| Ref | Part Number | Description |
|---|
| 1 |
496412 |
CYLINDER ASSY Price: Call Us |
| 2 |
399265 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 2 |
92-3992 |
REPAIR KIT Price: $153.48 |
| 3 |
391086 |
SEAL, OIL Price: Call Us |
| 4 |
494238 |
BASE, ENGINE Price: Call Us |
| 5 |
495858 |
HEAD, CYLINDER Price: Call Us |
| 7 |
272614 |
GASKET, CYLINDER HEAD Price: Call Us |
| 8 |
495735 |
BREATHER ASSY Price: Call Us |
| 9 |
27803 |
GASKET, VALVE COVER Price: Call Us |
| 10 |
94621 |
SCREW, STEMS Price: Call Us |
| 11 |
281246 |
TUBE, BREATHER Price: Call Us |
| 12 |
271916 |
GASKET, CRANKCASE COVER 1/64" Price: Call Us |
| 12 |
271996 |
GASKET, CRANKCASE COVER .009" Price: Call Us |
| 12 |
271997 |
GASKET, CRANKCASE COVER .005" Price: Call Us |
| 13 |
94728 |
SCREW, CYLINDER HEAD Price: Call Us |
| 15 |
94239 |
PLUG, OIL DRAIN Price: Call Us |
| 16 |
495162 |
CRANKSHAFT Price: Call Us |
| 16 |
94196 |
KEY, TIMING GEAR Price: Call Us |
| 20 |
291675 |
SEAL, OIL Price: Call Us |
| 22 |
94624 |
SCREW, SEMS, BASE MOUNTING Price: Call Us |
| 23 |
492326 |
FLYWHEEL & RING GEAR ASSY, MAGNETO Price: Call Us |
| 24 |
222698 |
KEY, FLYWHEEL Price: Call Us |
| 25 |
495860 |
PISTON ASSY, STANDARD SIZE Price: Call Us |
| 25 |
495977 |
PISTON ASSY .010" OVERSIZE Price: Call Us |
| 25 |
495978 |
PISTON ASSY .020" OVERSIZE Price: Call Us |
| 25 |
495979 |
PISTON ASSY .030" OVERSIZE Price: Call Us |
| 26 |
495851 |
RING SET, PISTON, .020" OVERSIZE Price: Call Us |
| 26 |
495852 |
RING SET, PISTON, .010" OVERSIZE Price: Call Us |
| 26 |
495854 |
RING SET, PISTON, STANDARD SIZE Price: Call Us |
| 26 |
495855 |
RING SET, PISTON, .030" OVERSIZE Price: Call Us |
| 27 |
263129 |
LOCK, PISTON PIN Price: Call Us |
| 28 |
498319 |
PIN, PISTON, STD SIZE Price: Call Us |
| 29 |
494504 |
ROD ASSY, CONNECTING Price: Call Us |
| 29 |
495490 |
ROD ASSY, CONNECTING Price: Call Us |
| 32 |
94695 |
SCREW Price: Call Us |
| 32A |
94648 |
SCREW Price: Call Us |
| 33 |
495856 |
VALVE, EXHAUST Price: Call Us |
| 34 |
495857 |
VALVE, INTAKE Price: Call Us |
| 35 |
262811 |
SPRING, VALVE Price: Call Us |
| 37 |
224502 |
GUARD, FLYWHEEL Price: Call Us |
| 40 |
224641 |
RETAINER, VALVE SPRING Price: Call Us |
| 45 |
262411 |
TAPPET, VALVE Price: Call Us |
| 46 |
496884 |
GEAR, CAM Price: Call Us |
| 51 |
272465 |
GASKET, CARBURETOR (CARBURETOR TO ELBOW) Price: Call Us |
| 52 |
272569 |
GASKET, CARBURETOR Price: Call Us |
| 53 |
94637 |
STUD, CARBURETOR MOUNTING Price: Call Us |
| 73 |
224948 |
SCREEN, FLUSH ROTATING Price: Call Us |
| 75 |
225136 |
WASHER, SPRING Price: Call Us |
| 78 |
94626 |
SCREW, SEMS Price: Call Us |
| 93 |
281346 |
BUSHING, THROTTLE SHAFT Price: Call Us |
| 94 |
498030 |
VALVE, IDLE, ADJUSTMENT Price: Call Us |
| 95 |
94098 |
SCREW, THROTTLE Price: Call Us |
| 98 |
495800 |
SCREW, IDLE SPEED Price: Call Us |
| 104 |
231789 |
PIN, FLOAT HINGE Price: Call Us |
| 105 |
231855 |
VALVE ASSY, INLET NEEDLE Price: Call Us |
| 106 |
231854 |
INLET VALVE SEAT Price: Call Us |
| 108 |
224540 |
VALVE, CHOKE Price: Call Us |
| 111 |
262719 |
SPRING, CHOKE Price: Call Us |
| 117 |
232118 |
JET, MAIN (STANDARD) Price: Call Us |
| 117 |
232119 |
JET, MAIN (HIGH ALTITUDE) Price: Call Us |
