| Ref | Part Number | Description |
|---|
| 1 |
120-9090 |
HOOD ASM Price: $4,242.71 |
| 1 |
532059192 |
VALVE CAP Price: $4.99 |
| 2 |
120-9099-0P |
HOOD PIVOT ASM This part replaces 120-9099-03. Price: $341.70 |
| 2 |
532065139 |
VALVE STEM LT Price: $5.99 |
| 3 |
114-3823 |
SEAL-BULB Price: $64.68 |
| 3 |
532122073 |
TIRE.15X6-6.TURF.SAVER.FRONT This part replaces 532106222. Price: $59.99 |
| 4 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 4 |
532059904 |
TUBE.5.3/4.5/6 Price: $19.99 |
| 5 |
121-1470 |
PIVOT-SCREEN Price: $28.37 |
| 5 |
532106732 |
RIM.ASM.6X4.5.FRONT.SILVER This part replaces 532141446. Price: $79.99 |
| 6 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 6 |
532000278 |
FITTING LT. This part replaces 532124957. Price: $5.99 |
| 7 |
120-4196-0P |
HOOD SUPPORT ASM This part replaces 120-4196-03. Price: $146.51 |
| 7 |
532009040 |
BEARING.FLANGE This part replaces 532124959. Price: $6.99 |
| 8 |
137-3101 |
SCREW-PLASTIC, HWH This part replaces 46-8092. Price: $0.59 |
| 8 |
532106108 |
RIM.ASM.8X7.REAR.SILVER This part replaces 532141447. Price: $99.99 |
| 9 |
532125833 |
TIRE.20X10-8.TURF.SAVER This part replaces 532122082. Price: $119.99 |
| 9 |
65-5100 |
HANDLE-DOOR Price: $9.05 |
| 10 |
104-3590 |
SEAL-BULB Price: $37.82 |
| 11 |
104-3588-03 |
PIVOT-SCREEN Price: $32.46 |
| 12 |
103-4081 |
LATCH-KEEPER Price: $13.99 |
| 12 |
532124577 |
COVER.FRONT.WHEEL Price: $10.99 |
| 13 |
104-3580 |
SEAL-CORNER, SCREEN Price: $32.63 |
| 13 |
532124578 |
CAP,HUB REAR Price: $13.99 |
| 14 |
32144-109 |
SCREW-THD Price: $1.29 |
| 15 |
120-8949-0P |
SUPPORT-HOOD, LH This part replaces 120-8949-03. Price: $51.81 |
| 16 |
104-8313 |
ROD-HOOD Price: $58.83 |
| 17 |
283-67 |
PIN-CLEVIS Price: $2.04 |
| 18 |
2412-134 |
CLAMP-R Price: $5.79 |
| 19 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 20 |
120-9096-03 |
SCREEN-HOOD, REAR Price: $87.01 |
| 21 |
120-9097-03 |
SCREEN-HOOD, TOP Price: $185.70 |
| 22 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 23 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 24 |
117-2382 |
PLUG-PLASTIC Price: $0.69 |
| 25 |
120-9087 |
SEAL-FOAM Price: $1.77 |
| 26 |
32128-33 |
NUT-HF Price: $0.25 |
| 27 |
32104-4 |
SCREW Price: $0.47 |
| 28 |
321-4 |
SCREW-HH Price: $0.99 |
| 32 |
106-2045 |
DECAL-HOOD Price: $47.06 |
| 33 |
104-7201 |
NUT-HF Price: $0.69 |
| 34 |
120-8948-0P |
SUPPORT-HOOD, RH This part replaces 120-8948-03. Price: $53.08 |
| 35 |
3269-4 |
RIVET-POP Price: $1.19 |
| 37 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 38 |
3274-65 |
SCREW-HSBH Price: $1.15 |
| 39 |
127-3707-0P |
SUPPORT-HOOD This part replaces 127-3707-03. Price: $22.24 |
