| Ref | Part Number | Description |
|---|
| 1 |
133-2757-0P |
PANEL-ELECTRICAL This part replaces 133-2757-01. Price: $32.40 |
| 2 |
42862 |
BLOCK-TERMINAL, GROUND Price: $19.58 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
99-7430 |
RELAY-MINI Price: $22.99 |
| 4 |
99-7435 |
RELAY Price: $32.43 |
| 5 |
321-3 |
SCREW-HH Price: $0.28 |
| 6 |
104-7201 |
NUT-HF Price: $0.69 |
| 7 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 8 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 9 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 10 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 11 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 12 |
42863 |
STRIP-JUMPER Price: $2.90 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 14 |
106-5190 |
BATTERY Price: $170.85 |
| 15 |
133-2758 |
DECAL-FUSE Price: $4.85 |
| 15 |
599306004 |
FUEL TANK, 3GAL, 2.25"NECK, 20 This part replaces 532438027. Price: $199.99 |
| 16 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 17 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 18 |
585124801 |
CAP ASSY FUEL 3" GRAY Price: $17.99 |
| 18 |
63-7790 |
SCREW-CAP Price: $1.46 |
| 19 |
120-0615 |
CABLE-BATTERY, NEGATIVE Price: $80.04 |
| 20 |
105-0114 |
CABLE-BATTERY, POSITIVE Price: $70.97 |
| 20 |
587242701 |
THROTTLE.PRO.RSTART. 38 Price: $27.99 |
| 21 |
122-1442 |
HARNESS-WIRE This part replaces 122-0671. Price: $1,976.84 |
| 21 |
596321701 |
Screws Price: $2.99 |
| 22 |
122-0694 |
HARNESS-WIRE, REAR Price: $955.37 |
| 23 |
122-0695 |
HARNESS-WIRE, AUTO/MAN Price: $31.17 |
| 24 |
119-5049-03 |
BRACKET-BATTERY Price: $91.77 |
| 25 |
93-7595 |
BATTERY BOX ASM Price: $83.58 |
| 26 |
3339-175 |
STRAPPING-WEB Price: $18.99 |
| 27 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 45 |
596133601 |
Hardware Price: $2.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK Price: $22.99 |
| 71 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN Price: $27.99 |
| 79 |
596134202 |
Screws Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
