Center Boom Mount Assembly
Parts (39)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 144-6198-03 | CRADLE-ASM, LOWER [BLACK] Price: $47.56 |
| 2 | 140-6355 | CRADLE ASM-UPPER This part replaces 140-7337-03. Price: $55.22 |
| 3 | 136-0381 | BOOM-LH Price: $460.17 |
| 5 | 108-3725 | LH SINGLE BODY TURRET ASM Price: $57.64 |
| 6 | 108-3727 | DOUBLE TURRET BODY ASM Price: $57.64 |
| 7 | 108-3726 | RH SINGLE BODY TURRET ASM Price: $57.64 |
| 9 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 10 | 108-3717 | HOSE-BOOM Price: $25.69 |
| 11 | 108-3439 | TEE Price: $10.76 |
| 12 | 2412-129 | CLAMP-HOSE Price: $2.10 |
| 13 | 110-5050 | SCREW-HHF Price: $2.59 |
| 14 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 15 | 108-3457 | SPACER Price: $21.03 |
| 16 | 3213-8 | SCREW-HH Price: $2.58 |
| 17 | 108-3489 | CAP-TUBE Price: $3.25 |
| 18 | 110-5052 | SCREW-HHF Price: $1.22 |
| 19 | 108-3495 | COVER-SLIDE Price: $98.16 |
| 20 | 108-3743 | WASHER Price: $2.31 |
| 21 | 108-3744 | SCREW-SHOULDER Price: $9.60 |
| 22 | 114-9566 | CLAMP-R Price: $2.78 |
| 23 | 95-9186 | CAP Price: $7.89 |
| 24 | 95-9187 | CAP-BLANK Price: $10.69 |
| 25 | 108-3735 | HOSE-BOOM, CENTER (LH) Price: $43.48 |
| 26 | 108-3718 | HOSE-BOOM, CENTER (RH) Price: $43.48 |
| 27 | 3256-68 | WASHER-FLAT Price: $2.69 |
| 28 | 110-5070 | BUMPER Price: $10.00 |
| 29 | 130-8244-03 | MOUNT-BOOM, RH Price: $76.95 |
| 30 | 130-8245-03 | MOUNT-BOOM, LH Price: $76.95 |
| 31 | 110-5057 | CAPSCREW-HHF Price: $2.71 |
| 32 | 108-3745 | NUT-HHF, WHIZ Price: $1.15 |
| 33 | 132-4323 | HOSE-BOOM, CENTER Price: $132.77 |
| 34 | 127-3923 | CONDUIT-CONVOLUTED Price: $9.97 |
| 35 | 144-6199 | SPRING-EXTENSION Price: $65.21 |
| 36 | 3290-378 | TIE-CABLE Price: $0.79 |
| 37 | 3234-42 | SCREW-HHF Price: $1.10 |
| 38 | 136-0382 | BOOM-RH Price: $460.17 |
| 39 | 110-6894 | WASHER-PIVOT Price: $0.59 |
| 40 | 3296-19 | NUT-HEX Price: $0.65 |
| 41 | 3246-4 | SCREW-SET Price: $0.75 |
