| Ref | Part Number | Description |
|---|
| 1 |
58-9580-03 |
REST-FOOT Price: $291.45 |
| 2 |
60-0640-01 |
PEDAL-TRACTION Price: $172.47 |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 5 |
60-2110 |
PIN Price: $1.42 |
| 6 |
48-6790 |
BEARING Price: $12.14 |
| 8 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 9 |
3-2858 |
DISC-FRICTION Price: $31.32 |
| 10 |
60-1130 |
LEVER Price: $177.91 |
| 11 |
3290-483 |
WASHER-CONICAL Price: $7.61 |
| 12 |
325-9 |
SCREW-HH Price: $1.87 |
| 13 |
47-7030 |
BUSHING-RUBBER Price: $31.76 |
| 15 |
33014-00 |
NUT-HEX Price: $0.25 |
| 16 |
3217-9 |
NUT-HH Price: $0.37 |
| 18 |
33114-035 |
SCREW-HH This part replaces 48-7740. Price: $3.77 |
| 19 |
48-7100 |
DAMPER-STEERING Price: $441.57 |
| 20 |
3219-5 |
NUT-HEX Price: $1.22 |
| 21 |
58-4310 |
COLLAR-PINNED Price: $51.49 |
| 22 |
58-5100 |
WASHER-TRACTION Price: $28.50 |
| 23 |
60-5700 |
SPRING Price: $27.02 |
| 24 |
58-9010 |
TAB-CLAMP Price: $60.87 |
| 25 |
3274-89 |
SCREW-HSH Price: $8.07 |
| 26 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 27 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 28 |
98-1209-03 |
LEVER-PUMP Price: $336.56 |
| 29 |
60-6990 |
WASHER Price: $4.62 |
| 30 |
3255-24 |
WASHER-LOCK / EXT Price: $0.25 |
| 31 |
3217-29 |
NUT-HEX Price: $0.25 |
| 32 |
3274-7 |
SCREW-HSH Price: $0.91 |
| 33 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 34 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
112-6500-01 |
BRACKET-LOCK, NEUTRAL This part replaces 60-0730-01. Price: $300.58 |
| 36 |
92-9228-03 |
LEVER Price: $170.54 |
| 37 |
3296-19 |
NUT-HEX Price: $0.65 |
| 38 |
60-6740 |
WASHER Price: $2.31 |
| 39 |
92-9221 |
CABLE ASM Price: $19.69 |
| 40 |
92-4730-03 |
PLATE-FLOOR Price: $1,213.65 |
| 42 |
60-0760 |
CLEVIS-ROD, TRACTION Price: $42.76 |
| 43 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 44 |
33114-020 |
SCREW-HH Price: $0.28 |
| 45 |
58-0400-01 |
SHROUD Price: $472.86 |
| 46 |
62-7400 |
DECAL Price: $24.54 |
| 47 |
60-0600-03 |
BRACKET-PIVOT Price: $236.10 |
| 48 |
60-1110 |
BUSHING Price: $15.95 |
| 49 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 50 |
325-7 |
SCREW-HH Price: $1.53 |
| 51 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 52 |
2411-44 |
END-ROD Price: $72.59 |
| 54 |
76-3430 |
ROD-TRACTION Price: $79.20 |
| 55 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 65 |
322-6 |
SCREW-HH Price: $0.45 |
| 66 |
3218-2 |
NUT-JAM Price: $0.25 |
| 67 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 68 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 69 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 70 |
32128-20 |
NUT-HF Price: $0.99 |
| 71 |
121146X |
SUB= 155112 Price: Call Us |
| 71 |
33114-045 |
SCREW-HH Price: $0.68 |
| 72 |
121147X |
SUB= 150698 Price: Call Us |
| 72 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 73 |
106211X |
GASKET TI Price: Call Us |
| 73 |
3290-482 |
WASHER-BELLEVILLE Price: $5.87 |
| 74 |
5020J |
NEEDLE BRNG LT Price: Call Us |
| 76 |
102113X |
PINION-INPUT CRT Price: Call Us |
| 77 |
102110X |
SHAFT-INPUT CRT Price: Call Us |
| 79 |
102136X |
WASHER SEAL CRT Price: Call Us |
| 80 |
7392M |
SUB= 100482K Price: Call Us |
| 81 |
100371K |
SPRING-SHIFT CRT Price: Call Us |
| 82 |
106160X |
O-RING TI Price: Call Us |
| 83 |
102107X |
ARM ASSY CRT Price: Call Us |
| 84 |
8353J |
SHIFT FORK TI Price: Call Us |
| 85 |
12000039 |
KLIP RING Price: Call Us |
| 86 |
102109X |
SHAFT SHIFT CRT Price: Call Us |
| 87 |
104159X |
SPACER SPLIT CRT Price: Call Us |
| 88 |
4358J |
WASHER Price: Call Us |
| 89 |
12000040 |
KLIP RING Price: Call Us |
| 90 |
102114X |
GEAR ASSY CRT Price: Call Us |
| 91 |
102115X |
GEAR-REV IDLR CRT Price: Call Us |
| 92 |
6803J |
NEEDLE BEARING TI Price: Call Us |
| 93 |
102111X |
SHAFT CRT Price: Call Us |
| 94 |
10040700 |
LOCKWASHER Price: Call Us |
| 95 |
73610700 |
NUT.ASF.HEX.7/16 Price: Call Us |
| 96 |
102128X |
O RING CRT Price: Call Us |
| 98 |
106390X |
BUSHING TI Price: Call Us |
| 99 |
102134X |
CHAIN CRT Price: Call Us |
| 100 |
109204X |
SUB= 150737 Price: Call Us |
| 101 |
102106X |
SUB= 918102106X Price: Call Us |
| 102 |
106388X |
SPACER TI Price: Call Us |
| 103 |
102121X |
SPRCKT 8 GEAR CRT Price: Call Us |
| 104 |
102112X |
SHFT 2ND RED. CRT Price: Call Us |
| 105 |
102101X |
SCRW WHIZ LOK CRT Price: Call Us |
| 106 |
106141X |
SUB= 137300 Price: Call Us |
| 107 |
4422J |
BEARING Price: Call Us |
| 108 |
106142X |
SUB= 137300 Price: Call Us |
| 109 |
105345X |
GEAR TI Price: Call Us |
| 110 |
105346X |
GEAR TI Price: Call Us |
| 111 |
8358J |
REDUCTION SHFT TI Price: Call Us |
| 112 |
4220R |
BRNG RACE Price: Call Us |
| 113 |
106146X |
SPACER TI Price: Call Us |
| 114 |
9672R |
CUP.FORMED. Price: Call Us |
| 115 |
102144X |
RING SPIRAL CRT Price: Call Us |
| 116 |
9676R |
SUB= 147344 Price: Call Us |
| 117 |
9674R |
SUB= 147344 Price: Call Us |
| 118 |
121745X |
SUB= 150700 Price: Call Us |
| 119 |
106144X |
SHAFT ASSY TI Price: Call Us |
| 120 |
106147X |
CHAIN.50 LINK TI Price: Call Us |
| 121 |
17580408 |
SCREW CRT Price: Call Us |
