| Ref | Part Number | Description |
|---|
| 1 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 1 |
530035203 |
Idle Speed Adj. Screw Price: $5.99 |
| 2 |
530035339 |
Idle Speed Adj. Spring Price: $1.99 |
| 2 |
63-8410 |
WASHER Price: $1.76 |
| 3 |
108-1928-03 |
BRACKET-GEARBOX Price: $82.35 |
| 3 |
504130906 |
GASKET This part replaces 530035164. Price: $1.99 |
| 4 |
504130807 |
PUMP DIAPHRAGM This part replaces 530035166. Price: $2.99 |
| 4 |
63-9750 |
MOUNT Price: $18.92 |
| 5 |
3231-26 |
SCREW-CARR Price: $0.86 |
| 5 |
530035172 |
Fuel Inlet Screen WT-3 Price: $0.64 |
| 6 |
108-1341-03 |
COVER-DECK, RH REAR (OUTER) Price: $28.53 |
| 6 |
503117001 |
Needle This part replaces 530035106. Price: $7.99 |
| 7 |
119-4808-03 |
COVER-DECK, RH FRONT (OUTER) Price: $28.42 |
| 7 |
530035188 |
Metering Lever Spring Price: $1.99 |
| 8 |
119-4807-03 |
COVER-DECK, RH (INNER) Price: $131.44 |
| 8 |
530035016 |
Metering Lever Pin Screw Price: $2.99 |
| 9 |
119-4806-03 |
COVER-DECK, LH (INNER) Price: $116.22 |
| 9 |
505520127 |
Metering Lever This part replaces 530035031. Price: $3.99 |
| 10 |
119-4805-03 |
COVER-DECK, LH (OUTER) Price: $45.98 |
| 10 |
505520125 |
Pin This part replaces 530035028. Price: $1.99 |
| 11 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 11 |
530035162 |
Welch Plug-5/16 Dia. Price: $0.99 |
| 12 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 12 |
530035163 |
Welchg Plug-1/4 Dia. Price: Call Us |
| 13 |
131-6083 |
GEARBOX ASM Price: $967.44 |
| 13 |
530035165 |
Metering Diaphragm Gasket Price: $7.99 |
| 14 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 14 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 15 |
29-4820 |
ROLLER Price: $14.88 |
| 15 |
530035023 |
Low Speed Mixture Needle Spring Price: $0.99 |
| 16 |
325-18 |
SCREW-HH Price: $3.19 |
| 16 |
530035171 |
Low Speed Mixture Needle Price: $2.99 |
| 17 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 17 |
530035169 |
High Speed Mixture Needle Price: Call Us |
| 18 |
530035167 |
High Speed Mixture Needle Spring Price: $0.64 |
| 19 |
117-6989 |
FRACTIONAL TURN OVAL HEAD STUD ASM Price: $13.02 |
| 21 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 23 |
323-4 |
SCREW-HH Price: $1.02 |
| 24 |
93-6697 |
DECAL-LUBE Price: $11.38 |
| 25 |
1-804254 |
NUT-LOCK, HH Price: $1.29 |
| 26 |
106-6778 |
BUSHING-LATCH, SWELL Price: $1.28 |
| 27 |
106-6777 |
HANDLE-LATCH, SWELL Price: $22.20 |
| 28 |
131-6084 |
BREATHER PLUG ASM (F/W GEARBOX) Price: $35.71 |
| 530035027 |
Fuel |
Inlet Screen WT20/247 Price: $1.99 530035027 |
