| Ref | Part Number | Description |
|---|
| 0 |
640230 |
CARBURETOR-NLA This part replaces 640902A. Price: Call Us |
| 1 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 1 |
632947 |
SHAFT & LEV Price: $18.80 |
| 2 |
117-9565-01 |
TUBE-CROSS Price: $620.99 |
| 2 |
632928 |
SPRING Price: $2.60 |
| 3 |
632926 |
CLIP Price: Call Us |
| 3 |
93-4696 |
PIN-HITCH Price: $5.84 |
| 3A |
632950 |
SCREW Price: Call Us |
| 3B |
632949 |
SPACER Price: Call Us |
| 4 |
119-9020-0P |
PIVOT HUB ASM This part replaces 119-9020-03. Price: $270.51 |
| 4 |
632939A |
WASHER Price: Call Us |
| 5 |
119-9018 |
HANDLE PIVOT ASM Price: $412.34 |
| 5 |
532411764 |
DASH.P/L.TEX.CBL.CL.N/CHK.BLAC Price: $44.99 |
| 5 |
632929A |
WASHER Price: $3.86 |
| 6 |
108-4548 |
SPRING-TORSION Price: $64.72 |
| 6 |
632930 |
SHUTTER Price: $10.29 |
| 7 |
120-3414 |
HANDLE ASM Price: $412.45 |
| 7 |
632931 |
SCREW Price: $2.57 |
| 8 |
233-48 |
KNOB Price: $10.92 |
| 9 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 10 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 11 |
109-1063 |
SCREW-WING Price: $3.49 |
| 12 |
120-3404 |
BLOCK-GUIDE Price: $43.90 |
| 13 |
117-2486-01 |
GUIDE Price: $43.49 |
| 14 |
532406179 |
HOOD.BLACK.ALPHA Price: $89.99 |
| 14 |
59-9460 |
GUIDE Price: $14.60 |
| 15 |
115-5103 |
SCREW-HHF Price: $0.34 |
| 16 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 17 |
632946 |
SCREW Price: $6.48 |
| 17 |
98-1375 |
SCREW-HWH Price: $1.45 |
| 18 |
120-3413 |
CUTTER HEAD ASM Price: $828.24 |
| 18 |
532426741 |
GRILLE.ASM.ALPHA Price: $119.99 |
| 19 |
112-9318 |
SCREW-HHF, LOCKING Price: $1.38 |
| 20 |
640908 |
SCREW Price: $9.15 |
| 20 |
93-6024 |
BUSHING-SUPPORT, HANDLE Price: $14.67 |
| 21 |
323-14 |
SCREW-HH Price: $1.34 |
| 21 |
640904 |
SPRING Price: $3.76 |
| 27 |
632916 |
PIN Price: $2.49 |
| 28 |
632915 |
LEVER Price: $2.60 |
| 30 |
632918 |
INLET NEEDLE Price: $7.48 |
| 31 |
632920 |
SPRING Price: $2.60 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS Price: $34.99 |
| 34 |
632917 |
SCREW Price: Call Us |
| 36 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 37 |
532420986 |
FENDER.TLT.FS.W/CPH.428 Price: $149.99 |
| 45 |
632919 |
SCREEN Price: $2.45 |
| 48 |
632902 |
WELCH PLUG Price: Call Us |
| 50 |
632904 |
DIAPHRAGM Price: $14.93 |
| 51 |
632903 |
GASKET Price: $2.60 |
| 52 |
632905 |
COVER Price: Call Us |
| 52 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 53 |
632906 |
SCREW Price: $2.31 |
| 58 |
532412280 |
DRAWBAR UPPER 2PC SMALL FENDER Price: $32.99 |
| 60 |
632933 |
REPAIR KIT Price: Call Us |
| 61 |
640909 |
SCREW Price: Call Us |
| 62 |
640252 |
PUMP DIAPHRAGM This part replaces 632908. Price: $3.86 |
| 63 |
632907 |
GASKET Price: $2.60 |
| 64 |
632988 |
COVER Price: $22.17 |
| 65 |
632945 |
SCREW Price: $3.61 |
| 68 |
640906 |
MODULE Price: Call Us |
| 68 |
817490508 |
SCREW LT Price: $3.99 |
| 69 |
640907 |
CAP Price: Call Us |
| 130 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 137 |
532184921 |
BUMPER.HOOD.LARGE.1.75" Price: $3.99 |
| 138 |
532409730 |
CUPHOLDER.TL.TEX.BLACK Price: $3.99 |
| 151 |
532187568 |
BRACKET.PIVOT.ALPHA.LT Price: $11.99 |
| 152 |
532199535 |
SHIELD.BROWNING.W/TEX Price: $11.99 |
| 153 |
532195402 |
LENS.ALPHA.BAR.LT Price: $11.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 162 |
532142432 |
SCREW.HI-LO.CONSOLE Price: $3.99 |
| 175 |
532193243 |
CROSSMEMBER.LT Price: $17.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $6.99 |
| 177 |
532195228 |
BUSHING STEERING Price: $2.99 |
| 180 |
532415063 |
CHASS.WLDMNT.TL.12GA/2P.48/54 Price: $109.99 |
| 181 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $27.99 |
| 182 |
532193057 |
DASH.LOWER.LT.CCS Price: $64.99 |
| 183 |
874520520 |
BOLT.5/16-18X1-1/4 FULL THD Price: $2.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 194 |
583612701 |
NUT HEX,LOCK,FLAN This part replaces 873900500. Price: $3.99 |
| 196 |
532414579 |
CONSOLE.ASM.DECKLFT.BL/RBT.TLT Price: $22.99 |
| 213 |
539976934 |
HCS 5/16C X 3/4 This part replaces 874760512. Price: $1.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $8.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $2.99 |
| 228 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 235 |
532406129 |
SPACER FENDER Price: $2.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
