| Ref | Part Number | Description |
|---|
| 1 |
3219-1 |
NUT-HEX Price: $0.47 |
| 1 |
539110941 |
FRAME W/DECALS Price: $1,535.99 |
| 2 |
539108362 |
PANEL W/ DECALS This part replaces 539107850. Price: $110.99 |
| 2 |
70-2160 |
BRACKET-STOP, SPEED Price: $65.93 |
| 3 |
539107853 |
HOOD ORANGE Price: $179.99 |
| 3 |
72-5920 |
SCREW Price: $6.96 |
| 4 |
539107847 |
REAR FRAME Price: $188.99 |
| 4 |
67-8370 |
HUB-FAN Price: $108.86 |
| 5 |
18-5620 |
SCREW-COVER TO BODY Price: $8.96 |
| 5 |
539106405 |
SUPPORT WLDMT, RT Price: $61.99 |
| 6 |
18-5630 |
LOCKWASHER Price: $7.56 |
| 6 |
539106406 |
SUPPORT WLDMT, LT Price: $60.99 |
| 7 |
18-5580 |
DISCONTINUED Price: Call Us |
| 7 |
539107205 |
FENDER WELDMT, RH Price: $147.99 |
| 8 |
539107206 |
FENDER WELDMT, LH Price: $303.99 |
| 8 |
70-2060 |
COVER Price: $358.49 |
| 9 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 9 |
539110904 |
CONSOLE TOP-FINISHED ORANGE Price: $26.99 |
| 10 |
18-5640 |
DISCONTINUED Price: Call Us |
| 10 |
539110907 |
CONTROL PANEL Price: $76.99 |
| 11 |
18-5790 |
DISCONTINUED Price: Call Us |
| 11 |
539107776 |
CONSOLE BOTTOM Price: $83.99 |
| 12 |
539110934 |
CONSOLE SUPPORT Price: $28.99 |
| 12 |
70-2140 |
DISCONTINUED Price: Call Us |
| 13 |
539108391 |
HCS 1/4-20 X 3 GR 5 ZD Price: $4.99 |
| 13 |
70-2130 |
CLAMP-BRG TO COVER Price: $85.89 |
| 14 |
18-5770 |
LOCKWASHER-BEARING/COVER Price: $1.33 |
| 14 |
539108055 |
SUPPORT WELDMENT Price: $16.99 |
| 15 |
539107867 |
BLACK-STIFFNER-PAINTED Price: $6.99 |
| 15 |
70-2150 |
FLYWEIGHT Price: $61.78 |
| 16 |
329-3 |
SCREW-HH Price: $0.22 |
| 16 |
539110920 |
DOOR - FINISHED Price: $19.99 |
| 17 |
539977778 |
ANTI-SKID PAD Price: $3.99 |
| 17 |
70-2110 |
DISCONTINUED Price: Call Us |
| 18 |
539104721 |
FOOT PLATE WIDMT Price: $179.99 |
| 18 |
70-2100 |
DISCONTINUED Price: Call Us |
| 19 |
18-5540 |
RETAINER-STOP, SLEEVE Price: $18.31 |
| 19 |
539102587 |
GROMMET, BUMPER Price: $4.99 |
| 20 |
597783101 |
GSPW Knobs This part replaces 539104411. Price: $3.99 |
| 20 |
72-5940 |
BEARING-NEEDLE Price: $61.68 |
| 21 |
539107858 |
GROMMET BUMPER Price: $3.99 |
| 21 |
70-2070 |
LEVER-ADJUSTING, SPEED Price: $46.09 |
| 22 |
539103684 |
GROMMET Price: $3.99 |
| 22 |
70-2090 |
STUD-PIVOT, LEVER Price: $14.07 |
| 23 |
3296-5 |
NUT-HEX Price: $3.09 |
| 23 |
539107656 |
GROMMET Price: $3.99 |
| 24 |
539107210 |
GROMMET Price: $6.99 |
| 24 |
72-5860 |
SPRING-GOVERNOR Price: $69.31 |
| 25 |
539110923 |
LATCH Price: $7.99 |
| 25 |
72-5850 |
PIN-FORCE, IDLE Price: $5.43 |
| 26 |
539106300 |
SKID PLATE Price: $48.99 |
| 26 |
72-5930 |
SCREW Price: $3.38 |
| 27 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 27 |
71-4780 |
DISCONTINUED Price: Call Us |
| 28 |
18-5750 |
PIN-SHAFT, LEVER Price: $1.53 |
| 28 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 29 |
3219-2 |
NUT-HEX Price: $0.37 |
| 29 |
539111568 |
IDLER Price: $59.99 |
| 30 |
539106418 |
ARM WELDMENT Price: $33.99 |
| 30 |
72-5890 |
SHAFT-ROCKER Price: $67.37 |
| 31 |
18-5410 |
TORSION SPRING Price: $9.36 |
| 31 |
539106417 |
BUSHING Price: $69.99 |
| 32 |
539103256 |
SPRING Price: $9.99 |
| 32 |
72-5880 |
THROTTLE LEVER ASM Price: $78.58 |
| 33 |
539103300 |
ZERK Price: $2.99 |
| 33 |
72-5870 |
EYEBOLT Price: $42.76 |
| 34 |
597524002 |
THROTTLE This part replaces 539102732. Price: $37.99 |
| 34 |
72-5910 |
BUMPER SCREW ASM Price: $49.84 |
| 35 |
18-5450 |
DISCONTINUED Price: Call Us |
| 35 |
596917001 |
Screws This part replaces 539110673. Price: $2.99 |
| 36 |
539990362 |
SCREW 1/4 X 5/8 Price: $3.99 |
| 36 |
70-2080 |
BODY Price: $400.66 |
| 37 |
18-5520 |
DISCONTINUED Price: Call Us |
| 37 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 38 |
121-6270 |
SPACER-PLUG, EXPANSION This part replaces 18-5440. Price: $28.84 |
| 38 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 39 |
18-5430 |
PLUG-EXPANSION Price: $7.96 |
| 39 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 40 |
18-5530 |
SCREW-LEVER TO SHAFT Price: $2.11 |
| 40 |
539110850 |
SLEEVE Price: $1.99 |
| 41 |
18-5670 |
RETAINER-PIN, PIVOT Price: $7.98 |
| 41 |
539110851 |
SLEEVE Price: $3.99 |
| 42 |
18-5660 |
PIN-PIVOT, FLYWEIGHT Price: $31.58 |
| 42 |
539110922 |
RETAINER Price: $2.99 |
| 43 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 43 |
70-2120 |
DISCONTINUED Price: Call Us |
| 44 |
32121-51 |
PIN-ROLL Price: $0.70 |
| 44 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 45 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 46 |
539110927 |
STOP Price: $12.99 |
| 47 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 48 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 49 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 50 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 51 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 52 |
596564801 |
Washers This part replaces 539990052. Price: $1.99 |
| 53 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 54 |
539107026 |
HCS 1/2-13X2 GR 8 Price: $1.99 |
| 55 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 56 |
539990258 |
NUT HEX 1/2 Price: $3.99 |
| 57 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 58 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 59 |
539976938 |
CAPSCREW Price: $3.99 |
| 60 |
596564404 |
Bolts This part replaces 539990629. Price: $2.99 |
| 61 |
539108346 |
HEX SCREW 1/2-13 X 2.5" GR 5 Price: $4.99 |
| 62 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 63 |
539111823 |
PLUG Price: $0.99 |
| 64 |
539111824 |
FOAM STRIP Price: $3.99 |