| 121 |
499233 |
CARBURETOR OVERHAUL KIT Price: Call Us |
| 123 |
94913 |
SCREW, TORX HEX Price: Call Us |
| 125 |
499153 |
CARBURETOR ASSY Price: Call Us |
| 127 |
PARTS |
IMAGE REFER TO PARTS IMAGE Price: Call Us PARTS IMAGE |
| 130 |
224539 |
VALVE, THROTTLE Price: Call Us |
| 131 |
494379 |
SHAFT & LEVER, THROTTLE Price: Call Us |
| 133 |
494381 |
FLOAT, CARBURETOR Price: Call Us |
| 137 |
281165 |
GASKET, FLOAT BOWL Price: Call Us |
| 138 |
281164 |
WASHER, FLOAT BOWL SCREW Price: Call Us |
| 141 |
495931 |
SHAFT & LEVER, CHOKE Price: Call Us |
| 142 |
232117 |
NOZZLE, CARBURETOR Price: Call Us |
| 164 |
214047 |
ELBOW, CARBURETOR Price: Call Us |
| 166 |
94555 |
STUD, ROCKER ARM Price: Call Us |
| 171 |
281051 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 186A |
493496 |
ELBOW, FUEL PIPE Price: Call Us |
| 187 |
492790 |
HOSE, FUEL Price: Call Us |
| 188 |
94627 |
SCREW, SEMS 3/4" Price: Call Us |
| 192 |
492160 |
SCREW ASSY, ROCKER ARM Price: Call Us |
| 201 |
262767 |
LINK, GOVERNOR Price: Call Us |
| 209 |
260695 |
SPRING, GOVERNOR Price: Call Us |
| 216 |
262766 |
LINK, CHOKE Price: Call Us |
| 219 |
490815 |
GOVERNOR GEAR Price: Call Us |
| 222 |
495611 |
PLATE, GOVERNOR CONTROL Price: Call Us |
| 224 |
94729 |
SCREW, SEMS, HEX HEAD Price: Call Us |
| 225 |
495157 |
CRANK, GOVERNOR, 1/4" DIAMETER Price: Call Us |
| 227 |
493935 |
LEVER ASSY, GOVERNOR Price: Call Us |
| 230 |
94927 |
WASHER, GOVERNOR LEVER Price: Call Us |
| 232 |
262785 |
SPRING, GOVERNOR LINK Price: Call Us |
| 238 |
262836 |
CAP, VALVE Price: Call Us |
| 240 |
394358 |
FILTER, FUEL Price: Call Us |
| 246 |
224546 |
BRACE, AIR CLEANER Price: Call Us |
| 265 |
221535 |
CLAMP Price: Call Us |
| 284 |
94704 |
SCREW, AIR CLEANER Price: Call Us |
| 294 |
810068 |
SCREW, SET Price: Call Us |
| 304 |
496318 |
HOUSING, BLOWER Price: Call Us |
| 305 |
94786 |
SCREW Price: Call Us |
| 306 |
225020 |
SHIELD, CYLINDER Price: Call Us |
| 307 |
94930 |
SCREW Price: Call Us |
| 309 |
497595 |
MOTOR, STARTING, 12 VOLT Price: Call Us |
| 310 |
497602 |
BOLT, THRU Price: Call Us |
| 311 |
497608 |
BRUSH SET Price: Call Us |
| 333 |
495859 |
ARMATURE, MAGNETO Price: Call Us |
| 334 |
94731 |
SCREW, SEMS Price: Call Us |
| 337 |
491055 |
PLUG, SPARK Price: Call Us |
| 346 |
93705 |
SUB= 69485 Price: Call Us |
| 356 |
497708 |
WIRE ASSY Price: Call Us |
| 356A |
497671 |
WIRE, STOP Price: Call Us |
| 356B |
494705 |
WIRE, STOP Price: Call Us |
| 358 |
495993 |
GASKET SET Price: Call Us |
| 363 |
19203 |
PULLER, FLYWHEEL Price: Call Us |
| 383 |
89838 |
WRENCH SPARK PLUG Price: Call Us |
| 423 |
94903 |
SCREW, HEX HEAD Price: Call Us |
| 445 |
496894 |
CARTRIDGE, AIR CLEANER Price: Call Us |
| 455 |
222561 |
CUP, SCREEN MOUNTING Price: Call Us |
| 467 |
493903 |
KNOB, AIR CLEANER Price: Call Us |
| 474 |
393474 |
STATOR, ALTERNATOR, DUAL CIRCUIT Price: Call Us |
| 482 |
93621 |
SCREW, SEMS Price: Call Us |
| 503 |
806000 |
STRAP, STARTER Price: Call Us |
| 510 |
497606 |
DRIVE, STARTER Price: Call Us |
| 523 |
495230 |
CAP AND DIPSTICK, OIL FILLER Price: Call Us |
| 524 |
281370 |
SEAL, FILLER TUBE Price: Call Us |
| 525 |
496113 |
TUBE, OIL FILLER Price: Call Us |
| 535 |
