| Ref | Part Number | Description |
|---|
| 1 |
3220-3 |
NUT-HJ Price: $0.28 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532190120. Price: $149.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
93-6337 |
SCREW Price: $9.77 |
| 3 |
99-8701 |
ROTATING KIT Price: $1,722.95 |
| 4 |
105-2856 |
PISTON-SERVO Price: $739.56 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
94-3032 |
FOLLOWER-PISTON Price: $574.71 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
94-3033 |
PLATE-COVER Price: $121.09 |
| 7 |
105-9853 |
PLATE-COVER Price: $142.29 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $17.99 |
| 10 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 11 |
105-2858 |
VALVE-RELIEF Price: $1,100.81 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $8.99 |
| 13 |
323-15 |
SCREW-HH Price: $1.53 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
323-16 |
SCREW-HH Price: $2.89 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 15 |
93-6324 |
SCREW Price: $8.89 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 16 |
99-8704 |
PLATE-VALVE Price: $457.47 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
105-2904 |
BACKPLATE Price: $1,515.44 |
| 19 |
93-6344 |
DRIVESHAFT Price: $967.93 |
| 20 |
3217-5 |
NUT-HEX Price: $0.25 |
| 21 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 22 |
60-6240 |
WASHER Price: $15.20 |
| 23 |
93-6375 |
KEY Price: $18.32 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 24 |
95-2110 |
ADAPTOR Price: $1,026.64 |
| 25 |
105-2862 |
ARM-CONTROL Price: $36.88 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
115-4446 |
CONTROL-SERVO, MANUAL Price: $1,343.56 |
| 27 |
93-6365 |
GEROTER-INNER Price: $124.40 |
| 28 |
93-6364 |
GEROTER-OUTER Price: $152.48 |
| 29 |
94-3041 |
ORIFICE-CONTROL (.028 DIA) Price: $26.81 |
| 30 |
74-9280 |
PLUG ASM Price: $35.55 |
| 31 |
105-2913 |
VALVE-BYPASS Price: $91.51 |
| 32 |
94-3030 |
WASHER Price: $6.24 |
| 33 |
93-6336 |
WASHER Price: $3.19 |
| 41 |
532140675 |
STRAP Price: $5.99 |
