| Ref | Part Number | Description |
|---|
| 1 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 1 |
530047721 |
Bulb-Purge Price: $3.99 |
| 2 |
28-3680 |
TIRE Price: $118.18 |
| 2 |
530071717 |
Kit-Choke Lever Price: $7.99 |
| 3 |
217-60 |
RIM Price: $110.16 |
| 3 |
530015843 |
Screw-tank Price: $1.99 |
| 4 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 4 |
530057973 |
Assy - Fuel Cap w/retainer This part replaces 530049386. Price: $7.99 |
| 5 |
10-6821 |
BRAKE DRUM ASM This part replaces 10-6820. Price: $170.90 |
| 5 |
530095646 |
Assy-Fuel pickup Price: $2.99 |
| 6 |
111512 |
DISCONTINUED This part replaces 10-6830. Price: Call Us |
| 6 |
530069247 |
Kit-Fuel Line This part replaces 530071404. Price: $3.99 |
| 7 |
11-1579 |
DISCONTINUED-SEE MPV NOTES This part replaces 215-73. Price: Call Us |
| 7 |
530069216 |
Kit-Fuel/Purge line Price: $3.99 |
| 8 |
329-3 |
SCREW-HH Price: $0.22 |
| 8 |
530015775 |
Screw Price: $1.99 |
| 9 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 9 |
545000501 |
Cover-Air box Price: $3.99 |
| 10 |
325-11 |
SCREW-HH Price: $1.93 |
| 10 |
545082301 |
Filter-Air Price: $2.99 |
| 11 |
10-8000 |
BRAKE BRACKET *B Price: $37.62 |
| 11 |
530015849 |
Screw-Carb. Price: $1.99 |
| 12 |
237-80 |
O-RING Price: $6.10 |
| 12 |
545000601 |
Box-Air Price: $4.99 |
| 13 |
353-389 |
FITTING-ELBOW, 45 DEG Price: $36.57 |
| 14 |
32108-10 |
DISCONTINUED Price: Call Us |
| 15 |
27-2580 |
DISCONTINUED Price: Call Us |
| 15 |
545075305 |
Assy-Fuel Tank This part replaces 545075304. Price: $11.99 |
| 16 |
27-2160 |
DISCONTINUED Price: Call Us |
| 16 |
530015771 |
Screw-Crankcase Price: $1.99 |
| 17 |
3220-2 |
NUT-JAM Price: $0.50 |
| 17 |
530015952 |
Screw-Shroud Price: $1.99 |
| 18 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 18 |
545000701 |
Assy-Rear Shroud Price: $17.99 |
| 19 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 20 |
321-2 |
SCREW-HH Price: $2.79 |
| 20 |
530027593 |
Valve-Reed Price: $1.99 |
| 21 |
10-6350 |
CONTROL ROD WA Price: $102.40 |
| 21 |
530029781 |
Stop-Reed Price: $1.99 |
| 22 |
321-5 |
SCREW-HH Price: $0.22 |
| 22 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 23 |
10-8220 |
TOOL BOX PAD Price: $24.12 |
| 23 |
530015875 |
Screw-Retainer Price: $1.99 |
| 24 |
10-6430 |
DISCONTINUED Price: Call Us |
| 24 |
530055492 |
Isolator-Tank Price: $1.99 |
| 25 |
27-2380 |
SPACER Price: $11.14 |
| 25 |
530054941 |
Ret.-Tank Price: $1.99 |
| 26 |
3290-318 |
DISCONTINUED Price: Call Us |
| 26 |
530054834 |
Handle-Starter Price: $1.99 |
| 27 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 27 |
545050409 |
Kit - Rope This part replaces 545050410. Price: $4.99 |
| 28 |
3217-9 |
NUT-HH Price: $0.37 |
| 28 |
545081601 |
Bearing-Inner Price: $7.99 |
| 29 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 29 |
530015787 |
Retainer Price: $1.99 |
| 30 |
530019158 |
Seal Price: $2.99 |
| 31 |
27-8140 |
DISCONTINUED X-REF Price: Call Us |
| 31 |
530032102 |
Bearing-Outer Price: $8.99 |
| 32 |
329-7 |
SCREW-HH This part replaces 215-105. Price: $0.22 |
| 32 |
530015789 |
Ret.-Crankshaft Price: $2.99 |
| 33 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 33 |
530028807 |
Assy-Crankshaft Price: $19.99 |
| 34 |
20-7650 |
DISCONTINUED Price: Call Us |
| 35 |
3217-5 |
NUT-HEX Price: $0.25 |
| 36 |
136-8446 |
KIT, CENTER PULL FRAME This part replaces 12-8200. Price: $340.89 |
| 36 |
530055524 |
Assy-Flywheel Price: $22.99 |
| 37 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 37 |
530016030 |
Washer Price: $1.99 |
| 38 |
282-2 |
YOKE Price: $30.04 |
| 38 |
530055620 |
Spacer Price: $4.99 |
| 39 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 39 |
530015775 |
Screw-Baffle Price: $1.99 |
| 40 |
10-8010 |
DISCONTINUED X-REF Price: Call Us |
| 40 |
545115201 |
Plate-Baffle This part replaces 530054939. Price: $2.99 |
| 41 |
11-5790 |
KEY-SQUARE Price: $17.50 |
| 41 |
545050408 |
Kit-Pulley Price: $14.99 |
| 42 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 42 |
545008014 |
KIT STARTER SPRING This part replaces 545054901. Price: $3.99 |
| 43 |
530019182 |
Grommet Price: $1.99 |
| 43 |
62-5070 |
DECAL-WARNING This part replaces 27-2890. Price: $5.59 |
| 44 |
215-75 |
HOLD DOWN SPRING Price: $7.60 |
| 44 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 45 |
530055248 |
Assy-Fan Housing Price: $17.99 |
| 45 |
99-5652 |
BRAKE ASM & LEVER This part replaces 3-6944. Price: $179.21 |
| 46 |
215-74 |
DISCONTINUED Price: Call Us |
| 46 |
530094189 |
Washer-Clutch Price: $2.99 |
| 47 |
215-76 |
DISCONTINUED Price: Call Us |
| 47 |
530055122 |
Assy-Clutch Price: $8.99 |
| 48 |
232-24 |
STEM-VALVE Price: $4.03 |
| 48 |
530150247 |
Assy-Drum/Adapter Price: $17.99 |
| 49 |
530010960 |
Assy-Conn. Rod Price: $14.99 |
| 50 |
530015162 |
Ret.-Piston pin Price: $1.99 |
| 51 |
530012594 |
Ring-Piston Price: $3.99 |
| 54 |
530058846 |
Assy-Leadwire Price: $4.99 |
| 55 |
530016387 |
Bolt-Muffler 1/4"-20 Price: $1.99 |
| 56 |
530015241 |
Screw Price: $1.99 |
| 57 |
545030502 |
Kit-Spark Arrestor Price: $5.99 |
| 59 |
545033201 |
Shield Price: $3.99 |
| 61 |
530012586 |
Cylinder Price: $17.99 |
| 63 |
530001624 |
Bolt-Cyl. 1/4"-20 Price: $1.99 |
| 64 |
545081826 |
Kit - Ignition Module This part replaces 530039234. Price: $32.99 |
| 65 |
530016357 |
Screw-Module Price: $1.99 |