272403 |
ELEMENT, AIR CLEANER Price: Call Us |
| 537 |
281106 |
O-RING, AIR CLEANER Price: Call Us |
| 544 |
497603 |
ARMATURE, STARTER Price: Call Us |
| 552 |
231597 |
BUSHING, GOVERNOR CRANK, 1/4" I.D. Price: Call Us |
| 562 |
94907 |
BOLT, GOVENOR LEVEL Price: Call Us |
| 592 |
231978 |
NUT, HEX Price: Call Us |
| 601 |
93053 |
CLAMP, HOSE, GREEN Price: Call Us |
| 614 |
93306 |
COTTER, HAIR PIN Price: Call Us |
| 615 |
263080 |
RETAINER Price: Call Us |
| 634 |
494455 |
SEAL, SPRING ASSY. Price: Call Us |
| 634A |
491323 |
SEAL, GOVERNOR Price: Call Us |
| 635 |
280872 |
ELBOW, SPARK PLUG Price: Call Us |
| 657 |
94906 |
SCREW Price: Call Us |
| 663 |
94929 |
SCREW, SELF-TAPPING Price: Call Us |
| 668 |
280848 |
SPACER Price: Call Us |
| 718 |
230192 |
PIN, DOWEL Price: Call Us |
| 726 |
392134 |
GEAR, RING Price: Call Us |
| 727 |
490324 |
COVER, STARTER Price: Call Us |
| 728 |
94951 |
SCREW, HEX HEAD Price: Call Us |
| 729 |
225170 |
RETAINER, WIRE Price: Call Us |
| 729A |
281390 |
CLIP, WIRE Price: Call Us |
| 741 |
262932 |
GEAR, TIMING Price: Call Us |
| 757 |
213998 |
LINK, COUNTERWEIGHT Price: Call Us |
| 758 |
399891 |
COUNTERWEIGHT ASSY Price: Call Us |
| 759 |
298909 |
PIN ASSY, PISTON, STD Price: Call Us |
| 761 |
94593 |
SCREW, COUNTERWEIGHT Price: Call Us |
| 783 |
280104 |
GEAR, STARTER Price: Call Us |
| 801 |
394856 |
CAP, DRIVE Price: Call Us |
| 802 |
497605 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 803 |
497604 |
HOUSING, STARTER Price: Call Us |
| 842 |
270920 |
SEAL, OIL FILLER CAP Price: Call Us |
| 847 |
496415 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 851 |
493880 |
TERMINAL, IGNITION CABLE Price: Call Us |
| 868 |
494435 |
SEAL ASSEMBLY, VALVE Price: Call Us |
| 868A |
272610 |
GASKET, VALVE Price: Call Us |
| 871 |
262835 |
BUSHING, GUIDE (INTAKE & EXHAUST) Price: Call Us |
| 872 |
281104 |
COVER, AIR CLEANER Price: Call Us |
| 875 |
495862 |
BODY, AIR CLEANER Price: Call Us |
| 877 |
393456 |
DIODE & CONNECTOR ASSY Price: Call Us |
| 947 |
497672 |
SOLENOID Price: Call Us |
| 965 |
94108 |
LOCKNUT, AIR CLEANER MOUNTING Price: Call Us |
| 975 |
495933 |
BOWL ASSEMBLY, CARBURETOR Price: Call Us |
| 977 |
494385 |
CARBURETOR GASKET KIT Price: Call Us |
| 987 |
281166 |
SEAL, THROTTLE SHAFT Price: Call Us |
| 1005 |
280687 |
FAN, FLYWHEEL Price: Call Us |
| 1006 |
224413 |
RETAINER, FAN Price: Call Us |
| 1019 |
496758 |
LABEL KIT Price: Call Us |
| 1022 |
272475 |
GASKET, COVER Price: Call Us |
| 1023 |
224552 |
COVER, ROCKER ARM Price: Call Us |
| 1026 |
494432 |
ROD, PUSH, INTAKE Price: Call Us |
| 1026 |
495136 |
ROD, PUSH, EXHAUST Price: Call Us |
| 1029 |
224554 |
ARM, ROCKER Price: Call Us |
| 1033 |
495992 |
VALVE OVERHAUL KIT Price: Call Us |
| 1034 |
495248 |
GUIDE ASSEMBLY, PUSH ROD Price: Call Us |
| 1036 |
499364 |
LABEL KIT, EMISSIONS Price: Call Us |
| 1044 |
94673 |
SCREW, SHOULDER, HEX HEAD Price: Call Us |
| 1045 |
231828 |
EXTENSION, CRANKSHAFT Price: Call Us |
| 1058 |
272623 |
MANUAL, OWNER'S Price: Call Us |
| 1090 |
497607 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 1091 |
281364 |
CAP, LIMITER Price: Call Us |
| 2500 |
28N707-1026 |
REPLACEMENT ENGINE Price: Call Us |
