| Ref | Part Number | Description |
|---|
| 1 |
45_108_06 |
Ring Set-Std .003 Price: Call Us |
| 1 |
45_108_10 |
Ring Set-Std .003 Price: Call Us |
| 2 |
45_874_01 |
Piston W/Ring Set-Std. Price: Call Us |
| 2 |
45_874_11 |
Piston W/Ring Set-Std. Price: Call Us |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 3 |
47_018_01 |
Retainer Price: Call Us |
| 4 |
45_067_22 |
Connecting Rod-Std. Price: Call Us |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 15 |
583507201 |
TANK.ASSY.XTERNAL.FILL.GT2.TEX This part replaces 532435816. Price: $129.99 |
| 20 |
532412165 |
CONTROL.THROTTLE.COBRA.BLACK Price: $27.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532187768 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532189541. Price: $27.99 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 45_067_23 |
Connecting |
Rod-.010 Price: Call Us 45_067_23 |
| 45_067_24 |
Connecting |
Rod (Std.) Price: Call Us 45_067_24 |
| 45_067_25 |
Connecting |
Rod (.010) Price: Call Us 45_067_25 |
| 45_108_07 |
Ring |
Set-.010 Price: Call Us 45_108_07 |
| 45_108_08 |
Ring |
Set-.020 Price: Call Us 45_108_08 |
| 45_108_09 |
Ring |
Set-.030 Price: Call Us 45_108_09 |
| 45_108_11 |
Ring |
Set-.010 Price: Call Us 45_108_11 |
| 45_108_12 |
Ring |
Set-.020 Price: Call Us 45_108_12 |
| 45_108_13 |
Ring |
Set-.030 Price: Call Us 45_108_13 |
| 45_874_02 |
Piston |
W/Ring Set-.003 Price: Call Us 45_874_02 |
| 45_874_03 |
Piston |
W/Ring Set-.010 Price: Call Us 45_874_03 |
| 45_874_04 |
Piston |
W/Ring Set-.020 Price: Call Us 45_874_04 |
| 45_874_05 |
Piston |
W/Ring Set-.030 Price: Call Us 45_874_05 |
| 45_874_12 |
Piston |
W/Ring Set-.003 Price: Call Us 45_874_12 |
| 45_874_13 |
Piston |
W/Ring Set-.010 Price: Call Us 45_874_13 |
| 45_874_14 |
Piston |
W/Ring Set-.020 Price: Call Us 45_874_14 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 70 |
583955601 |
TUBE.EXHAUST.LH.FR961/FR730 This part replaces 532424765. Price: $24.99 |
| 71 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 This part replaces 532424766. Price: $24.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 108 |
583400501 |
COVER.PULLEY.ENGINE.SRD.FRENCH This part replaces 532423041. Price: $89.99 |
| 137 |
532441461 |
SPILL.CUP Price: $7.99 |
