| Ref | Part Number | Description |
|---|
| 1 |
539102827 |
SPACER Price: $4.99 |
| 1 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 2 |
539102828 |
SCREW, 5/16 X 5/8 SHOULDER Price: $3.99 |
| 2 |
76-1910 |
DISCONTINUED Price: Call Us |
| 3 |
539103547 |
WASHER Price: $0.99 |
| 3 |
92-6533 |
SEAT CUSHION KIT This part replaces 67-9550. Price: $290.43 |
| 4 |
104-4620 |
SEAT This part replaces 66-5400. Price: $273.15 |
| 4 |
539105069 |
E-RING 5/8 Price: $2.99 |
| 5 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 5 |
92-6534 |
ORDER COMPLETE SEAT This part replaces 67-9560. Price: Call Us |
| 6 |
539108460 |
BOLT 5/16-18 X 1 1/4 TFS Price: $2.99 |
| 7 |
539108793 |
DAMPENER Price: $49.99 |
| 8 |
539110021 |
POST, RETURN TO NEUTRAL Price: $3.99 |
| 8 |
76-2940 |
BUMPER Price: $9.73 |
| 9 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 9 |
539110142 |
SHAFT, MOTION, BRAKE PLATED Price: $54.99 |
| 10 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 10 |
539110145 |
MOTION CASTING Price: $34.99 |
| 11 |
322-3 |
SCREW-HH Price: $0.79 |
| 11 |
539110233 |
MOTION CONTROL ARM, WLDMNT LH Price: $59.99 |
| 12 |
539110236 |
MOTION CONTROL ARM, WLDMNT RH Price: $59.99 |
| 12 |
66-8610 |
DISCONTINUED Price: Call Us |
| 13 |
539110430 |
BUSHING ELASTOMER Price: $3.99 |
| 13 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 14 |
108-6702 |
ADJUSTER-SEAT, W/HANDLE This part replaces 66-8510. Price: $239.09 |
| 14 |
594977001 |
Nuts This part replaces 539110340. Price: $4.99 |
| 15 |
539110268 |
BRAKE ROD FORMED RT Price: $11.99 |
| 15 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 16 |
539110269 |
BRAKE ROD FORMED LT Price: $11.99 |
| 16 |
66-8540 |
SPRING HANGER Price: $41.78 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
539110282 |
BRAKE LEVER Price: $9.99 |
| 18 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 18 |
596299801 |
Springs This part replaces 539110342. Price: $2.99 |
| 19 |
539110477 |
BRAKE LEVER SPRING Price: $3.99 |
| 19 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 20 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 20 |
539110478 |
BRAKE LEVER CAP Price: $2.99 |
| 21 |
32128-25 |
NUT-HF Price: $3.19 |
| 21 |
539110675 |
SPRING BRACKET Price: $14.99 |
| 22 |
539113121 |
MOTION BUSHING Price: $3.99 |
| 22 |
66-8600 |
FRAME-UPPER Price: $327.08 |
| 23 |
539916159 |
SPRING-TRANS Price: $5.99 |
| 24 |
596582201 |
Bolts This part replaces 539976935. Price: $2.99 |
| 25 |
539976937 |
HCS 5/16-18X2 Price: $2.99 |
| 26 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 27 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 28 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 29 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 30 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 31 |
596584001 |
Screws This part replaces 539991034. Price: $2.99 |
| 32 |
597357701 |
Nuts This part replaces 539991112. Price: $2.99 |
| 33 |
596565401 |
Screws This part replaces 539990643. Price: $1.99 |
| 34 |
539110338 |
CONTROL LEVER Price: $54.99 |
