| Ref | Part Number | Description |
|---|
| 1 |
04001-190 |
Bolt, Hex Head 1/2-13 x 2-3/4" (48V & 52V - One Weight) Price: Call Us |
| 2 |
431183 |
Spacer, Wheel Mount Price: Call Us |
| 3 |
04001-30 |
Bolt, Hex Head 3/8-16 x 4.00 Price: Call Us |
| 4 |
487321 |
Chain, Tine Drive Price: Call Us |
| 5 |
487320 |
Chain, Wheel Drive Price: Call Us |
| 6 |
453356 |
Sprocket, Motor Price: Call Us |
| 7 |
487439 |
Bolt, Ilder Sprocket Price: Call Us |
| 8 |
04063-XX |
No Part Description Available Price: Call Us |
| 9 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 10 |
487270 |
Sprocket, Idler 15T Price: Call Us |
| 11 |
04003-23 |
Carriage Bolt, 3/8-16 x 1.0" Price: Call Us |
| 12 |
428948 |
Bracket LH, Wheel Mount Price: Call Us |
| 13 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 14 |
04024-03 |
Nut, Push-On 5/16-18 Price: Call Us |
| 15 |
431182 |
Bushing, Idler Sprocket Price: Call Us |
| 16 |
04019-06 |
Nut, Hex Serrated Flange 1/2-13 Price: Call Us |
| 17 |
493896 |
Assembly (incl. #18, 19, 20, 21, 22) Price: Call Us |
| 18 |
481035 |
Nut , Spec ial 1 -1/ 1 6 - 1 8 Price: Call Us |
| 19 |
487330 |
Bearing, Ball 30mm Bore x 62mm OD Price: Call Us |
| 20 |
431180 |
Spacer, Wheel Bearing Price: Call Us |
| 21 |
453345 |
Hub, Wheel Price: Call Us |
| 22 |
453346 |
Shaft, Wheel Price: Call Us |
| 23 |
04063-07 |
KEY, WOODRUFF #9, 3/16 X 3/4" Price: Call Us |
| 24 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 25 |
46928 |
Wheel Hub Assembly Price: Call Us |
| 26 |
04008-01 |
Bolt, Serr. Flange 1/2-20 x 4.563" Price: Call Us |
| 27 |
422214 |
Lock Washer, Wheel Motor Price: Call Us |
| 28 |
04027-01 |
Hex Castle Nut, 3/4-28 UNEF Price: Call Us |
| 29 |
487462 |
Wheel Assy., 18 x 6.5 - 8 Price: Call Us |
| 30 |
04028-02 |
Wheel Nut, 1/2-20 x 13/16 Price: Call Us |
| 31 |
04017-16 |
Capscrew, 5/16-18 x .75 Serrated Flange Hex Head Price: Call Us |
| 32 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 33 |
453354 |
Pivot Bearing Wlmt Price: Call Us |
| 34 |
487280 |
Pivot Bearing Price: Call Us |
| 35 |
04021-19 |
Locknut, Hex 1/2-13 Center Lock Price: Call Us |
| 36 |
453353 |
Pivot Bearing Wlmt Price: Call Us |
| 37 |
429025 |
Stop Plate, Pivot Bearing Price: Call Us |
| 38 |
04014-07 |
Capscrew, 3/8-16 x 1-1/4" Price: Call Us |
| 39 |
453337 |
Pivot Arm Wlmt Price: Call Us |
| 40 |
04001-117 |
BOLT, HEX HEAD, 7/16-14 X 1-3/4 Price: Call Us |
| 41 |
487259 |
Bearing, 1" Flange Price: Call Us |
| 42 |
04019-05 |
HEX NUT, 7/16-14 SERRATED FLANGE Price: Call Us |
| 43 |
04001-178 |
Bolt, Hex Head 7/16-20 x 1" Price: Call Us |
| 44 |
453336 |
Tine Wlmt, LH Drive Price: Call Us |
| 45 |
485553 |
Clamp Collar, 1.25 Bore 2 Piece Price: Call Us |
| 46 |
48100-08 |
Bushing, 1.003 ID This part replaces 48100-17. Price: Call Us |
| 47 |
453335 |
Tine Wlmt, Idler Price: Call Us |
