| Ref | Part Number | Description |
|---|
| 1 |
93-3199-03 |
RH SPINDLE ASM This part replaces 92-7825. Price: $366.74 |
| 2 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
92-7807-01 |
REAR AXLE PIN ASM This part replaces 92-7807. Price: $151.97 |
| 4 |
67-1750 |
BUSHING Price: $0.92 |
| 5 |
32128-23 |
NUT-HF Price: $1.51 |
| 6 |
92-7803-01 |
AXLE SUPPORT ASM This part replaces 92-7803. Price: $958.49 |
| 7 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 8 |
532139123 |
PULLEY.IDLER.V. This part replaces 532121361. Price: $32.99 |
| 8 |
71-4540 |
WASHER-THRUST Price: $1.97 |
| 9 |
32146-20 |
NUT-HEX Price: $3.23 |
| 9 |
532177748 |
KEEPER ASM BELT ENGINE Price: $12.99 |
| 10 |
32151-104 |
RING-RETAINING, EXTERNAL Price: $4.85 |
| 10 |
532175287 |
BUSHING Price: $17.99 |
| 11 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 11 |
532414737 |
KIT.TRACTOR CLUTCH.OG.1.125" This part replaces 532174605. Price: $199.99 |
| 12 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 12 |
532143996 |
PULLEY ENG VGT ELECT CLUTCH Price: $37.99 |
| 13 |
237-22 |
O-RING Price: $2.43 |
| 14 |
106-6774 |
JOINT-BALL This part replaces 92-5838. Price: $79.04 |
| 15 |
340-54 |
ELBOW-45 DEG Price: $40.72 |
| 15 |
532179115 |
TANK.FUEL.5.0 LEFT.FILL.YTGT Price: $89.99 |
| 16 |
115-4524 |
CYLINDER-HYDRAULIC This part replaces 92-7828. Price: $914.47 |
| 16 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 17 |
5-1226 |
WASHER Price: $3.90 |
| 17 |
532106082 |
PAD-SPACER LT Price: $3.99 |
| 18 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 18 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 19 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 21 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532164863. Price: $14.99 |
| 22 |
217-106 |
WHEEL-8 INCH Price: $141.58 |
| 22 |
532175440 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532178639. Price: $27.99 |
| 23 |
5108 |
VALVE This part replaces 232-31. Price: $6.29 |
| 24 |
231-105 |
TIRE-RIBBED Price: $62.56 |
| 24 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 25 |
32136-5 |
NUT-HEX, SLOTTED Price: $2.71 |
| 25 |
873920600 |
Nut Keps 3/8-24 Unf Price: $3.99 |
| 26 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 26 |
532003645 |
BUSHING OUTLET T Price: $3.99 |
| 27 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 27 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 28 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 28 |
532008542 |
FUEL LINE 42" This part replaces 532007834. Price: $5.99 |
| 29 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
21-2820 |
HUB Price: $269.34 |
| 31 |
253-129 |
SEAL Price: $21.73 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 32 |
111512 |
DISCONTINUED This part replaces 10-6830. Price: Call Us |
| 33 |
99-1292-03 |
LH SPINDLE ASM This part replaces 92-7823. Price: $366.74 |
| 34 |
256-121 |
WASHER-THRUST Price: $4.55 |
| 35 |
100-6566-03 |
REAR AXLE ASM This part replaces 92-7816. Price: $926.46 |
| 35 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 36 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 37 |
3220-6 |
NUT-JAM Price: $1.25 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
92-7821 |
DISCONTINUED Price: Call Us |
| 39 |
21-0141 |
RH BALL JOINT ASM Price: $109.12 |
| 39 |
596564004 |
SCREW TT 3/8-16X2.31 UNC This part replaces 817490636. Price: $1.99 |
| 40 |
3220-5 |
NUT-JAM Price: $0.65 |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 UNC Price: $3.99 |
| 41 |
256-242 |
BUSHING Price: $3.32 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
21-2000 |
TIE ROD-STEERING Price: $103.72 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
3220-3 |
NUT-HJ Price: $0.28 |
| 43 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 45 |
56-2460 |
WASHER-FLAT Price: $3.32 |
| 46 |
323-6 |
SCREW-HH Price: $0.66 |
| 47 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 47 |
532175288 |
BUSHING Price: $4.99 |
| 48 |
24-9830-01 |
AXLE SUPPORT ASM This part replaces 24-9830. Price: $83.43 |
| 49 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 50 |
3217-9 |
NUT-HH Price: $0.37 |
| 51 |
71-4850 |
DISCONTINUED Price: Call Us |
| 52 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 53 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
532176069 |
TUBE.EXHAUST.B&S.VGT.LH Price: $51.99 |
| 71 |
532176070 |
TUBE.EXHAUST.B&S.VGT.RH Price: $64.99 |
| 74 |
532162295 |
ELBOW STREET BRASS Price: $29.99 |
| 79 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 80 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532148315. Price: $14.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
