| Ref | Part Number | Description |
|---|
| 1 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 2 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 2 |
530016153 |
Screw Price: $1.99 |
| 3 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 3 |
530059006 |
Reflector-Tape Price: $1.99 |
| 4 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 4 |
530039238 |
Module - Ignition Price: $29.99 |
| 5 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 5 |
530016432 |
Screw Price: $1.99 |
| 6 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 6 |
530047442 |
Strap-Ground Price: $1.99 |
| 7 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 7 |
530057943 |
Assy-Wire Harness Price: $5.99 |
| 8 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 8 |
530058687 |
Cover-Air Filter Price: $4.99 |
| 9 |
530057925 |
Filter-Air Price: $0.99 |
| 10 |
530016425 |
Screw Price: $1.99 |
| 11 |
530057892 |
Housing-Air Filter Price: $4.99 |
| 12 |
545070601 |
Carburetor Zama W-26 This part replaces 530035590. Price: $27.99 |
| 13 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 14 |
530047721 |
Bulb-Purge "snap-in" Price: $3.99 |
| 16 |
530071894 |
Gasket-cyl. o-ring (kit) Price: $6.99 |
| 17 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 19 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 21 |
530057942 |
Backplate-Muffler Price: $5.99 |
| 22 |
530071894 |
Gasket-Muffler (kit) Price: $6.99 |
| 23 |
530071886 |
Kit-Spark Arrestor Price: $9.99 |
| 24 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 25 |
545015301 |
Insert-Left (black) Cyl. This part replaces 530057885. Price: $2.99 |
| 26 |
545112901 |
Assy-Crankshaft/Rod This part replaces 530012537. Price: $49.99 |
| 27 |
530016417 |
Bolt Price: $1.99 |
| 28 |
530057941 |
Cap-Crankcase Price: $5.99 |
| 29 |
530056363 |
Assy-Bearing/Seal Price: $11.99 |
| 31 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 32 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 33 |
545015401 |
Insert-Right (gray) Cyl. This part replaces 530057886. Price: $2.99 |
| 34 |
530071894 |
Seal-Adaptor (kit) Price: $6.99 |
| 35 |
530016426 |
Screw Price: $1.99 |
| 36 |
530071894 |
Gasket-Carb. (kit) Price: $6.99 |
| 37 |
530057926 |
Tube-Intake Price: $1.99 |
| 38 |
530057909 |
Wire-Throttle Price: $1.99 |
| 39 |
530016101 |
Nut-Carb. Price: $1.99 |
| 41 |
530031163 |
Scrench Price: $4.99 |
