| Ref | Part Number | Description |
|---|
| 1 |
115-3434 |
SPINDLE Price: $164.39 |
| 1 |
532136973 |
WIRE.INNER.HANDLE.LIFT.LEVER Price: $12.99 |
| 2 |
100-5703 |
SPACER AND BEARING ASM Price: $87.23 |
| 2 |
532145117 |
SHAFT ARM LIFT RH Price: $74.99 |
| 3 |
136-3339 |
SPINDLE SHAFT ASM This part replaces 100-5705. Price: $233.69 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 4 |
253-154 |
SEAL-OIL Price: $5.48 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
100-5709 |
NUT-SPINDLE, SPECIAL Price: $57.43 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
302-62 |
FITTING-GREASE Price: $1.34 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 10 |
532122512 |
SPRING, COMP T Price: $7.99 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $22.99 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $22.99 |
| 15 |
532127218 |
FRONT LINK Price: $14.99 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
532175689 |
TRUNNION This part replaces 532130171. Price: $3.99 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 21 |
819151216 |
Washer 15/32 x 3/4 x 16 Gauge Price: $2.45 |
| 22 |
812000037 |
Ring, Klip #T5304-37 Price: $4.99 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
596917601 |
Pins This part replaces 876020308. Price: $1.99 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
532110810 |
TRUNION LT Price: $17.99 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT This part replaces 532140302. Price: $5.99 |
| 32 |
873810600 |
LOCK NUT Price: $3.99 |
| 33 |
532140168 |
BRACKET Price: $2.90 |
| 34 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 35 |
532120529 |
WASHER T Price: $2.99 |
| 36 |
532123933 |
HEIGHT INDICATOR PNTR This part replaces 532138346. Price: $3.99 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532123934 |
HEIGHT INDICATOR Price: $2.99 |
