| Ref | Part Number | Description |
|---|
| 1 |
112-6311 |
HOOD ASM Price: $2,736.62 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $138.99 |
| 2 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 2 |
874760412 |
BOLT LT Price: $3.99 |
| 3 |
103-2898 |
LATCH-RUBBER Price: $32.99 |
| 4 |
237-136 |
GROMMET Price: $3.52 |
| 5 |
32104-95 |
SCREW-HWH Price: $0.41 |
| 6 |
3290-255 |
PIN-COTTER, HAIR Price: $7.89 |
| 7 |
108-9943-03 |
SCREEN-INTAKE Price: $224.62 |
| 8 |
110-8291 |
ROD-PROP, HOOD Price: $21.91 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $11.99 |
| 9 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 10 |
3274-39 |
SCREW-HSBH Price: $4.34 |
| 11 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 12 |
3229-11 |
SCREW-CARR Price: $0.99 |
| 13 |
103-2897 |
LATCH-CATCH Price: $7.99 |
| 14 |
110-8285-0P |
ANGLE-SEAL This part replaces 110-8285-03. Price: $45.67 |
| 15 |
110-9795 |
SUPPORT-HOOD Price: $343.10 |
| 16 |
108-9811 |
SUPPORT-ROD, PROP Price: $14.74 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 17 |
110-8287 |
BULB-SEAL Price: $18.69 |
| 18 |
3234-33 |
SCREW-HHF Price: $0.79 |
| 19 |
104-7201 |
NUT-HF Price: $0.69 |
| 20 |
110-8288 |
SEAL-FOAM Price: $2.67 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 25 |
532412894 |
CABLE.STARTER.6GA.BL/RED.14. Price: $10.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 28 |
532198885 |
CABLE.BLACK.18"REAR.BA Price: $19.99 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $24.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $6.99 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $68.99 |
| 41 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 817720408. Price: $1.99 |
| 42 |
532154336 |
Cover, Terminal Red This part replaces 532131563. Price: $4.99 |
| 43 |
532192507 |
SOLENOID.W/BRASS.PLUNG Price: $16.99 |
| 55 |
532171877 |
Bolt 5/16-18 unc x 3/4 This part replaces 817060512. Price: $3.99 |
| 71 |
532400449 |
HARNESS.IGN.CHASS.TEX.REAR.BAT Price: $24.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $2.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
532192540 |
SCREW.PLASTITE Price: $2.99 |
