| Ref | Part Number | Description |
|---|
| 1 |
598602801 |
Decks This part replaces 532402999. Price: $349.99 |
| 1 |
98-3726 |
PLATE - VALVE Price: $515.25 |
| 3 |
93-6372 |
RING-QUAD This part replaces 94-3036. Price: $5.92 |
| 4 |
94-3037 |
RING-RETAINING Price: $1.78 |
| 5 |
94-3038 |
ACTUATOR-DUMP VALVE Price: $159.36 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
94-9999 |
VALVE-RELIEF Price: $768.40 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 8 |
98-3727 |
BACKPLATE ASM Price: $1,881.67 |
| 9 |
94-3035 |
DISCONTINUED Price: Call Us |
| 10 |
94-3023 |
COUPLER Price: $196.98 |
| 12 |
94-3017 |
CHARGE ADAPTER ASM Price: $1,110.47 |
| 13 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 14 |
60-6220 |
SCREW-HH This part replaces 94-3028. Price: $5.33 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
94-3029 |
DISCONTINUED Price: Call Us |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $29.99 |
| 28 |
3217-5 |
NUT-HEX Price: $0.25 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 29 |
94-3031 |
ARM-CONTROL Price: $32.40 |
| 30 |
3274-59 |
SCREW-HSH Price: $1.15 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 31 |
94-3040 |
ORIFICE Price: $37.14 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 33 |
94-3032 |
FOLLOWER-PISTON Price: $574.71 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 35 |
94-3021 |
ROTATING KIT ASM Price: $2,396.18 |
| 36 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 36 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 41 |
94-3025 |
SERVO PISTON ASM Price: $392.53 |
| 43 |
105-9853 |
PLATE-COVER This part replaces 94-3034. Price: $142.29 |
| 44 |
3256-77 |
WASHER-FLAT Price: $1.60 |
| 45 |
3274-81 |
SCREW-HSH Price: $0.74 |
| 46 |
3220-3 |
NUT-HJ Price: $0.28 |
| 47 |
94-3030 |
WASHER Price: $6.24 |
| 48 |
94-3027 |
WASHER-SEAL Price: $32.38 |
| 50 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 51 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 52 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 53 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 54 |
105-3331 |
SEAL-SHAFT This part replaces 94-3008. Price: $35.63 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 55 |
76-7010 |
RING-RETAINING Price: $3.66 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 56 |
94-3020 |
SHAFT-DRIVE Price: $627.17 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 58 |
94-3018 |
DISCONTINUED Price: Call Us |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 59 |
94-3033 |
PLATE-COVER Price: $121.09 |
| 62 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 65 |
93-6306 |
CONTROL ASM This part replaces 94-3019. Price: $1,822.55 |
| 66 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 68 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 190 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 196 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
