| Ref | Part Number | Description |
|---|
| 1 |
117-8320 |
SADDLE ASM Price: $3,431.83 |
| 1 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 2 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 2 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 3 |
323-6 |
SCREW-HH Price: $0.66 |
| 3 |
532141342 |
KEEPER/MOWER DRIVE RH Price: $4.99 |
| 4 |
108-0657 |
PIN-FLAG Price: $39.42 |
| 4 |
532138029 |
PULLEY.ENGINE.36/38 LR Price: $48.99 |
| 5 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 5 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 6 |
3233-32 |
BOLT-CARRIAGE Price: $8.48 |
| 6 |
871170744 |
Bolt, Hex Hd. 7/16-20 UNF Grade 5 Price: $2.99 |
| 7 |
117-8305-03 |
SADDLE-PIVOT Price: $20.05 |
| 7 |
531005025 |
BELT Price: $68.99 |
| 8 |
325-7 |
SCREW-HH Price: $1.53 |
| 8 |
532156109 |
BELT KEEPER KIT This part replaces 532123405. Price: $3.99 |
| 9 |
872140612 |
Bolt, Carriage 3/8-16 UNC x 1-1/2 Price: $2.99 |
| 10 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 10 |
532123396 |
KEEPER.BELT.GROUND.DRIVE.IDLER Price: $4.99 |
| 11 |
532150926 |
ARM, GROUND DRIVE CLUTCH Price: $4.69 |
| 12 |
532123674 |
PULLEY.IDLER.FLAT Price: $24.99 |
| 13 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 14 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 15 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 16 |
532126471 |
CLIP,INSULATOR Price: $3.99 |
| 17 |
532150932 |
SPACER, RETAINER Price: $2.99 |
| 18 |
532131459 |
SPRING.EXTENSION Price: $4.99 |
| 20 |
532139919 |
KEEPER-T/A GROUND DRIVE BELT Price: $2.99 |
| 21 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 22 |
532123404 |
KEEPER,FRA DR BEL Price: $3.22 |
| 23 |
532140916 |
KEEPER-MOWER DRIVE LH Price: $5.99 |
| 24 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 25 |
532150935 |
BUSHING NYLON COLLERED Price: $3.99 |
