price: $2.51 |
| 7 |
32128-20 |
NUT-HF Price: $0.99 |
| 8 |
115-5304 |
CAP-FUEL This part replaces 93-3101. Price: $26.87 |
| 9 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 9 |
596501502 |
Keepers This part replaces 584908001. Price: $9.99 |
| 10 |
353-536 |
DISCONTINUED Price: Call Us |
| 11 |
42-6080 |
SHIM-AXLE Price: $29.45 |
| 12 |
3256-67 |
WASHER Price: $0.49 |
| 12 |
586478501 |
ENGINE.PULLEY Price: $27.99 |
| 13 |
237-136 |
GROMMET Price: $3.52 |
| 14 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 15 |
321-5 |
SCREW-HH Price: $0.22 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA Price: $44.99 |
| 16 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 17 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 18 |
231-101 |
TIRE (23X8.5-12) 4-PLY TURF SAVER Price: $147.85 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 19 |
217-117 |
WHEEL Price: $164.56 |
| 20 |
23-7270 |
NUT-LUG Price: $10.37 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 21 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 25 |
92-9788 |
PIVOT PIN ASM Price: $32.55 |
| 26 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 27 |
324-5 |
SCREW-HH Price: $0.54 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
92-9786-03 |
CARRIER BRACKET This part replaces 92-9786. Price: $106.42 |
| 32 |
3219-6 |
NUT-HEX Price: $2.78 |
| 33 |
3272-17 |
PIN-COTTER Price: $1.79 |
| 34 |
86-9640-03 |
FRONT AXLE ASM This part replaces 86-9640. Price: $2,641.21 |
| 35 |
3273-38 |
SCREW-HSH Price: $6.65 |
| 36 |
66-3060 |
DISCONTINUED Price: Call Us |
| 37 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
62-7650 |
GASKET Price: $4.28 |
| 39 |
92-8874 |
TANK - FUEL (GAS) Price: $485.33 |
| 40 |
46-6560 |
BUSHING Price: $2.94 |
| 41 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 42 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
32121-49 |
PIN-ROLL Price: $2.37 |
| 44 |
32121-71 |
PIN-SPRING Price: $0.61 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 94 |
581880901 |
EXHAUST.TUBE.B&S.28/31 This part replaces 581099201. Price: $19.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
