| Ref | Part Number | Description |
|---|
| 1 |
120-8056 |
TUBE ASM Price: $144.29 |
| 1 |
591350101 |
DECK.SVC.WLDT.54CC.428 This part replaces 575438003. Price: $1,099.99 |
| 2 |
120-8055 |
TUBE ASM Price: $137.84 |
| 2 |
539112170 |
MANDREL.DECK.ASSEMBLY Price: $69.99 |
| 3 |
115-4412 |
TUBE ASM Price: $132.35 |
| 3 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 539107520. Price: $3.99 |
| 4 |
115-4408 |
TUBE ASM Price: $126.40 |
| 4 |
532174375 |
PULLEY.DRIVEN.DECK.48' This part replaces 532107521. Price: $34.99 |
| 5 |
115-4406 |
TUBE ASM Price: $119.83 |
| 5 |
596134801 |
Nuts This part replaces 539107590. Price: $1.00 |
| 6 |
115-4409 |
TUBE ASM Price: $115.75 |
| 6 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 539107630. Price: $3.99 |
| 7 |
115-4405 |
TUBE ASM Price: $119.61 |
| 7 |
539110733 |
DISCHARGE CHUTE 52" Price: $44.99 |
| 8 |
136-3414 |
HYDRAULIC TUBE ASM This part replaces 125-4581. Price: $81.81 |
| 8 |
596646001 |
Springs This part replaces 539110735. Price: $3.99 |
| 9 |
595935501 |
Pins This part replaces 539110736. Price: $2.99 |
| 9 |
92-7606-03 |
BRACKET-BULKHEAD Price: $13.64 |
| 10 |
125-4560 |
HOSE ASM Price: $96.58 |
| 10 |
574870801 |
BLADE, 17.75 X 2.5 X .25 Price: $19.99 |
| 11 |
92-7539 |
HOSE-HYD Price: $134.23 |
| 12 |
105-3873-03 |
BRACKET-MOUNT, CLAMP Price: $33.52 |
| 12 |
574875002 |
PLATE.52".CONFINEMENT.BLACK Price: $37.99 |
| 13 |
120-8057 |
TUBE ASM Price: $94.49 |
| 13 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 14 |
340-70 |
NUT-LOCK Price: $2.10 |
| 14 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 15 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 15 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 16 |
115-1794 |
SCREW-HHF Price: $1.73 |
| 16 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 17 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 17 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 18 |
574841802 |
ARM, IDLER, 52" BLK Price: $27.99 |
| 19 |
105-3993-0P |
BRACKET-TUBE SUPPORT This part replaces 105-3993-03. Price: $40.13 |
| 19 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 20 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 20 |
589766102 |
Pulleys This part replaces 539132728. Price: $27.99 |
| 21 |
2412-81 |
CLAMP-R Price: $3.39 |
| 21 |
575224501 |
BUSHING, IDLER Price: $27.99 |
| 22 |
119-4036 |
SCREW-HHF Price: $0.53 |
| 22 |
532133957 |
WHEEL GAGE DONUT This part replaces 539107610. Price: $11.99 |
| 23 |
125-4570 |
TUBE ASM Price: $80.61 |
| 23 |
596434404 |
Bolts This part replaces 539107608. Price: $4.99 |
| 24 |
121-3064 |
TUBE ASM Price: $100.05 |
| 24 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 25 |
121-3063 |
TUBE ASM Price: $64.29 |
| 25 |
575224702 |
SHIELD.BELT.LH.ORANGE Price: $29.99 |
| 27 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 28 |
539108271 |
HCS 3/8-16 X 3-1/2 GR5 ZD Price: $4.99 |
| 29 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 30 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 31 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 32 |
539990923 |
RHSNB 3/8-16X1-3/4 Price: $2.99 |
| 32 |
69-9761 |
PLATE-COVER Price: $6.26 |
| 33 |
596437601 |
Washers This part replaces 539104864. Price: $2.99 |
| 33 |
94-8105 |
CLAMP-TUBE Price: $3.17 |
| 34 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 34 |
532178515 |
WASHER Price: $5.99 |
| 35 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 35 |
595901901 |
Nuts This part replaces 539119124. Price: $2.99 |
| 36 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 37 |
596241101 |
Bolts This part replaces 539113621. Price: $2.99 |
| 38 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 39 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 43 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 44 |
575967302 |
SHIELD.BELT.RH.52.ORANGE This part replaces 575320002. Price: $32.99 |
| 45 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 46 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 47 |
581724301 |
DECAL.DECK.6MIL.EURO.NOSTEP This part replaces 539105743. Price: $3.99 |
| 48 |
539113224 |
DECAL, CAUTION Price: $4.99 |
| 49 |
531229002 |
DECAL.DECK.BELT.ROUTING.48/54 This part replaces 532198785. Price: $1.99 |
| 50 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 51 |
539108461 |
BOLT 1/4-20 X 1/2 HWST Price: $2.99 |
| 52 |
596435201 |
Bolts This part replaces 539104870. Price: $2.99 |
| 53 |
574845603 |
BELT, 143.5" EL Price: $89.99 |
| 54 |
531165901 |
SERVICE KIT GUARD This part replaces 575224301. Price: $4.99 |
| 55 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 56 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 57 |
596645601 |
Springs This part replaces 539106850. Price: $8.99 |
| 58 |
539112050 |
BEARING, BALL Price: $5.99 |
| 59 |
575352901 |
RP PULLEY, COLLECTION 48 Price: $54.99 |
| 60 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 61 |
532404851 |
ROD.ANTI.SWAY.48/54"K4 Price: $22.99 |
| 62 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 63 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
