| Ref | Part Number | Description |
|---|
| 1 |
130-2682-0P |
CHAMBER-OUTER This part replaces 130-2682-01. Price: $277.06 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO Price: $219.99 |
| 2 |
130-2683-0P |
CHAMBER-INNER This part replaces 130-2683-01. Price: $249.02 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
3230-18 |
SCREW-CARR Price: $4.09 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
3296-45 |
NUT-HEX Price: $3.79 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
29-4820 |
ROLLER Price: $14.88 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
325-17 |
SCREW-HH Price: $2.90 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
107-3154 |
NUT-PUSH Price: $0.99 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
74-5950 |
LATCH-SWELL Price: $21.28 |
| 10 |
100-5669 |
COVER-MOTOR, LH DECK Price: $139.21 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $17.99 |
| 11 |
100-5664-03 |
PLATE-COVER, LH Price: $73.07 |
| 12 |
100-5667-03 |
PLATE-COVER, LH SIDE Price: $77.06 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $8.99 |
| 13 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
1-804254 |
NUT-LOCK, HH Price: $1.29 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
871110814 |
BOLT.HEX.BLACK Price: $8.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
810040800 |
LOCKWASHER Price: $5.99 |
