| Ref | Part Number | Description |
|---|
| 1 |
237-78 |
O-RING Price: $3.85 |
| 1 |
951-10438 |
FUEL TANK Not Available This part replaces 751-10438. Price: |
| 2 |
83-7000 |
HYD CYLINDER ASM This part replaces 43-5260. Price: $363.59 |
| 2 |
951-10841 |
FLYWHEEL SHROUD Not Available This part replaces 751-10841. Price: |
| 3 |
32152-10 |
LOCKNUT Price: $0.81 |
| 3 |
951-10840 |
REED VALVE ASSEMBLY Not Available This part replaces 751-10840. Price: |
| 4 |
951-10334 |
Oil Filler Tube Assembly This part replaces 751-10334. Price: $20.69 |
| 5 |
70-2780 |
PISTON Price: $133.22 |
| 5 |
951-10333 |
Dipstick Assembly This part replaces 751-10333. Price: $15.70 |
| 6 |
951-10845 |
CYLINDER HEAD ASSEMBLY Not Available This part replaces 751-10845. Price: |
| 7 |
951-11789A |
SHORTBLOCK ASSEMBLY Not Available This part replaces 751-10847. Price: |
| 8 |
951-10320A |
Stop Switch and Brake Ass'y This part replaces 751-10320. Price: $34.99 |
| 9 |
951-10319 |
Recoil Spring & Pulley This part replaces 751-10319. Price: $44.50 |
| 10 |
70-2770 |
DISCONTINUED Price: Call Us |
| 10 |
951-10314 |
Push Rod This part replaces 751-10314. Price: $15.70 |
| 11 |
951-10313 |
Valve Kit This part replaces 751-10313. Price: $57.10 |
| 12 |
43-5220 |
RING-RETAINING Price: $65.14 |
| 12 |
951-10370 |
Oil Drain Plug & Washer Assembly This part replaces 751-10370. Price: $7.96 |
| 13 |
43-5230 |
DISCONTINUED Price: Call Us |
| 13 |
951-10367 |
Ignition Coil Assembly This part replaces 751-10367. Price: $95.86 |
| 14 |
951-10838 |
CARBURETOR ASSEMBLY This part replaces 751-10838. Price: $90.60 |
| 15 |
751P10307A |
WOODRUFF KEY This part replaces 751-10307. Price: $2.01 |
| 16 |
951-10876 |
Air Cleaner Housing Assembly Complete This part replaces 751-10844. Price: $36.07 |
| 17 |
710-05093 |
Carb Stud M6x92 This part replaces 751-10304. Price: $3.65 |
| 19 |
951-12296A |
FUEL FILTER This part replaces 751-10358. Price: $8.68 |
| 20 |
951-10440 |
Fuel Cap This part replaces 751-10440. Price: $17.59 |
| 21 |
951-10299A |
Recoil Starter This part replaces 751-10299. Price: $60.89 |
| 22 |
951-10298 |
Air Filter This part replaces 751-10298. Price: $15.94 |
| 23 |
951-10297 |
Air Cleaner Thumb Screw This part replaces 751-10297. Price: $5.34 |
| 24 |
951-10404 |
MUFFLER GUARD Not Available This part replaces 751-10404. Price: |
| 25 |
951-10843 |
MUFFLER Not Available This part replaces 751-10843. Price: |
| 26 |
951-10402 |
Muffler Gasket /Heat Shield This part replaces 751-10402. Price: $16.75 |
| 27 |
951-10387 |
Governor Return Spring This part replaces 751-10387. Price: $6.54 |
| 28 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 751-10292. Price: $6.35 |
| 29 |
951-10869 |
ROLL OVER VALVE ASSEMBLY Not Available This part replaces 751-10869. Price: |
| 30 |
951-14126 |
Carbon Canister This part replaces 751-10443. Price: $27.92 |
| 31 |
951-10351A |
SPARK ARRESTOR This part replaces 751-10351. Price: $48.91 |
