| Ref | Part Number | Description |
|---|
| 1 |
99-6810 |
SCREW-HHF Price: $3.09 |
| 2 |
324-5 |
SCREW-HH Price: $0.54 |
| 2 |
598818701 |
NEEDS DESCRIPTION Price: Call Us |
| 3 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 4 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 5 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 6 |
120-8935-03 |
BRACKET-FAN Price: $221.61 |
| 7 |
140-6482 |
HUB-FAN This part replaces 117-2364. Price: $160.95 |
| 8 |
114-3825 |
FAN Price: $353.82 |
| 9 |
340-70 |
NUT-LOCK Price: $2.10 |
| 9 |
596501502 |
Keepers Price: $9.99 |
| 10 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 11 |
121-1518 |
SHIM-SUPPORT Price: $5.04 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 12 |
121-1554 |
TUBE-HYD Price: $75.61 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
121-1555 |
TUBE ASM Price: $62.39 |
| 14 |
121-1553 |
TUBE-HYD Price: $79.36 |
| 15 |
115-8486 |
SCREW-HH Price: $0.68 |
| 15 |
597954504 |
FUEL TANK ASSEMBLY 2.5 GAL This part replaces 597954503. Price: $109.99 |
| 16 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 17 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 18 |
104-7201 |
NUT-HF Price: $0.69 |
| 18 |
587382901 |
FUEL.CAP.ASM.2.25TETHRED.RATCH Price: $14.99 |
| 19 |
117-4769 |
HYD MOTOR ASM Price: $932.88 |
| 20 |
340-129 |
FITTING-ELBOW, 90 DEG Price: $99.81 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers Price: $2.99 |
| 45 |
596133601 |
Hardware Price: $2.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 Price: $19.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 Price: $17.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 96 |
596135301 |
Washers Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 111 |
587044580 |
Hoses This part replaces 596941501. Price: $9.99 |
