| Ref | Part Number | Description |
|---|
| 1 |
422594 |
Belt Guard Price: Call Us |
| 2 |
481531 |
Hinge, Belt Guard Price: Call Us |
| 3 |
04003-07 |
Bolt, Carriage 1/4-20 x 1/2" Price: Call Us |
| 4 |
04019-02 |
Nut, Hex Serrated Flange 1/4-20 Price: Call Us |
| 5 |
04003-02 |
Bolt, Carriage 1/4-20 x 3/4" Price: Call Us |
| 6 |
422386 |
Brace, Engine Mounting Price: Call Us |
| 7 |
04001-19 |
Bolt, Hex Head 3/8-16 x 1" Price: Call Us |
| 8 |
04021-09 |
Nut, Hex Elastic Stop 3/8-16 Price: Call Us |
| 9 |
481284 |
Bumper, Rubber Price: Call Us |
| 10 |
04019-03 |
Nut, Hex Serrated Flange 5/16-18 Price: Call Us |
| 11 |
481460 |
Belt, Deck Drive Price: Call Us |
| 12 |
481461 |
Belt, Pump Drive Price: Call Us |
| 13 |
481522 |
Spring, Main Drive Price: Call Us |
| 14 |
462088 |
PUMP MTG PLATE ASSY, 2000-01 This part replaces 451021. Price: Call Us |
| 15 |
43428 |
Base, Clutch Anti-Rotation Price: Call Us |
| 16 |
04019-05 |
Nut, Hex Serrated Flange 7/16-14 Price: Call Us |
| 17 |
481469 |
Isolator, Rubber Price: Call Us |
| 18 |
461716 |
CLUTCH UPGRADE PKG, STT-GT 3.5 This part replaces 481530. Price: Call Us |
| 19 |
04063-06 |
Key, 1/4 x 1/4 x 1-1/2" Price: Call Us |
| 20 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 21 |
04001-101 |
Bolt, Hex Head 7/16-20 x 2-1/2" Price: Call Us |
| 22 |
48030-09 |
Clamp, Cable 1/2" ID. Price: Call Us |
| 23 |
04030-03 |
Lockwasher, 5/16" Price: Call Us |
| 24 |
04020-03 |
Nut, Hex 5/16-18 Price: Call Us |
| 25 |
481535 |
Pulley, 6.00 OD. 1.125 Bore Price: Call Us |
| 26 |
04030-02 |
Lockwasher, 1/4" Price: Call Us |
| 27 |
422714 |
Base, Idler Arm Price: Call Us |
| 28 |
04001-09 |
Bolt, Hex Head 5/16-18 x 1" Price: Call Us |
| 29 |
04021-10 |
Nut, Hex Elastic Stop 5/16-18 Price: Call Us |
| 30 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" Price: Call Us |
| 31 |
04041-07 |
Flatwasher, 3/8" (.391 x .938 x .105) Price: Call Us |
| 32 |
48181 |
Pulley, Idler Price: Call Us |
| 34 |
04043-04 |
Flatwasher, 3/8 GR 8 Special Price: Call Us |
| 35 |
48224 |
Ball Bearings Price: Call Us |
| 36 |
04019-04 |
Nut, Hex Serrated Flange 3/8-16 Price: Call Us |
| 37 |
04001-136 |
Bolt, Hex Head 3/8-16 x 1-1/2" Price: Call Us |
| 38 |
481398 |
Pulley, 6.35 Dia. Taper Bore Price: Call Us |
| 39 |
481536 |
Tapered Hub, 1.00 Bore Price: Call Us |
| 40 |
04012-05 |
Setscrew, Hex Socket 1/4-20 x 1/2" Price: Call Us |
| 41 |
04001-138 |
Bolt, Hex Head 3/8-16 x 3-3/4" Price: Call Us |
| 43 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 44 |
04020-04 |
Nut, Hex 3/8-16 Price: Call Us |
| 45 |
43277 |
Spacer Price: Call Us |
| 46 |
04021-05 |
Locknut, Hex Center Lock 3/8-16 Price: Call Us |
| 47 |
483211 |
Idler Pulley, Wheel Drive This part replaces 48198. Price: Call Us |
| 48 |
482751 |
Pulley, Pump Shaft This part replaces 48586. Price: Call Us |
| 49 |
04063-14 |
Key, 5 x 5 x 25 mm Price: Call Us |
| 50 |
481309 |
Latch, Hood Price: Call Us |
| 51 |
04010-01 |
Screw, Phillips Washer Head #10-32 x 1/2" Price: Call Us |
| 52 |
04031-01 |
Lockwasher, #10-32 External Tooth Price: Call Us |
| 53 |
04020-01 |
Nut, Hex #10-32 Price: Call Us |
| 55 |
04001-10 |
Bolt, Hex Head 5/16-18 x 1-1/4" Price: Call Us |
| 56 |
04063-20 |
Key, 1/4 x 1/4 x 1" Price: Call Us |
| 57 |
43644 |
Spindle Housing This part replaces 43294. Price: Call Us |
| 58 |
43296 |
Spacer, Inside Price: Call Us |
| 59 |
43297 |
Spindle Bushing, Bottom Price: Call Us |
| 60 |
43312 |
Spacer, Outside Price: Call Us |
| 61 |
43321 |
Shaft, PTO Deck Drive Price: Call Us |
| 62 |
481022 |
Roller Bearing Assembly Price: Call Us |
| 63 |
481024 |
Seal, 2.00 OD. x 1.50 Bore Price: Call Us |
| 64 |
481025 |
Seal, 2.00 OD. x 1.625 Bore Price: Call Us |
| 65 |
481035 |
Nut, 1.06-18 Price: Call Us |
| 66 |
48114-04 |
Grease Fitting 1/4-28 Self Tap Price: Call Us |
| 67 |
48677 |
Relief Fitting Price: Call Us |
| 68 |
482424 |
Driveshaft This part replaces 481528. Price: Call Us |
| 69 |
04001-109 |
Bolt, Hex head 1/4-20 x 1-3/8" Full Thread Price: Call Us |
| 70 |
04001-31 |
Bolt, Hex Head 3/8-16 x 2.50 Price: Call Us |
| 71 |
43503 |
Pivot, Idler - Short Price: Call Us |
| 72 |
04001-21 |
Bolt, Hex Head 3/8-16 x 1-3/4" Price: Call Us |
| 73 |
04063-20 |
Key Price: Call Us |
| 74 |
04021-05 |
Nut, Center Lock 3/8-16 Price: Call Us |
