| Ref | Part Number | Description |
|---|
| 1 |
105-8536-01 |
ARM-STEERING Price: $484.40 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532184995. Price: $219.99 |
| 2 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
104-5185-01 |
BRACKET-VALVE, STEERING Price: $46.12 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
323-5 |
SCREW-HH Price: $0.41 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
93-5988 |
HUB-PIVOT Price: $29.62 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
95-8794-01 |
COVER-VALVE, STEERING Price: $43.77 |
| 8 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
67-1300 |
DECAL Price: $29.99 |
| 10 |
233-48 |
KNOB Price: $10.92 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 11 |
95-8798-03 |
LEVER-STEERING Price: $104.27 |
| 12 |
121-7856 |
STEERING VALVE ASM Price: $1,012.28 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
80-2880 |
BRACKET-TILT Price: $18.75 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 14 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 15 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 16 |
32128-44 |
NUT Price: $2.69 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 17 |
75-0560 |
STEERING WHEEL ASM Price: $204.13 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 21 |
68-5370 |
DECAL Price: $6.21 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 22 |
95-8842 |
HOSE-HYD Price: $112.74 |
| 23 |
95-8843 |
HOSE-HYD Price: $115.15 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 24 |
95-8844 |
HOSE ASM Price: $111.52 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 25 |
95-8845 |
HOSE ASM Price: $117.24 |
| 26 |
95-8846 |
HOSE-HYD Price: $146.45 |
| 27 |
99-3502 |
BOSS Price: $14.91 |
| 28 |
31-0390 |
DISC-FRICTION Price: $11.25 |
| 29 |
82-9010 |
DISC-FRICTION Price: $15.53 |
| 30 |
80-2930 |
WASHER-FLAT Price: $5.00 |
| 31 |
3218-7 |
NUT-JAM Price: $3.86 |
| 32 |
33103-012 |
SCREW-HHF Price: $3.21 |
| 36 |
99-3405-01 |
SHIELD-STEERING Price: $29.30 |
| 39 |
32128-21 |
NUT-HF Price: $0.39 |
| 40 |
100-4929 |
SLOPE INDICATOR ASM Price: $196.34 |
| 41 |
321-7 |
SCREW-HH Price: $4.19 |
| 42 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 43 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 44 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 45 |
3256-27 |
WASHER-FLAT Price: $0.47 |
