| Ref | Part Number | Description |
|---|
| 1 |
23230506 |
SET SCREW Price: Call Us |
| 1 |
27-6861 |
SHAFT-FLANGED AXLE, LH Price: $984.28 |
| 2 |
130811 |
SUB= 532130811 Price: Call Us |
| 2 |
99-6969 |
SEAL-OIL, WHEEL END This part replaces 92-1774. Price: $14.71 |
| 3 |
122955X |
BRKT ASSY Price: Call Us |
| 3 |
21-8180 |
BEARING ASM Price: $65.11 |
| 4 |
21-9450 |
SHIELD-DUST Price: $45.14 |
| 4 |
72140404 |
BOLT Price: Call Us |
| 5 |
43-6810 |
SPIDER-TORQUE Price: $138.50 |
| 5 |
74770812 |
SCREW Price: Call Us |
| 6 |
121463X |
KEEPER BELT Price: Call Us |
| 6 |
21-9390 |
SOCKET-SCREW, ADJUSTING Price: $5.56 |
| 7 |
104213X |
NUT-CAP TI Price: Call Us |
| 7 |
21-9370 |
SCREW-ADJUSTING Price: $18.80 |
| 8 |
19091016 |
WASHER Price: Call Us |
| 8 |
21-9380 |
NUT-PIVOT Price: $26.77 |
| 9 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 10 |
109227X |
PAD IDLER TI Price: Call Us |
| 10 |
21-8360 |
CLIP-RETAINING Price: $1.29 |
| 11 |
28-0680-03 |
DRUM-BRAKE This part replaces 28-0680. Price: $358.84 |
| 11 |
72140406 |
BOLT T Price: Call Us |
| 12 |
9179R |
SUB= TH3H390 Price: Call Us |
| 12 |
94-6935 |
LOCKNUT Price: $1.09 |
| 13 |
2649M |
KEY T Price: Call Us |
| 13 |
28-0670 |
SEAL-GREASE Price: $19.74 |
| 14 |
21-9440 |
SPRING-SCREW, ADJUSTING Price: $11.92 |
| 14 |
9174R |
TRANS SHEAVE RT Price: Call Us |
| 15 |
132213 |
SUB= 532132213 Price: Call Us |
| 15 |
21-9460 |
RETAINER-LEVER, BRAKE Price: $2.18 |
| 16 |
12000036 |
KLIP RING TI Price: Call Us |
| 16 |
84-8600 |
SET-SHOES, LINED Price: $131.50 |
| 17 |
21-9430 |
SPRING-RETURN, RH Price: $19.96 |
| 17 |
73350600 |
NUT Price: Call Us |
| 18 |
21-9420 |
SPRING-RETURN, LH Price: $19.96 |
| 18 |
9178R |
SUB= 75673 Price: Call Us |
| 19 |
24-9180 |
STRUT AND LEVER ASM Price: $86.76 |
| 19 |
674A30 |
IDLER ARM TI Price: Call Us |
| 20 |
74760620 |
Bolt Fin Flex 3/8-16unc X 1-1/4 Price: Call Us |
| 21 |
106968X |
SHAFT IDLER TI Price: Call Us |
| 21 |
94-6934 |
SCREW-HH Price: $6.99 |
| 22 |
105358X |
SHIELD-DIRT TI Price: Call Us |
| 22 |
24-8840 |
RING-RETAINING, WHEEL BEARING Price: $37.15 |
| 23 |
10040400 |
LOCKWASHER Price: Call Us |
| 23 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 24 |
73220400 |
SUB= 50675 Price: Call Us |
