| Ref | Part Number | Description |
|---|
| 1 |
105-6967 |
DISCONTINUED Price: Call Us |
| 2 |
88-4510 |
HOUSING-SPINDLE Price: $71.13 |
| 3 |
38-7820 |
BEARING-BALL This part replaces 100-1048. Price: $13.99 |
| 4 |
62-3661 |
SPACER Price: $10.41 |
| 5 |
80-4380 |
SPACER Price: $4.08 |
| 6 |
80-4360 |
SHIELD-BEARING Price: $12.11 |
| 7 |
80-4341 |
SHAFT-SPINDLE Price: $40.48 |
| 8 |
92-7952-03 |
BLADE-RECYCLER Price: $22.97 |
| 9 |
105-6973 |
PULLEY ASM Price: $72.62 |
| 10 |
126-2928 |
KIT, ANTI-SCALP ROLLER AXLE This part replaces 99-2842. Price: $18.59 |
| 11 |
1-603299 |
ROLLER-SCALP, ANTI This part replaces 68-2730. Price: $21.99 |
| 12 |
29-4820 |
ROLLER Price: $14.88 |
| 13 |
118960-03 |
SHAFT-ROLLER Price: $25.18 |
| 14 |
29-5590-03 |
BRACKET-PIVOT Price: $23.25 |
| 15 |
98-5049 |
DISCONTINUED Price: Call Us |
| 16 |
40-6230 |
SPRING Price: $37.99 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 18 |
3211-15 |
SCREW-HH Price: $7.99 |
| 19 |
3296-5 |
NUT-HEX Price: $3.09 |
| 20 |
32144-41 |
SCREW-TAPTITE Price: $4.79 |
| 21 |
3290-465 |
WASHER-BELLEVILLE Price: $2.89 |
| 22 |
26-0671 |
SCREW-HH Price: $7.99 |
| 23 |
98-5975 |
WASHER-BELLEVILLE Price: $3.09 |
| 24 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 25 |
3230-18 |
SCREW-CARR Price: $4.09 |
| 26 |
105-6975-01 |
DISCONTINUED Price: Call Us |
| 27 |
105-6974-01 |
DISCONTINUED Price: Call Us |
| 28 |
46-8560 |
SCREW-HHFTF Price: $1.79 |
| 29 |
106-6408 |
DISCONTINUED Price: Call Us |
| 30 |
3219-6 |
NUT-HEX Price: $2.78 |
| 31 |
321-4 |
SCREW-HH Price: $0.99 |
| 32 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 33 |
105-6977 |
BELT V Price: $133.35 |
| 34 |
3272-21 |
PIN-COTTER Price: $3.09 |
| 35 |
1-373034 |
WASHER Price: $3.19 |
| 42 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 50 |
93-7652 |
BAFFLE-LH Price: $202.26 |
| 51 |
93-7651 |
BAFFLE-RH Price: $202.26 |
| 52 |
84-5760 |
PLATE-KICKER Price: $8.58 |
| 53 |
59-4310 |
SPACER Price: $0.20 |
| 54 |
322-6 |
SCREW-HH Price: $0.45 |
| 55 |
94-5583 |
KNOB Price: $12.99 |
| 56 |
32149-1 |
NUT-KEPS Price: $5.59 |
| 57 |
3290-456 |
WASHER-BELLEVILLE Price: $2.59 |
