| Ref | Part Number | Description |
|---|
| 1 |
98-1880-03 |
KNUCKLE-PIVOT This part replaces 98-1880. Price: $350.23 |
| 3 |
99-5610 |
PIN Price: $40.16 |
| 4 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 6 |
94-8947 |
BUSHING-FLANGE Price: $4.54 |
| 8 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 10 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 11 |
93-2704-03 |
LINK-LEFT This part replaces 93-2704. Price: $23.18 |
| 12 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 13 |
98-8823 |
LINK Price: $239.39 |
| 14 |
92-7637 |
HOSE ASM Price: $92.60 |
| 15 |
67-1750 |
BUSHING Price: $0.92 |
| 16 |
92-8002 |
SWITCH-LIFT, BACK BIASED Price: $105.67 |
| 19 |
92-8754 |
DISCONTINUED Price: Call Us |
| 20 |
99-5621 |
GUIDE-HOSE Price: $34.45 |
| 23 |
33114-020 |
SCREW-HH Price: $0.28 |
| 24 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 25 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 28 |
93-6687 |
DECAL-NO STEP Price: $14.45 |
| 29 |
105-0111 |
DISCONTINUED This part replaces 99-2566. Price: Call Us |
| 30 |
105-0112 |
LIFT ARM ASM #7 This part replaces 99-2567. Price: $696.09 |
| 33 |
93-2699 |
PIN Price: $48.15 |
| 34 |
33029-00 |
NUT-LOCK, NI Price: $2.92 |
| 35 |
98-8821 |
LINK-REAR Price: $30.71 |
| 36 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 37 |
75-6370 |
CAP-SENSOR Price: $8.87 |
| 39 |
138-6956 |
CYLINDER ASM-HYDRAULIC This part replaces 93-2631. Price: $692.61 |
| 40 |
93-2700 |
ROLLER-PLASTIC Price: $30.55 |
| 46 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 47 |
94-1449 |
FITTING-STR,ORIF Price: $112.90 |
| 49 |
98-2427-01 |
ARM-SUPPORT, RH #7 ASM This part replaces 98-2427. Price: $1,030.36 |
| 50 |
98-2426 |
ARM-SUPPORT, LH NO. 6 Price: $1,030.36 |
| 52 |
340-78 |
NUT-LOCK Price: $1.63 |
| 53 |
340-75 |
BULKHEAD-TEE Price: $45.10 |
| 54 |
94-1443 |
ELBOW-UNION BULKHEAD Price: $46.30 |
| 55 |
94-1444 |
UNION-BULKHEAD Price: $33.59 |
| 64 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 65 |
92-7643 |
HYD HOSE ASM Price: $118.39 |
| 70 |
147-6067 |
PIVOT PIN ASM This part replaces 98-8826. Price: $44.62 |
| 72 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 75 |
2412-93 |
CLAMP-R Price: $1.02 |
| 76 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 79 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 80 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 81 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 82 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 83 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 84 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 85 |
106-9004 |
BUMPER This part replaces 99-5605. Price: $6.35 |
| 86 |
283-71 |
PIN-LYNCH Price: $2.73 |
