| Ref | Part Number | Description |
|---|
| 1 |
137-6110 |
TUBE ROLLER 3.0IN DIA X 24.5IN This part replaces 115-8297-03. Price: $273.64 |
| 1 |
532140064 |
Spring, Mower Clutch (AYP part number) This part replaces 532122028. Price: $12.99 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
876020308 |
Pin, Cotter 3/32 x 1/2 (AYP part number) This part replaces 876020312. Price: $1.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
873680600 |
Nut, Crownlock 3/8-16 UNC Price: $1.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
819131412 |
Washer 13/32 x 7/8 x 12 Ga. (AYP part number) Price: $3.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
532121316 |
Idler, Flat (AYP part number) Price: $22.99 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
819132203 |
Washer 13/32 x 1-3/8 x 3 Ga. (AYP part number) Price: $3.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
532126756 |
Guide, Belt (AYP part number) Price: $25.96 |
| 8 |
532123702 |
Assembly, Mower Idler Arm (AYP part number) Price: $8.99 |
| 9 |
872110618 |
Bolt, Carriage 3/8-16 x 2 1/4 (AYP part number) Price: $2.99 |
| 10 |
532122049 |
Rod, Brake (AYP part number) Price: $9.39 |
| 11 |
532106578 |
Assembly, Brake (AYP part number) Price: $32.99 |
| 12 |
532124293 |
V-Belt (AYP part number) Price: $34.99 |
| 13 |
532124208 |
MANDREL ASS'Y This part replaces 532124207. Price: $109.99 |
| 14 |
873680400 |
Nut, Crownlock 1/4-20 (AYP part number) Price: $2.99 |
| 15 |
532144727 |
HOUSING 36" This part replaces 532126410. Price: $171.99 |
| 16 |
872140404 |
Bolt, Carriage 1/4-20 x 1/2 (AYP part number) Price: $3.99 |
| 17 |
532100668 |
Support, Plate Jackshaft (AYP part number) Price: $2.38 |
| 18 |
817490614 |
Screw Hex Thdrol. 3/8-16 x 7/8 (AYP part number) Price: Call Us |
| 19 |
532143969 |
BLADE 36" NONVENT This part replaces 532126338. Price: $14.99 |
| 20 |
874610624 |
Bolt, Fin. Hex 3/8-24 UNF x 1-1/2 Gr. 5 (AYP part number) Price: $3.99 |
| 21 |
539990118 |
SLW 3/8 STD This part replaces 810030600. Price: $1.99 |
| 22 |
819132012 |
Washer 13/32 x 1-1/4 x 12 Ga. (AYP part number) Price: $2.99 |
| 23 |
874760620 |
BOLT This part replaces 817490620. Price: $3.99 |
| 24 |
872140505 |
Bolt, Carriage 5/16-18 UNC x 5/8 (AYP part number) Price: $2.99 |
| 25 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 26 |
872110608 |
Bolt, Carriage 3/8-16 UNC x 1 Gr. 5 (AYP part number) Price: $3.99 |
| 27 |
532123439 |
Guide, R.H. Rear Belt (AYP part number) Price: $29.99 |
| 28 |
532122051 |
Support, Idler Arm (AYP part number) Price: $3.99 |
| 29 |
532123673 |
Guide, L.H. Belt (AYP part number) Price: $8.99 |
